Dacor EORS127 Manuale tecnico
PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Specifications are subject to change without notice.
See installation instructions for additional details. 1.3
27”, 30”, 36” Wide, Single,
Renaissance Wall Ovens
EOR, MOR
1/2
Revised
01/28/08
All tolerances: +1/6”, -0, (+1.6mm, -0) unless otherwise stated
Model
Number
Overall
Width (A)
Chassis
Width (B)*
Overall
Height (C)
Chassis
Height (D)
EORS127/
MORS127
26 7/8”
(68.3 cm)
25 3/8”
(64.5 cm) 28 7/16”
(72.2 cm)
26 7/16”
(67.2 cm)
EORS130/
MORS130
29 7/8”
(75.9 cm)
28 3/8”
(72.1 cm)
EORS136 35 7/8”
(91.1 cm)
34 3/8”
(87.3 cm)
28 5/8”
(72.7 cm)
26 5/8”
(67.6 cm)
X = Number of convection ovens
* Width at light covers on sides
Utility Cutout
Width (E)
Utility Cutout
Height (F)
Utility Cutout
Depth (G)
Control
Panel Depth
(H)
Notch Depth
(J)
Chassis
Depth (K)
Notch Height
(L)
All Models 5”
(12.7 cm)
5 ¼”
(13.3 cm)
6”
(15.2 cm)
1”
(2.54 cm)
1 1/8”
(2.9 cm)
24”
(61.0 cm)
1 1/8”
(2.9 cm)
21 1/8”
3 3/8”
(8.6 cm)
1”
(2.5 cm)
1”
(2.5 cm)
EPICURE MILLENNIA -
HANDLE IS INTEGRAL
Model Number Dedicated Circuit
Requirements* Total Connected Load
EORS127
240 Vac 60 Hz,
30 Amp.
5.0 kW
(20.8 Amp.)
MORS127
EORS130
MORS130
EORS136
* The above specifications are for reference only. See the
appliance data plate for exact specifications.
C
H
B
G
F
E
A
Side View
Control Panel
Front
Conduit:
60” (152 cm)
Long
J
K
L
D
* Width at light
covers on sides
Light cover
Utility Cutout
PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Specifications are subject to change without notice.
See installation instructions for additional details. 1.4
27”, 30”, 36” Wide, Single,
Renaissance Wall Ovens
EOR, MOR
Revised
01/28/08 2/2
1 1/2”
(3.8 cm)
Typical Counter
1“ (2.5 cm) min.
to combustible floor
3/4” (1.9 cm)
Support Platform
1“ (25mm) min. to combustibles
Recommended
Electrical
Location
4” Typical Toe Kick
36”
(91.4 cm) “N”
“P”
SINGLE WALL OVEN - INSTALLED UNDER COUNTER
Recommended
Electrical
Location
Alternate
Electrical
Location
4” Typical Toe Kick
“M”
“N”
“P”
3/4” (1.9 cm)
Support Platform
31 1/4” (79.4 cm)
Recommended
1” (2.5 cm) min.
to bottom of
cabinet door
1” (2.5 cm) min.
to top of
cabinet door
SINGLE WALL OVEN - CUT OUT DIMENSIONS
Model
Number
Minimum
Cabinet
Width (M)
Minimum Cut
Out Width (N)
Minimum Cut
out Height
(P)
EORS127/
MORS127
27”
(68.6 cm)
25 ½”
(64.8 cm) 27 3/8” (69.5
cm)
EORS130/
MOCS130
30”
(76.2 cm)
28 ½”
(72.4 cm))
EORS136 36”
(91.4 cm)
34 ½”
(87.6 cm)
27 ¾”
(70.5 cm)
Minimum Interior Cabinet Depth:
24” (61.0 cm)
PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Specifications are subject to change without notice.
See installation instructions for additional details. 1.7
27”, 30”, 36” Wide, Double,
Renaissance Wall Ovens
EOR, MOR
1/2
C
H
B
G
F
E
A
J
K
L
Side View
Control Panel
Front
Conduit:
66” (168 cm)
Long
D
3 3/8”
(8.6 cm)
1”
(2.5 cm)
1”
(2.5 cm)
Revised
01/28/08
Model
Number
Overall
Width (A)
Chassis
Width (B)*
Overall
Height (C)
Chassis
Height (D)
EORX227/
MORX227
26 7/8”
(68.3 cm)
25 3/8”
(64.5 cm) 49 15/16”
(127.0 cm)
47 15/16”
(121.8 cm)
EORX230/
MORX230
29 7/8”
(75.9 cm)
28 3/8”
(72.1 cm)
X = Number of convection ovens
* Width at light covers on sides
Utility Cutout
Width (E)
Utility Cutout
Height (F)
Utility Cutout
Depth (G)
Control
Panel Depth
(H)
Notch Depth
(J)
Chassis
Depth (K)
Notch Height
(L)
All Models 5”
(12.7 cm)
5 ¼”
(13.3 cm)
6”
(15.2 cm)
1”
(2.54 cm)
1 1/8”
(2.9 cm)
24”
(61.0 cm)
1 1/8”
(2.9 cm)
Model Number Dedicated Circuit
Requirements* Total Connected Load
EORS227
240 Vac 60 Hz,
50 Amp.
10.0 kW
(41.7 Amp.)
EORD227
MORS227
MORD227
EORS230
EORD230
MOCS230
MOCD230
* The above specifications are for reference only. See the
appliance data plate for exact specifications.
Light cover
21 1/8”
EPICURE MILLENNIA -
HANDLE IS INTEGRAL
Utility Cutout
PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Specifications are subject to change without notice.
See installation instructions for additional details. 1.8
27”, 30”, 36” Wide, Double,
Renaissance Wall Ovens
EOR, MOR
2/2
4” Typical Toe Kick
Recommended
Electrical
Location
“M”
“N”
“P”
3/4” (1.9 cm)
Support Platform
1” (2.5 cm) min.
to bottom of
cabinet door
1” (2.5 cm) min.
to top of
drawer face
9 5/8” (24.4 cm)
Recommended
Double Wall Oven - Cut Out Dimensions
Model
Number
Minimum
Cabinet
Width (M)
Minimum Cut
Out Width (N)
Minimum Cut
out Height
(P)
EORX227/
MORX227
27”
(68.6 cm)
25 ½”
(64.8 cm) 49 1/16”
(124.6 cm)
EORX230/
MORX230
30”
(76.2 cm)
28 ½”
(72.4 cm)
X = Number of convection ovens
Revised
01/04/08
