D-Link DSL-G604T Manuale utente
DSL-G604T
©2004D-LinkSystems,Inc.Allrightsreserved.Trademarksorregisteredtrademarksarethepropertyoftheirrespectiveholders.
Softwareandspecificationssubjecttochangewithoutnotice.DSL-G604T.12062004
If any of the above items are missing, please contact your reseller.
CD-ROM with Manual
Before You Begin:
DSL-G604T Wireless ADSL Router
Check Your Package Contents
Wireless ADSL Router
12VAC, 1.2APower Adapter
Using a power
supply with a
differentvoltagerating
will damage this
product and void its
warranty.
This product can be setup usingThis product can be setup using
This product can be setup usingThis product can be setup using
This product can be setup using
anan
anan
any curry curr
y curry curr
y currenen
enen
ent Wt W
t Wt W
t Web breb br
eb breb br
eb browserowser
owserowser
owser, i.e, i.e
, i.e, i.e
, i.e.,.,
.,.,
.,
Internet Explorer 6 or NetscapeInternet Explorer 6 or Netscape
Internet Explorer 6 or NetscapeInternet Explorer 6 or Netscape
Internet Explorer 6 or Netscape
Navigator 6.2.3 or aboveNavigator 6.2.3 or above
Navigator 6.2.3 or aboveNavigator 6.2.3 or above
Navigator 6.2.3 or above
Pleasereadand makesureyouunderstand alltheprerequisitesfor proper installationof
your new ADSL Router. Have all the necessary information and equipment on hand
beforebeginningtheinstallation.
Ethernet Cable
Telephone Cord
802.11gAntenna
2
Hardware Overview
Front Panel
Power LED: Solid light
indicatesaconnectionto
agood powerconnector. Status LED: A blinking
light indicates normal
operation.If thislightisnot
litandthepowerlightison,
thisindicates failure.
ADSL LED: Lightssolid
when sychronized with
theADSLconnection. WLANLED:ThisLEDblinks
to indicate wireless activity.
LAN Ports: A solid light
indicates a connection
ontheassociatedport.A
blinking light indicates
activityontheassociated
port.
3
ResetButton: ResetstheDSL-G604T
tothefactorydefaultsettings.Holdfor
seven seconds for the unit to factory
reset.
Power Receptor: The AC
PowerAdapterconnectshere.
LAN Ports: Your computers
connect here using standard
Ethernetcables.
ADSL Port: Connects to
yourtelephonejackusing a
standardtelephonecord.
Rear Panel
Hardware Overview (continued)
Wireless Antenna:
Used for wireless
communication.
4
Hardware Installation
Step a
Step a
Step b
Step c
5
Hardware Installation (continued)
Connectthetelephonecordfromyourphone
jack to theADSLport on the DSL-G604T.
ConnectanEthernetcablefromyourcomputer
toa LAN port on the DSL-G604T.
Connect the power adapter to the power
connector on the DSL-G604T and the other
endtoaknowngoodpowersource.
Step a
Step b
Step c
6
Administhedefault User Name
andPassword.Type admin into
the User name and Password
fields.
Click OK
Typehttp://192.168.1.1 intothe
URL address box and press the
Enter or Return key.
Using the Setup Wizard
Click Run Wizard
Launch your Web browser
(a shortcut is typically found
onyour desktop).
Step a
Step b
Step c
Step d
7
Using the Setup Wizard (continued)
Click Next
This screen allows you to enter
a new password for the admin
account. This password is used
to log into the web-based
managementinterface.
SelectyourTime Zone
Click Next
Click Next
Step e
Step f
Step g
8
You will need to select the Internet Connection Type. If you are unsure which type of
InternetConnectionyouhave,pleasecontactyour InternetService Provider.Therearefour
connectionmodesandsettingsvarydependingontheconnectiontype.
1. Dynamic IPAddress - see Dynamic IP Address on page 8.
2. Static IPAddress - see Static IP Address on page 9.
3. PPPoE/PPPoA - see PPPoE/PPPoA on page 9.
4. Bridge Mode - see Bridge Mode on page 10.
A checklist of necessary settings is provided in the Appendix. Contact your Internet Service
Provider to obtain the necessary details.
Using the Setup Wizard (continued)
Click Next
Click Next
ClickClone MAC Address
Dynamic IP Address
Select your Connection Type
andproceed to step h1, h2, h3,
or h4 depending upon your
connection type.
The DSL-G604T defaults to the
most commonly used values in the
United States.
Note: If the MAC address does not
appear, please refer to the User
Manual on the CD-ROM.
2c
Step h
Step h1
Step h1
Step h2
Step h3
Step h4
9
Using the Setup Wizard (continued)
Static IP Address
Click Next
PPPoE/PPPoA
Click Next
The DSL-G604T defaults to the most
commonly used values in the United
States.The IP address information on
the right is only shown as an example
of the format that you will use.
The DSL-G604T defaults to the most
commonly used values in the United
States. Only modify these settings if
youaresuretheyneedtobechanged.
The User Name and Password will
be unique to your Internet account.
If you forget your account information,
please contact your Internet Service
Provider.
Step h2
Step h3
10
ClickRestart
Configurationiscomplete!Typein
a URL such as www.dlink.com
to test your connection.
Bridge Mode
Click Next
Using the Setup Wizard (continued)
Step h4
Step i
Step j
