Quick Installation Guide

for All Ethernet Switches

First Edition (September 2001)

6SWITCHML.01

Printed In Taiwan

RECYCLABLE

Introduction

This Quick Installation Guide gives step-by-step

instructions for setting up all D-Link switches.

Please note that the model you have purchased

may appear slightly different from those shown in

the illustrations.

For more detailed information about your switch,

its components, making network connections, and

technical specifications, please refer to the User’s

Guide included with your switch.

Step 1  Unpacking

Open the shipping carton and carefully unpack its

contents. Please consult the packing list located in

the User Guide to make sure all the correct items

are present and undamaged. If any item is found

missing or damaged, please contact your local

D-Link reseller for replacement.

Items Included in Switch Packages

Type of Switch *

Unmanaged Smart or Managed

Item

Palm

Desktop/Rack Mount

Chassis

Device Yes

Yes Yes Yes

RS-232 Cable

(Printer cable) No No Yes Yes

Rack Mounting

Brackets No Yes Yes Yes

Rubber Feet Yes

Yes Yes Yes

Power Cord

(Adapter) Yes

Yes Yes Yes

User¡ƒs Gui d Yes

Yes Yes Yes

Multi-lingual

QIG Yes

Yes Yes Yes

*Stackable switches, unlike standalone switches, should also

include a cascade cable.

Step 2  Switch Installation

For safe switch installation and operation, it is

recommended that you:

♦ Visually inspect the power cord and see that

it is secured fully to the AC power connector.

♦ Make sure that there is proper heat

dissipation from and adequate ventilation

around the switch.

♦ Do not place heavy objects on the switch.

Desktop or Shelf Installation

When installing the switch on a desktop or shelf, the

rubber feet included with the device must be

attached on the bottom at each corner of the device’s

base. Allow enough ventilation space between the

device and the objects around it.

Figure 1. Attaching the rubber feet

Rack Installation

The switch can be mounted in an EIA standard size,

19-inch rack, which can be placed in a wiring closet

with other equipment. To install, attach the

mounting brackets on the switch’s front panel (one

on each side) and secure them with the screws

provided (please note that these brackets are not

designed for palm size switches).

Figure 2. Attaching the mounting brackets

Then, use the screws provided with the equipment

rack to mount the switch in the rack.

Figure 3. Installing the switch in a standard-sized

equipment rack

Step 3  Understanding Device

Network Connections

At this point, please connect the AC power cord into

an electrical outlet (preferably one that is grounded

and surge protected) and into the rear of the switch.

Once the switch is powered on, you will be able to

immediately see whether the network connections

are valid or not. A valid connection will cause the

Link/Act LED on the front panel of the switch to

light up for the corresponding port being connected.

Power Failure

As a precaution, the switch should be unplugged in

case of power failure. When power is resumed, plug

the switch back in.

Step 4  Plugging in the AC Power

Cord

Computers, servers and routers can be connected to

the switch by using media-appropriate fiber optic

cabling. For more information about cable types,

please refer to the User’s Guide.

Figure 4. Plugging the switch into an outlet

Additional Information

If you are encountering problems setting up your

network, please refer to the User’s Guide that came

with the switch. It contains many more rules,

charts, explanations and examples to help you get

your network up and running.

Additional help is available online at

http://www.dlink.com, http://www.dlink.com.uk, or

through our offices listed at the back of the User’s

Guide.
