D-Link DWR-161 Manuale utente
3G/4G PORTABLE WIRELESS N 150 ROUTER
DWR-161
QUICK
INSTALLATION
GUIDE
2DWR-161
ENGLISH
CONTENTS OF
PACKAGING
CD-ROM
INCLUDES TECHNICAL MANUALS
3G/4G PORTABLE WIRELESS N 150 ROUTER
DWR-161
ETHERNET CABLE
CAT5
If any of these items are missing from your packaging, contact
your reseller.
POWER ADAPTER
5 V / 1 A
CONTENTS
1700 mAh Li-ion BATTERY
3
DWR-161
ENGLISH
PRODUCT
SETUP
EASY SETUP: 3G/4G CONNECTION MODE
INSTALL THE 3G/4G USB ADAPTER
Plug your 3G/4G USB adapter into the USB port of the DWR-161.
CONNECT TO THE DWR-161
Plug one end of the Ethernet cable into the DWR-161. Plug the
other end of the cable into your PC's Ethernet port. You may
also connect to the router wirelessly. Please see the step below.
CONFIGURE THE DWR-161
Open a web browser and go to http://192.168.0.1. Enter admin
as the User Name, and leave the Password eld blank. You
may use the Setup Wizard to congure your DWR-161.
User Name xxxx
Password
Login
CONNECT TO THE DWR-161 WIRELESSLY
(OPTIONAL)
Use a PC or mobile device with an active wireless adapter to
scan for available wireless networks. Connect to the network
with the SSID labeled dlink.
Choose this mode if you want to use your DWR-161 to share a mobile Internet connection
through a 3G/4G USB adapter.
4DWR-161
ENGLISH
PRODUCT
SETUP
EASY SETUP: WAN CONNECTION MODE
CONNECT TO A CABLE/DSL MODEM
Plug one end of the Ethernet cable into the DWR-161. Plug the
other end of the cable into your cable/DSL modem.
CONNECT TO THE DWR-161
Use a PC or mobile device with an active wireless adapter to
scan for available wireless networks. Connect to the network
with the SSID labeled dlink.
CONFIGURE THE DWR-161
Open a web browser and go to http://192.168.0.1. Enter admin
as the User Name, and leave the Password eld blank. You
may use the Setup Wizard to congure your DWR-161.
User Name xxxx
Password
Login
Choose this mode if you want to use your DWR-161 to share an Internet connection from a
cable or DSL modem.
5
DWR-161
ENGLISH
TROUBLESHOOTING
SETUP AND CONFIGURATION PROBLEMS
1. HOW DO I CONFIGURE MY DWR-161 3G/4G PORTABLE WIRELESS N 150
ROUTER?
- Connect your PC to the DWR-161 using an Ethernet cable.
- Open a web browser and enter the router address: http://192.168.0.1
- The default username is admin. The default password is blank (leave this box empty).
- If you have changed the password and cannot remember it, you will need to reset the router to
factory default settings in order to set the password back to blank.
2. HOW DO I RESET MY DWR-161 3G/4G PORTABLE WIRELESS N 150 ROUTER TO
FACTORY DEFAULT SETTINGS?
- Ensure that the DWR-161 is plugged in and receiving power.
- Press and hold the reset button on the top of the device for 5 seconds.
Note: Resetting the product to the factory default will erase the current conguration.
To recongure your settings, log into the DWR-161 as outlined in question 1, then run the
Setup Wizard.
3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY
WIRELESS NETWORK NAME (SSID) OR WIRELESS ENCRYPTION KEY?
- For each PC that needs to connect to the DWR-161 wirelessly, you must ensure that the
correct Wireless Network Name (SSID) and encryption key has been entered.
- Use the web-based user interface (as described in question 1 above) to verify or choose your
wireless settings.
- Make sure you write down these settings so that you can enter them into each wirelessly
connected PC. You will nd a dedicated area on the back of this document to write down this
important information for future use.
4. WHY AM I UNABLE TO ESTABLISH AN INTERNET CONNECTION?
- If connecting using a 3G/4G connection, make sure that you are within range of your mobile
service provider, and that the service has been correctly congured on your 3G/4G USB
adapter.
- If connecting using ADSL/Cable service, make sure your modem has been enabled/connected
and is operational, and that the service is correctly congured.
6DWR-161
ENGLISH
TECHNICAL SUPPORT
Australia:
Tel: 1300-766-868
24/7 Technical Support
Web: http://www.dlink.com.au
E-mail: [email protected]
India:
Tel: +91-22-27626600
Toll Free 1800-22-8998
Web: www.dlink.co.in
E-Mail: [email protected]
Singapore, Thailand, Indonesia,
Malaysia, Philippines, Vietnam:
Singapore - www.dlink.com.sg
Thailand - www.dlink.co.th
Indonesia - www.dlink.co.id
Malaysia - www.dlink.com.my
Philippines - www.dlink.com.ph
Vietnam - www.dlink.com.vn
Korea:
Tel : +82-2-2028-1810
Monday to Friday 9:00am to 6:00pm
Web : http://d-link.co.kr
New Zealand:
Tel: 0800-900-900
24/7 Technical Support
Web: http://www.dlink.co.nz
E-mail: [email protected]
South Africa and Sub Sahara
Region:
Tel: +27 12 661 2025
08600 DLINK (for South Africa only)
Monday to Friday 8:30am to 9:00pm South
Africa Time
Web: http://www.d-link.co.za
E-mail: [email protected]
Saudi Arabia (KSA):
Tel: +966 01 217 0008
Fax: +966 01 217 0009
Saturday to Wednesday 9.30AM to 6.30PM
Thursdays 9.30AM to 2.00 PM
E-mail: [email protected]
D-Link Middle East - Dubai, U.A.E.
Plot No. S31102,
Jebel Ali Free Zone South,
P.O.Box 18224, Dubai, U.A.E.
Tel: +971-4-8809022
Fax: +971-4-8809066 / 8809069
Technical Support: +971-4-8809033
General Inquiries: [email protected]
Egypt
1, Makram Ebeid Street - City Lights Building
Nasrcity - Cairo, Egypt
Floor 6, ofce C2
Tel.: +2 02 26718375 - +2 02 26717280
Technical Support: +2 02 26738470
General Inquiries: [email protected]
Kingdom of Saudi Arabia
Ofce # 84 ,
Al Khaleej Building ( Mujamathu Al-Khaleej)
Opp. King Fahd Road, Olaya
Riyadh - Saudi Arabia
Tel: +966 1 217 0008
Technical Support:
+966 1 2170009 / +966 2 6522951
General Inquiries: [email protected]
Pakistan
Islamabad Ofce:
61-A, Jinnah Avenue, Blue Area,
Suite # 11, EBC, Saudi Pak Tower,
Islamabad - Pakistan
Tel.: +92-51-2800397, 2800398
Fax: +92-51-2800399
Karachi Ofce:
D-147/1, KDA Scheme # 1,
Opposite Mudassir Park, Karsaz Road,
Karachi – Pakistan
Phone: +92-21-34548158, 34326649
Fax: +92-21-4375727
Technical Support: +92-21-34548310, 34305069
General Inquiries: [email protected]
You can nd software updates and user documentation on the D-Link website.
Tech Support for customers in
7
DWR-161
ENGLISH
TECHNICAL SUPPORT
Iran
Unit 5, 5th Floor, No. 20, 17th Alley , Bokharest
St., Argentine Sq.,
Tehran IRAN
Postal Code : 1513833817
Tel: +98-21-88880918,19
+98-21-88706653,54
General Inquiries: [email protected]
Morocco
M.I.T.C
Route de Nouaceur angle RS et CT 1029
Bureau N° 312 ET 337
Casablanca, Maroc
Phone : +212 663 72 73 24
Lebanon RMA center
Dbayeh/Lebanon
PO Box:901589
Tel: +961 4 54 49 71 Ext:14
Fax: +961 4 54 49 71 Ext:12
Email: [email protected]
Bahrain
Technical Support: +973 1 3332904
Kuwait:
Technical Support: + 965 22453939 /
+965 22453949
Türkiye Merkez İrtibat Ofisi
Ayazağa Maslak yolu
Erdebil Cevahir İş Merkezi No: 5/A Ayazağa /
Maslak İstanbul
Tel: +90 212 2895659
Ücretsiz Müşteri Destek Hattı: 0 800 211 00 65
Web:www.dlink.com.tr
073-796-2797
Ver. 1.00(AU) 2012/03/15 11500Y20JX003A1A1
WIRELESS NETWORK REMINDER
Wireless Network Name (SSID)
Wireless Network Password
