2D-Link DIR-640L Quick Install Guide

Package Contents

• D-LinkDIR-640LWirelessN300CloudVPNRouter

• PowerAdapter(12V1.0A)

• EthernetCable

• ManualandWarrantyonCD

• QuickInstallGuide

Note: Usingapowersupplywithadierentvoltageratingthantheoneincludedwiththe

DIR-640Lwillcausedamageandvoidthewarrantyforthisproduct.Ifanyoftheaboveitems

aremissing,pleasecontactyourreseller.

System Requirements

Network Requirements

• AnEthernet-basedCableorDSLmodem

• 10/100Ethernetdevices

• 802.11n/gWirelessDevices

Web-based Conguration Utility Requirements

Computer with the following:

• Windows®,Macintosh,orLinux-basedoperatingsystem

• AninstalledEthernetadapter

Browser Requirements:

• InternetExplorer7orhigher

• Chrome

• Firefox

• Safari4orhigher

MakesureyouhavethelatestversionofJavainstalled.Visitwww.java.comto

downloadthelatestversion.

3D-Link DIR-640L Quick Install Guide

Hardware Overview

LEDs

1PowerLED Asolidlightindicatesyourdeviceispoweredon.

2InternetLED AsolidlightindicatesaconnectiontotheInternetport.This

LEDwillblinkduringdatatransmission.

3WirelessLED

Asolidlightindicatesthatthewirelessfunctionisready.This

LED will blink during data transmission. The LED will blink

slowlyfor120secondsduringtheWPSpairingprocessandwill

thenblinkrapidlyfor5secondsuponsuccessfullypairingwith

aWPSClient.

4LANLED(1-4) AsolidlightindicatesaconnectiontoanEthernetdevice.This

LEDwillblinkduringdatatransmission.

5USBPort Connect a USB 3G modem if you do not have a broadband

modemwithanEthernetport.

4D-Link DIR-640L Quick Install Guide

Hardware Overview

Connections

1COMPort Connectamodemwithaserialconnectorifyoudonothavea

broadbandmodemwithanEthernetport.

2LANPorts(1-4) ConnectEthernetdevicessuchascomputers,networkstorage

(NAS)devices,cameras,etc.

3InternetPort Connectyourbroadbandmodemtothisport.

4ResetButton Press and hold the reset button for 6 seconds to reset the

devicebacktothefactorydefaultsettings.

5PowerReceptor Connectthesuppliedpoweradapter.

6PowerButton Presstoturnthedeviceonoro.

123 5 6

5D-Link DIR-640L Quick Install Guide

Connect to your Network

Ifyouareconnectingtheroutertoacable/DSL/satellitemodem,please

followthestepsbelow:

1. Placetherouterinanopenandcentrallocation.Donotplug

thepoweradapterintotherouter.

2. Unplugthepowertoyourmodemandturnoyourcomputer.

3. UnplugtheEthernetcable(thatconnectsyourcomputertoyour

modem)fromyourcomputerandplaceitintotheInternetport

ontherouter.

4. PluganEthernetcableintooneofthefourLANportsonthe

router.PlugtheotherendintotheEthernetport onyour

computer.

5. Turnonorpluginyourmodem.Waitforthemodemtoboot

(about1minute).

6. Plugthepoweradaptertotherouterandconnecttoanoutlet

orpowerstrip.Pressthepowerbuttononthebacktopoweron

therouterandwaitabout30secondsfortheroutertoboot.

7. Turnonyourcomputer.

8. Verifythelinklightsontherouter.Thepowerlight,Internetlight,

andtheLANlight(theportthatyourcomputerispluggedinto)

shouldbelit. Ifnot,make sureyourcomputer,modem, and

routerarepoweredon and verifythecableconnectionsare

correct.

6D-Link DIR-640L Quick Install Guide

Setup Wizard

Openyourwebbrowserandthesetupwizardwillautomaticallylaunch.

Step 1:TheWelcomescreenwillappear.ClickNexttocontinue.

Step 2:TherouterwillautomaticallydetectyourInternetconnectiontype.

Step 3:Iftheroutercouldnotautomaticallydetectyourconnectiontype,select

yourconnectiontypeandclickNexttocontinue.

7D-Link DIR-640L Quick Install Guide

IfyouselectedPPPoE,enteryourPPPoEusernameandpassword.ClickNextto

continue.

Note: Make sure to remove your PPPoE software from your computer. The software is no longer

needed and will not work through a router.

IfyouselectedPPTP,enteryourPPTPsettingssuppliedbyyourISPandyourPPTP

usernameandpassword.ClickNexttocontinue.

IfyouselectedL2TP,enteryourL2TPsettingssuppliedbyyourISPandyourL2TP

usernameandpassword.ClickNexttocontinue.

8D-Link DIR-640L Quick Install Guide

Step 4: Createanameforyourwirelessnetwork(SSID),createapasswordforyour

wirelessnetwork(Wi-Fipassword),andthenclickNexttocontinue.

IfyouselectedStatic,enteryournetworksettingssuppliedbyyourInternetprovider.

ClickNexttocontinue.

Step 5: CreateanewpasswordandthenclickNexttocontinue.

9D-Link DIR-640L Quick Install Guide

Step 6:Selectyourtimezonefromthedrop-downmenuandthenclickNext

tocontinue.

Therouterwillreboot.Pleaseallow1-2minutes.

CloseyourbrowserwindowandreopenittotestyourInternetconnection.Itmay

takeafewtriestoinitiallyconnecttotheInternet.

Step 8: Youmaybookmarktherouter’swebUIbyclickingOK.Ifyoudonotwant

tobookmarkthelink,clickCancel.

Step 7: Yoursetupiscomplete.ClickSavetocontinue.

10D-Link DIR-640L Quick Install Guide

Onceyouhaveranthesetupwizard,youmayaccesstheweb-baseduserinterface

byopeningyourwebbrowserandtypehttp://192.168.0.1(orhttp://dlinkrouter.

local)intotheURLaddressbox.PressEnter.

Theloginpop-upscreenwillappear.SelectAdminandthenenteryourpassword.

ClickLog In.

Router Login

Pleaserefertotheusermanualformoreinformationonadvancedfeatures.
