DAEWOO ELECTRONICS DWC-084R Manuale utente
CONTENTS
1. Specifications................................................................................................2
2. Operation.....................................................................................................3
3. Wiring Diagram..........................................................................................10
4. Refrigerant Cycle.........................................................................................11
5. Control Block Diagram.................................................................................12
6. Circuit Diagram..........................................................................................13
7. Trouble Shooting..........................................................................................16
8. Key Components of Electronic Circuit............................................................26
9. Disassembly Instructions ...............................................................................28
10. Exploded Diagram and Parts List...................................................................30
Contents
1
2
1. SPECIFICATIONS
MODEL
ITEM
Function
Power source
Cooling Capacity
Energy Efficiency
Ratio
Dehumidification
Electrical Data
Compressor
Fan Motor
Refrigerant (R-22)
Dimensions
Weight
DWC-064R
6,710
1,691
10.70
2.70
2.13
970
627
5.5
RM5465GQ87
40µF/370VAC
A9525HS601-1
4µF/370VAC
14.46oz(410g)
62.8 lbs(28.5Kg)
66.2 lbs(30.0Kg)
DWC-084R
7,800
1,966
10.80
2.72
2.68
1,220
723
6.5
RM5475GQ87
45µF/370VAC
A9525HS602
7µF/370VAC
16.58oz(470g)
65.1 lbs(29.5Kg)
68.4 lbs(31Kg)
Btu/h
Kcal/h
Btu/Wh
Kcal/Wh
Pts/h
g/h
Power Input (W)
Running Current (A)
Type
Model
Capacitor
Model
Capacitor
Indoor-Fan
Outdoor-Fan
Control
Charge Amount(g)
Unit (WxHxD)
Packing (WxHxD)
Net Weight
Gross Weight
Cooling only
AC 115 V, 60 Hz
ROTARY
Blower-Fan
Propeller-Fan
Capillary
18.9(W)x14.6(H)x19.5(D) Inch (480(W)x369(H)x497(D) mm)
21.1(W)x17.6(H)x21.9(D) Inch (535(W)x446(H)x556(D) mm)
3
1
PARTS OF NAME AND FUNCTION
2. OPERATION
● DWC-064R / DWC-084R
NO PART NAME
1 CABINET
2 BLADE VERTICAL
3 BLADE HORIZONTAL
4 KNOB BLADE
5 GRILLE FRONT
6 INLET GRILLE
NO PART NAME
7 AIR FILTER
8 PANEL CONTROL
9 FRAME GUIDE TOP
10 FRAME WINDOW KIT
11 SHUTTER WINDOW
12 REMOTE CONTROLLER
9
2
4
0
q
8
7
7
1
1
5
5
6
2
4
8
3
3
6
w
4
2
REMOTE CONTROLLER
REMOTE SIGNAL TRANSMITTER
TIMER/CANCEL
• Everytime you push this button,
timer is set as follow.
(1Hr→2Hr→3Hr→4Hr→5Hr→6Hr
→8Hr→10Hr→12Hr→16Hr→20Hr
→24Hr→CANCEL).
After the unit is timed, if this
button is pushed, timer is
canceled.
SLEEP
• SLEEP mode is selected as
follow. (L1→L2→Cancel)
MODE
• Everytime you push this
button, it is selected as
follow.
(COOLING→TURBO→FAN
→COOLING)
ENERGY SAVE
(COOLING MODE ONLY)
• Whenever you push this
button, the cumulative power
consumption is decreased.
TEMPERATURE
• It is the button to set the room in
the desired room temp.
The temp. can be set within a
range from 16°C (60°F) to 32°C
(90°F) by 1°C (1°F)
POWER ON/OFF
• To turn the unit ON, push this
button. To turn the unit OFF,
push this button, again.
FAN SPEED
• Everytime you push this button,
it is selected as follow.
(High→Low→High)
TIMER/
CANCEL
FAN SPEED
TEMP
SLEEP
MODE
ENERGY
SAVE
5
3
REMOTE CONTROLLER DISPLAY
TEMP./TIMER DISPLAY
• It displays the temperature
and the timer.
MODE DISPLAY
• It displays the
operating mode.
REMOTE SIGNAL
RECEIVER
TEMPERATURE SET
• It is the button to set the
desired room temperature.
The temperature can be set
within a range from 16°C
(60°F) to 32°C (90°F) by
1°C (1°F)
POWER ON/OFF SWITCH
• To turn the unit ON, push
this button.
To turn the unit OFF, push
this button again.
MODE SELECT
• Everytime you push this
button, It is selected as
follow. (COOLING→TURBO
→ FAN→COOLING)
FAN SPEED
• Everytime you push this
button, It is selected as
follow. (High→Low→High)
ENERGY SAVE
• Whenever you push this
button, the cumulative power
consumption is decreased.
(Cooling mode only)
Room Air-conditioner
ROOM TEMP DESIRED TEMP
TEMP
MODE
FAN
SPEED
POWER
ENERGY
SAVE
FAN
TURBO
COOLING
TIMER
ENERGY
SAVE
Replacing Batteries
6
Remove the COVER from
the back of the remote
controller.
•Slide the cover
according to the arrow
direction
Insert two battaries.
•Be sure that the (+) and
(–) directions are correct
•Be sure that both batteries
are new
Re-attach the cover.
•Slide it back into position
•Do not use rechargeable batteries such batteries differ from standard dry cells in shape,
dimensions and performance.
•Remove the batteries from the remote controller if the air conditioner is not going to be used for
an extended length of time.
1 2 3
–+
–+
7
If you set time in OFF-Timer Mode, the unit will stop at the set time.
If you set time in ON-Timer Mode, the unit will run at the set time.
(1) Range of setting temperature: 16~32°C
(2) Setting temperature: Operating temperature of compressor
If the Unit Display receive the signal of Remote Controller, you can hear the signal "beep –" or "beep, beep".
OFF-Timer
4
DESCRIPTION OF FUNCTIONS
Unit ON
Unit OFF
SET Time HOUR
ON
OFF
ON-Timer
Unit ON
Unit OFF
SET Time HOUR
ON
OFF
Control of Room Temperature
Buzzer
COMP (ON)
(COOLING)
Desired temperature
COMP (OFF)
-1˚CTemperature
*Room temperatrue
< setting temperature
Compressor OFF
Room temperature
> setting temperafure
Compressor ON
(
(
8
(1) When you are going to sleep, select sleep button in remocon and the unit controls the room to the desired
temperature. (The unit will not operate after 4 hour)
(2) For changing the temperature.
• Mode I (L1)
•The unit will not operate after 4 hour.
• Mode II (L2)
•The unit will not operate perfectly after 10 hour.
(3) To cancel sleep mode, press the SLEEP button again or press the MODE button once. : the SLEEP indicator will
disappear in the display.
In normal operation, there is a time delay of three minutes between turn off and turning back on including
initial power up.
Sleep Mode
3min. Time Delay of Compressor
0 0.5 1.0 HOUR
SET TIME
Desired
Difference
desired temperature
between room
temperature (°C) 0.5°C0.5°C0.5°C
Temperature
Fan Speed
(1) Motor speed (high speed, low speed).
(2) Remote controller setting fan speed. (H, L)
(3) Relation of operating mode between fan speed.
FAN ONLY COOL TURBO
HHHH
LLL-
2hr 2hr 2hr 2hr 2hr
Desired
+1˚CTemperature
+1˚C
SET ON
SET OFF
1°C
1°C
1°C
9
Energy Save
1. ENERGY SAVE is operated while cooling Mode only.
2
. Desired temperature is changed as follows by pushing ‘ENERGY SAVE’button.
3. When the ‘ENERGY SAVE’button is pushed, the fan speed goes to ‘Low’
4. When the ‘ENERGY SAVE’function is canceled by pushing ‘ENERGY SAVE’button once again, the desired temperature is
return to the former desired temperature.
(1) Cooling Condition
1Fan Speed: High speed
2Set temperature:16˚C(Fixed)
3Compressor and Fan
Turbo Mode(Powerful Cooling)
-1
OFF ON
(Room temperature-18˚C)
01
Self-Diagnostic Function
The control will contain diagnostic test to verify the integrity of the system.
(1)Error Code Display
ERROR CODE 88 LED DISPLAY ERROR CONTENTS
1 Room air thermistor short or open.
hr
‘ENERGY SAVE’
ON ‘ENERGY SAVE’
OFF
1hr
+1°C+1°C-2°C
10
3. WIRING DIAGRAM
