PLASMA DISPLAY

USER’S MANUAL

DAEWOO ELECTRONICS CO., LTD.

DP-42GM

DP-42SM

DP-42WM

Proper use guarantees

product life.

Before using the product, be advised

that you read this owner’s manual well

and try to operate it.

- Product Warranty is included -

This Owner’s Manual presents safety precautions and how to use the product.

After reading it thoroughly, use the product safely.

Keep this manual where the user can see it easily.

Failure to comply with warnings and cautions for the safe use of electric

appliances may cause ﬁre or human injury.

•42”super-wide, 3.15”Ultra Slim Wall-mounting Monitor

DAEWOO PLASMA opens new TV era with advanced plasma technology – 3.15 inches ultra slim Monitor.

Light weight of only 66Lbs allows installing in narrow space.

• DVD Direct Connection / Outstanding Picture Quality Digital

Broadcasts Receive (SD Grade)

DVD can be directly connected to the unit so that you can view clear digital images. You can enjoy even

high quality images. by connecting digital broadcasting receiver with which digital broadcasts can be

viewed.

•

PC Direct Connection

PC can be connected to the PDP without a separate device, and can be used as a monitor so that the

effect of presentation gets maximized, making it more popular in various events and exhibitions.

•

PDP Monitor with Minimized Noise

Although PDP Monitor had an outstanding picture quality, there was a problem with the noise caused by

cooling fan until now. DAEWOO PLASMA does not need cooling fan any more since it adopts self air

circulation method with excellent heat transfer, eliminating the fan noise.

•

160º Wide-Angle Viewing Area

•

Flat Panel with No Distortion and Color Blurring

Since Plasma TV has no problems such as distortion, blurring, ﬂickering unlike existing CRT type,

you can enjoy Home Theater with super speaker.

•

Various Video Control

- 11 Languages OSD - 20 Step screen zooming function - Full-screen still function

- Various aspect ratio (16:9, Panorama, Normal, Enlarge LB, Enlarge LBS)

•

3 Way 6 Speaker Stereo Sound System

•

Worldwide : NTSC, PAL, SECAM / Free Volt (100-240V 50/60Hz)

Features

FCC RF INTERFERENCE ST

FCC RF INTERFERENCE STA

ATEMENT

TEMENT

NOTE :

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of

the following measures.

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio, TV technical for help.

- Only shielded interface cable should be used.

Finally, any changes or modifications to the equipment by the user not

expressly approved by the grantee or manufacturer could void the users

authority to operate such equipment,

Always obey all

safety messages.

•All the safety and

operating

instructions should

be read before the

product is operated.

If anything strange

happens, unplug

this product from

the wall outlet.

•Do not disassemble

or replace any parts

of the monitor.

Refer to a qualiﬁed

service personnel

for fepair.

Safety Precautions

WARNING

You can be killed

or seriously

injured if you do

not follow

instructions.

During a lightning storm, or when it is left

unattended and unused for a long period

of time, unplug it from the wall outlet.

It can result in ﬁre.

When unplugging your monitor, always

grip plug ﬁrmly and pull straight out from

the receptacle.

It can result in ﬁre or electric shock due to

damaged power cord.

This product must be properly grounded.

• Improper grounding may cause malfunction or

electric shock.

• When proper grounding is not possible, install

circuit breaker.

• Do not ground to gas pipe, water pipe, lightning

rod, and telephone line.

During a lightning storm, unplug the

monitor from the wall outlet, and do not

touch the antenna.

It can cause ﬁre or electric shock.

Power

Installation

Do not use this product in the

neighborhood of a bath or shower.

It can result in electric shock or ﬁre.

Do not place this monitor on an unstable

cart, stand, or table

It may cause the product and cart to overturn,

damaging equipment or causing possible injury.

While Using Monitor

Do not open cover (or back) because

high voltage is present within the

monitor’s enclosure.

It may cause electric shock.

Never push objects of any kind into

this product through openings at the

back of monitor.

It may cause ﬁre or electric shock.

No objects ﬁlled with liquids, such as

vases, shall be placed on the monitor.

Spilled liquids may cause electric shock or

ﬁre.

Do not allow children to play or hang

on the monitor.

These actions may tip it over, causing

personal injury.

Do not place candle or lighted

cigarette on the monitor.

If these fall into the inside of the monitor, it

may cause ﬁre or explosion.

Do not disassemble batteries, and

do not allow children to swallow

them.

Heavy metal may contaminate environment,

and can be harmful or detrimental to human

health. (When children swallow the

batteries, go to hospital and consult with a

doctor.)

Do not pray water to the monitor or

wipe with damp cloth.

It may cause electric shock or ﬁre.

Unplug the monitor from the wall

outlet when smoke or strange smell

occurs, then refer servicing to a

service personnel.

In the case of continuous use, it may cause

ﬁre or electric shock.

Always obey all

safety messages.

• All the safety and

operating instructions

should be read before

the product is

operated.

Safety Precautions

Power

Installation

CAUTION

You can be injured

or this product or

any other your

property can be

damaged if you

don’t follow

instructions.

When moving your monitor, remove the

power plug, antenna, and cables, and be

sure to move it by more than two people..

Failure to follow this instruction can result in

electric shock or personal injury.

Do not touch the power plug with wet

hands when plugging or unplugging.

It can result in a risk of electric shock.

Do not install the product where it will be exposed to

the direct sunlight, and the product should not be

near heat sources such as radiators, stoves, etc.

It may cause malfunction.

Do not install where there is oil, smog,

moist, and dust

It may cause malfunction.

For proper ventilation, separate the product

from the wall, and keep a distance of more

than 4”.

Due to the increase of temperature inside the

Monitor, it may cause ﬁre.

Do not place the monitor where

ventilation is not ensured.

Due to the increase of temperature inside the

Monitor, it may cause ﬁre.

If you wish to install this product on the

wall or ceiling, refer to the professional.

Failure to do so may cause damage to product

and injury to human.

When using an outside antenna system, do not

install it in the vicinity of overhead power lines.

When antenna touches such power lines, it may

cause electric shock.

During Use

CAUTION

You can be injured or this

product or any other your

property can be damaged if

you do not follow

instructions.

Do not wipe the monitor using a

cloth damped with chemicals

(benzene, thinner, etc.).

Monitor appearance may be marred.

(Unplug the power plug and wipe with soft

cloth.)

Do not place the monitor near

magnetic, speakers, or telephones.

It can cause a change in the color tone of

the screen.

Do not place any object or cover on

the monitor.

In an event of improper ventilation, the

monitor will be overheated causing ﬁre.

Do not place heavy objects or heat

sources on the power cord.

It may damage the power cord, causing ﬁre

or electric shock.

When watching the TV, the distance

between the Monitor screen and

your eye should be as 5~7 times as

the diagonal distance of the Monitor.

Watching the TV for a long time may hurt

your eye sight.

When cleaning of the inside of the

monitor is required, consult to the

qualiﬁed service personnel.

When the monitor is not cleaned for a long

period of time, dust in it may cause ﬁre or

malfunction.

When the monitor is placed on a cart

or table, the front side of the Monitor

should not project outward.

Unbalance may cause the monitor to drop,

resulting in personal injury or equipment

malfunction and damage.

Do not grip speakers when moving

the monitor attached with speakers.

When moving the monitor while gripping

speakers, speakers may be fallea away

from the monitor due to its weight, causing

personal injury.

INPUT

SELECTPOWER

DISPLAY

ZOOM


MODESCREEN

MODE

FREEZE

MUTE

SOUND

MODESLEEP

ZOOM+

VOL VOL

Remote Control

1UNIT

Batteries (AAA)

2UNITS

AC Cable

1UNIT

PC(15pin) Cable

1UNIT

A/V Cable

2UNITS

Audio Cable

1UNIT

Note

Check to be sure that the following items are

packed with your Monitor.

Checking Accessories

Supplied Accessories

Note

The following items are optional accessories.

Refer purchasing optional accessories from

Daewoo Electronics Local Dealer or the dealer

from where you purchased the unit.

Optional Accessories

DSP-SP20/SP21/SP22

Speaker Main Unit

Dimension : 3.94(W) x 24.72(H) 3.27(D)inch

Including Speaker Stand

Dimension : 6.69(W) x 28.7(H) x 7.64(D)inch

Audio Ampliﬁer : 8W + 8W

Impedance : 8Ω

Weight : 16.53Lbs

DSP-ST20/ST21/ST22

Dimension : 26.26(W) x 9.37(H) x

12.60(D)inch

Weight : 15.43Lbs

DSP-HG10

•

Variable Angles : 0º, 10º, 15º, 20º

Speaker Main Unit

•

Dimension : 23.66(W) x 23.31(H) x

1.38(D)inch

Including Stand

•

Weight : 9.92Lbs.

Wall Mounting Unit

Table Top Stand

Speakers

Altri manuali per DP-42GM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Daewoo Monitor

Daewoo

Daewoo 2708ED Manuale utente

Daewoo

Daewoo DPP-42A2(GDBD) Manuale utente

Daewoo

Daewoo 532X Manuale utente

Daewoo

Daewoo 712B Manuale utente

Daewoo

Daewoo 715B Manuale utente

Daewoo

Daewoo DT-4242N Manuale utente

Daewoo

Daewoo DSC-34W70N Manuale utente

Daewoo

Daewoo HL510S Manuale di servizio

Daewoo

Daewoo L510B Manuale utente

Daewoo

Daewoo HL900S Manuale di servizio

Daewoo

Daewoo DSP-4280GM Manuale utente

Daewoo

Daewoo DP-50GM Manuale utente

Daewoo

Daewoo 531B Manuale utente

Daewoo

Daewoo DTQ-3062SC Manuale utente

Daewoo

Daewoo DPM-42A1LBSB Manuale utente

Daewoo

Daewoo DPC-7200N Manuale utente

Daewoo

Daewoo DT- 4280NH Manuale utente

Daewoo

Daewoo 710C Manuale utente

Daewoo

Daewoo DSP-5014LX Manuale utente

Daewoo

Daewoo 531X-3 Manuale utente

Daewoo

Daewoo HL510S Manuale utente

Daewoo

Daewoo L700C Manuale utente

Daewoo

Daewoo 712D Manuale utente

Daewoo

Daewoo DPP-4270NHS Manuale utente

Manuali Monitor popolari di altre marche

Linear Acoustic

Linear Acoustic LQ-1000 Manuale utente

AOC

AOC I2579V Manuale utente

Gateway

Gateway FPD1520 Manuale utente

Furuno

Furuno Mu 120c Manuale utente

Asus

Asus VB171D - 17" LCD Monitor Manuale utente

Dell

Dell S2230MX Istruzioni utente

Philips

Philips 107C64 Manuale utente

Dell

Dell S2409WFP Manuale utente

EverFocus

EverFocus EN-7517E Manuale utente

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuale utente

Dell

Dell Precision 7680 Manuale di istruzioni

LG 50PM1M - - 50" Plasma Panel Manuale utente

Bosch

Bosch DDU 9 Manuale utente

Acer

Acer A231HL Manuale utente

Philips

Philips 86BDL4152T Manuale utente

NEC

NEC AccuSync LCD5V Manuale utente

Emay

Emay SleepO2 Manuale utente

IBM

IBM 6360 Istruzioni per l'installazione
