Dahua Technology A83AR6 Manuale utente
4K HDCVI Fisheye Camera
A83AR6
Quick Start Guide
Version 001.001
Dahua Technology USA Inc.
Table of Contents
1Welcome .......................................................................................................................... 1
1.1Important Safeguards and Warnings .................................................................. 1
Electrical safety ................................................................................................... 1
Environmental Precautions ................................................................................. 2
Operation and Daily Maintenance ...................................................................... 3
Lifting Appliance Requirement ............................................................................ 3
Warnings ............................................................................................................. 3
1.2FCC Information .................................................................................................. 4
FCC compliance： .............................................................................................. 4
1.3Legal Notices ...................................................................................................... 4
Copyright ............................................................................................................. 4
Trademarks ......................................................................................................... 4
1.4Disclaimer ........................................................................................................... 5
2Unpacking ........................................................................................................................ 6
2.1Parts List ............................................................................................................. 6
3Installation and Configuration .......................................................................................... 7
3.1Composite Cable Connections ........................................................................... 7
Cable Connections.............................................................................................. 7
Alarm I/O Port Configuration ............................................................................... 8
3.2Framework and Dimensions ............................................................................... 8
3.3Alarm Setup ........................................................................................................ 9
Alarm Input .......................................................................................................... 9
Alarm Output ....................................................................................................... 9
4Device Installation ......................................................................................................... 10
4.1Installing a Micro SD Card ................................................................................ 11
4.2Mounting the Camera ....................................................................................... 11
5Network Configuration ................................................................................................... 13
5.1Network Protocols ............................................................................................. 13
5.2Modifying the IP Address .................................................................................. 14
5.3Using the ConfigTool ........................................................................................ 14
5.4Accessing the Web Interface ............................................................................ 15
5.5Configuring Alarms ........................................................................................... 16
5.6Configuring Local SD Card Recording ............................................................. 17
1
1 Welcome
This manual offers reference material and general information about the basic operation,
maintenance, and troubleshooting of the Dahua Multi-Sensor Panoramic Camera. Read, follow, and
retain the following safety instructions. Heed all warning on the unit and in the operating instructions
before operating the unit. Keep this guide for future reference.
1.1 Important Safeguards and Warnings
Electrical safety
Install the unit in accordance with the manufacturer’s instructions and in accordance with
applicable local codes.
All installation and operation must conform to your local electrical safety codes.
Do not overload outlets and extension cords, which may cause fire or electrical shock.
Do not place the camera near or in a place where the camera may contact overhead power lines,
power circuits, or electrical lights.
Ensure power conforms to SELV (Safety Extra Low Voltage) and that the limited power source is
rated 24 VDC as specified in IEC60950-1. (Power supply requirement is subject to the device
label).
All input/output ports are SELV circuits. Ensure that SELV circuits are connected only to other
SELV circuits.
Ground the unit using the ground connection of the power supply to protect the unit from damage,
especially in damp environments.
Protect the plug and power cord from foot traffic, being pinched, and its exit from the unit.
Units with or without an ON/OFF switch have power supplied to the unit whenever the power
cord is inserted into the power source; however, the unit is operational only when the ON/OFF
switch is in the ON position. The power cord is the main power disconnect device for switching
off the voltage for all units.
Operate the unit only from the type of power source indicated on the label. Before proceeding,
disconnect the power from the cable to be installed into the unit.
For external power supplied units, use only the recommended or approved power supplies.
Limited power sources must comply with EN 60950. Substitutions may damage the unit or
cause fire or shock.
For 24 VAC units, voltage applied to the unit’s input power should not exceed ±25%. User-
supplied wiring must comply with local codes (Class 2 power levels). Do not ground the
supply at the terminals or at the unit’s power supply terminal.
Contact the local dealer or the power company to verify the correct power supply.
Do not supply power via the Ethernet connection (PoE) when power is already supplied via the
power connector.
Do not attempt to service the unit. Opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified personnel.
2
If the unit is damaged and requires service, unplug the unit from the main AC power supply and
from the PoE supply and refer to qualified service personnel. Damage may include, but is not
limited to:
The power supply cord or plug is damaged.
Liquid has spilled in or on the unit.
An object has fallen on the unit.
The unit has been dropped and the housing is damaged.
The unit displays a marked change in performance.
The unit does not operate in the expected manner when the user correctly follows the proper
operating procedures.
Ensure a service technician uses replacement parts specified by the manufacturer, or that have
the same characteristics as the original parts. Unauthorized parts may cause fire, electrical
shock, or other hazards. Dahua is not liable for any damage or harm caused by unauthorized
modifications or repairs.
Perform safety checks after completion of service or repairs to the unit.
Use attachments and accessories only specified by the manufacturer. Any change or
modification of the equipment, not expressly approved by Dahua, could void the warranty.
Incorporate a readily accessible disconnect device in the building installation wiring for quick
power disconnect to the camera.
Dahua assumes no liability or responsibility for any fire or electrical shock caused by improper
handling or installation.
Environmental Precautions
Do not aim the unit at a strong light source or into direct sunlight to focus. A strong light source
may cause overexposure and may affect the longevity of the CCD or the CMOS sensor.
Transport, use, and store the unit within the specified temperature and humidity range.
Do not place the unit in a wet, dusty, extremely hot or an extremely cold environment; and avoid
environments with strong electromagnetic radiation or unstable lighting.
Never push objects of any kind into this unit through openings as they may touch dangerous
voltage points or cause a short circuit that may result in fire or electrical shock. Take care to not
spill any liquid on the unit.
Do not use units intended for indoor applications near water, in damp or wet environments, or in
any area classified as a wet location. Do not expose an indoor unit to rain or moisture to reduce
the risk of fire or electric shock.
Do not block or cover any openings in the unit enclosure. These openings are provided for
ventilation to prevent overheating and to ensure reliable operation. Ensure the unit is placed in
an area with adequate ventilation.
Do not place the unit near a heat source such as heaters, stoves, radiators or other equipment
that produces heat.
Pack the unit with standard factory packaging or material of the same quality when transporting
the unit.
Take care to avoid heavy stress, violent vibration, or water spills to the camera unit during
transportation, storage, and installation.
3
Operation and Daily Maintenance
Do not touch the heat dissipation component of the unit. This part of the unit is hot and may
cause a burn.
Do not open or dismantle the device; there are no components that a user can fix or replace.
Opening the unit may cause water leakage or expose components to direct light. Contact the
manufacturer or a qualified service representative to service the camera or to replace a
component, including the desiccant.
Dahua recommends the use of a thunder-proof device in concert with the unit.
Do not touch the CCD or the CMOS optic sensor. Use a blower to clean dust or dirt on the lens
surface. Use a dry cloth dampened with alcohol and gently wipe away any dust on the lens.
Use a dry soft cloth to clean the unit’s housing. If the unit is particularly dusty, use water to dilute
a mild detergent, apply the diluted detergent to a soft cloth, then gently clean the device. Finally,
use a dry cloth to wipe the unit dry. Do not use a volatile solvent like alcohol, benzene, or thinner;
or use a strong detergent with abrasives, which may damage the surface coating or reduce the
working performance of the unit.
Do not touch or wipe a dome cover during installation, this cover is an optical device. Refer to
the following methods clean the dome cover:
Stained with dirt: Use an oil-free soft brush or blower to gently remove the dirt.
Stained with grease or fingerprints: Use a soft cloth to wipe gently the water droplet or the oil
from the dome cover. Then, use an oil-free cotton cloth or paper soaked with alcohol or
detergent to clean the lens from the center of the dome to outside. Change the cloth several
times to ensure the dome cover is clean.
Lifting Appliance Requirement
Select the proper installation mode and use the proper lifting device to safely lift the camera at
the installation site.
Ensure that the lifting device has the proper capacity to reach the installation height.
Use the lifting device in accordance with its operating instructions and abide by the device’s
safety precautions.
Warnings
Change the default password after the initial login to protect the integrity of the network.
Use the standard accessories provided by the manufacturer and ensure the unit is installed and
commissioned by qualified professionals.
Protect the lens area from laser radiation when using a laser device to aid in installation and
leveling of the unit.
Do not supply power via the Ethernet connection (PoE) when power is already supplied via the
power connector.
4
1.2 FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference;
This device must accept any interference received, including interference that may cause
undesired operation.
FCC compliance：
This equipment has been tested and found to comply with the limits for a digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
1.3 Legal Notices
Copyright
This user guide is ©2017, Dahua Technology Company, LTD.
This user guide is the intellectual property of Dahua Technology Company, LTD and is protected by
copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
5
1.4 Disclaimer
This user guide has been compiled with great care and the information it contains has been
thoroughly reviewed and verified. The text was complete and correct at the time of printing. This
guide may be periodically updated to reflect changes to the product or to correct previous
information and the content of this guide can change without notice. If you encounter an error or
have any questions regarding the contents of this guide, contact customer service for the latest
documentation and supplementary information. Dahua accepts no liability for damage resulting
directly or indirectly from faults, incompleteness, or discrepancies between this guide and the
product described. Dahua is not liable for any loss caused by installation, operation, or
maintenance inconsistent with the information in this guide.
Video loss is inherent to all digital surveillance and recording devices; therefore Dahua cannot be
held liable for any damage that results from missing video information. To minimize the
occurrence of lost digital information, Dahua recommends multiple, redundant recording systems,
and adoption of backup procedure for all data.
Contact the supplier or customer service if you encounter any issue while using this unit.
6
2 Unpacking
This equipment should be unpacked and handled with care. If an item appears to have sustained
damage during shipping, notify the shipper immediately.
Verify that all the parts listed below are included. If an item is missing, contact customer support or
your local representative.
The original packing carton is the safest container to transport the unit, in the event the unit must be
returned for service. Retain the carton and all shipping material for future use.
Please refer to the enclosed CD for more details, to view the detailed User’s Manual, and for
configuration software.
2.1 Parts List
Package Item Quantity
HDCVI Fisheye Camera 1
Installation Hardware Pack 1
Expansion Bolts 3
ST3 Self-tapping Screws 3
Multi-purpose Tool 1
Ceiling Bracket 1
Quick Start Guide 1
Documentation CD 1
7
3 Installation and Configuration
3.1 Composite Cable Connections
The following figure depicts the type and location of each cable coming from the device. This image is
intended as a reference only.
Figure 3-1
Cable Connections
No. Port Name Function Connector Note
1 POWER Power input port - Power port. Input 12 VDC power.
Use power according to the device tag.
2 LAN Network port Ethernet
port
Connect to standard Ethernet cable.
Certain devices support Power over Ethernet.
Check the specific device to determine if the
device accepts PoE and use an appropriate
Ethernet cable and network to supply power.
3 AUDIO IN Audio input port RCA Audio in to receive an analog audio signal
from an external pickup.
4 AUDIO OUT Audio output
port RCA Audio out from the device to an external
speaker.
5 I/O I/O port -
Alarm signal input/output. Refer to Error!
Reference source not found. for more
details.
Table 3-1
8
Alarm I/O Port Configuration
Port Name SN Name Note
I/O Port
1 ALARM_OUT1 Alarm output port 1. Use to output the alarm signal to the
alarm device.
Note: ALARM_OUT1 can only be used with
ALARM_OUT_GND1.
2 ALARM_OUT_GND1
3 ALARM_IN1 Alarm input port 1. Use to receive the On/Off signal from
an external alarm source.
4 ALARM_IN2 Alarm input port 2. Use to receive the On/Off signal from
an external alarm source.
5 ALARM_IN_GND Alarm input ground port
6 ALARM_OUT2 Alarm output port 2. Use to output the alarm signal to the
alarm device.
Note: ALARM_OUT2 can only be used with
ALARM_OUT_GND2.
7 ALARM_OUT_GND2
Table 3-2
3.2 Framework and Dimensions
The following figures show the dimensions of the device in mm (in.). These images are intended
as a reference only.
Figure 3-2
Indice
Altri manuali Dahua Technology Telecamera di sicurezza
Dahua Technology
Dahua Technology IPC-HDW2431T-AS-S2 Manuale utente
Dahua Technology
Dahua Technology DH-IPC-HDW3441TP-ZS-S2 Manuale utente
Dahua Technology
Dahua Technology IPC-HFW7442H-Z-X Manuale utente
Dahua Technology
Dahua Technology PC-EBW81242 Manuale utente
Dahua Technology
Dahua Technology IPC-HUM4431S-L4 Manuale utente
Dahua Technology
Dahua Technology IPC-HDW2249TM-S-IL-0280B Manuale utente
Dahua Technology
Dahua Technology 8A840WANF Manuale utente
Dahua Technology
Dahua Technology IPC-HDW2241T-S-0280B Manuale utente
Dahua Technology
Dahua Technology DSS4004-S2 Istruzioni generali
Dahua Technology
Dahua Technology Lite IPCHFW2231T-ZAS-S2 Manuale utente
Dahua Technology
Dahua Technology HDW2831TM-AS-S2 Manuale utente
Dahua Technology
Dahua Technology IPC-PDB4830-B360 Manuale utente
Dahua Technology
Dahua Technology IPC-HFW2531T-ZS-S2 Manuale utente
Dahua Technology
Dahua Technology HD IR Mini Bullet Manuale utente
Dahua Technology
Dahua Technology D-IPC-HFW1430DSP-SAW-0280B Manuale utente
Dahua Technology
Dahua Technology DH-IPC-PDW3849-A180-AS-PV-ANZ Manuale utente
Dahua Technology
Dahua Technology IPC-HFW5449T1-ASE-D2-0360B Manuale utente
Dahua Technology
Dahua Technology IPC-HFW1230S1-0280B-S5 Manuale utente
Dahua Technology
Dahua Technology N28BL7Z Manuale utente
Dahua Technology
Dahua Technology 50430UN Manuale utente
