D-Link AirPlus G DWL-G650X Manuale utente

You must have at least the following:

•An Apple PowerBook running Mac OS X (10.3.x *) with an available 32-bit Cardbus

slot

•An 802.11g or 802.11b Access Point (for Infrastructure Mode) or another 802.11g

or 802.11b wireless adapter (for Ad-Hoc; Peer-to-Peer networking mode.)

AirAir

Air

PlusPlus

Plus™™

™™

™

802.11g/2.4GHz802.11g/2.4GHz

802.11g/2.4GHz

Wireless Cardbus AdapterWireless Cardbus Adapter

Wireless Cardbus Adapter

DWL-G650XWL-G650X

WL-G650XWL-G650X

WL-G650X

If any of the above items are missing, please contact your reseller.

CD-ROM (containing Drivers, Manual and Warranty)

This product works with the following operating

system software: Macintosh OS X

(version 10.3.x *)

BefBef

Beforor

oror

ore Ye Y

e Ye Y

e You Beginou Begin

ou Beginou Begin

ou Begin

DWL-G650X AirPlus™G 2.4GHz Wireless

Cardbus Adapter

Check YCheck Y

Check Your Pour P

our Pour P

our Packack

ackack

ackage Contentsage Contents

age Contentsage Contents

age Contents

These are the items included with your DWL-G650X purchase:

their respective holders. Software and specifications subject to change without notice. DWL-G650X.07082004

* Please visit http://support.dlink.com for a list of supported operating system versions.

Installing the DWL-G650X Into Your

Computer

A. Locate the Cardbus slot on your laptop computer.

B. Gently insert the DWL-G650X into the Cardbus slot in your laptop

computer (as shown.)

Link/Activity LED

Indicates that the DWL-G650X is properly

installed when the computer is on and

blinks when data is being transmitted.

Antenna

Used to wirelessly connect

to 802.11b networks.

32-bit connector

This is the connector that fits into

the Cardbus slot of your laptop.

Installing the DriversInstalling the Drivers

Installing the Drivers

Double click the D-Link®icon

Insert the DWL-G650X Driver

CD into the CD-ROM drive.

Double-click D-Link

DWL-G650X.pkg

Click Continue

Select a Destination Volume

Click Continue

Installing the Drivers (continued)Installing the Drivers (continued)

Installing the Drivers (continued)

Click Install

Installing the Drivers (continued)Installing the Drivers (continued)

Installing the Drivers (continued)

Click OK

Enter the name and password of a user

with administrative rights.

Click Continue Installation

Click Restart

Driver Installation is Complete!

Connecting to YConnecting to Y

Connecting to Your Wirour Wir

our Wirour Wir

our Wireless Netweless Netw

eless Netweless Netw

eless Networkork

orkork

ork

Click DWL-G650X

Go to the Apple Menu and

select System Preferences.

Scroll through the list of available

wireless networks. If the network

is not listed, click the Start Scan

button.

To connect to a wireless network,

locate the network in the list of

available networks and double

click on it.

If connecting to a network with a DHCP server then your configuration is complete!

If you need to assign a static IP address to your DWL-G650X, then please follow the

steps on the following page.

Appendix - Assigning a Static IP Address to theAppendix - Assigning a Static IP Address to the

Appendix - Assigning a Static IP Address to the

DWL-G650XDWL-G650X

DWL-G650X

Select the Ethernet Adapter

Click Network

Go to the Apple Menu and

select System Preferences.

Note: Only perform these steps if you have

to assign a static IP address to your system.

Enter a unique IP address within

the same range as your network.

Enter the Subnet Mask of your

network.

Click Apply Now

Be sure Manually is selected.

Techniechni

echniechni

echnical Supportcal Support

cal Supportcal Support

cal Support

You can find software updates and user documentation on the D-Link website.

D-Link provides free technical support for customers within the United States and

within Canada for the duration of the warranty period on this product.

U.S. and Canadian customers can contact D-Link technical support through our

website, or by phone.

Tech Support for customers within the United States:

D-Link Technical Support over the Telephone:

(877) 453-5465

24 hours a day, seven days a week.

D-Link Technical Support over the Internet:

http://support.dlink.com

email:[email protected]

Tech Support for customers within Canada:

D-Link Technical Support over the Telephone:

(800) 361-5265

Monday to Friday 7:30am to 12:00am EST

D-Link Technical Support over the Internet:

http://support.dlink.ca

email:[email protected]
