Dahua C Series Wi-Fi Camera Quick Start Guide

Dahua C Series Wi-Fi Camera

Quick Start Guide

Version 1.0.0

ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Dahua C Series Wi-Fi Camera Quick Start Guide

2

1 Packing List

Device ×1 QSG ×1

Power Adapter ×1 Screw Package ×1

Quick Installation Board ×1USB ×1

Dahua C Series Wi-Fi Camera Quick Start Guide

3

Installation Position Map ×1

Dahua C Series Wi-Fi Camera Quick Start Guide

4

2 Product Appearance

Figure 2-1

Figure 2-2

Dahua C Series Wi-Fi Camera Quick Start Guide

5

Figure 2-3

Please refer to the following table for more details about each port.

Table 2-1

Note

For reset, long press for 10 seconds and then the light off; For WPS (Wi-Fi Protected

Setup), one quick press.

Please refer to the following table for more details about status of indicator light.

Table 2-2

No.

Component Name

1

Lens

2

MIC

3

Indicator light

4

SD card slot

5

Speaker

6

Reset/ WPS (Wi-Fi–Protected Setup) button

7

USB port

Indicator light status

Device status

Red light stably on

Booting.

Green light slow flashing

Booting completed, await Wi-Fi config, and enter smart

config status.

Green light quick flashing

Wi-Fi smart config in progress, including WPS (Wi-Fi

Protected Setup), management frame, etc.

Green light stably on

Wi-Fi connection succeeded, operate normally.

Red and green lights flash

alternately

Device upgrade.

Red light slow flashing

Network disconnection.

Red light quick flashing

Device fails to boot up; SD card does not work.

Dahua C Series Wi-Fi Camera Quick Start Guide

6

3 Operation by Easy4ip App

Step 1 Power on your camera with power adapter.

Step 2 Connect your smartphone to your Wi-Fi network, scan “Easy4ip” QR on the

packing box, download and install “Easy4ip” APP.

Step 3 Open Easy4ipAPP (take iOS version as an example), see Figure 3-1. Please

register an account for first use.

Figure 3-1

Step 4 Please tap “+”to add new devices after you login your account.

Dahua C Series Wi-Fi Camera Quick Start Guide

7

Figure 3-2

Step 5 Scan the QR code on the back of the camera to get the SN, you can also tap

"Manually enter the SN" and manually input the SN number on the next page.

Then tap "Next".

Dahua C Series Wi-Fi Camera Quick Start Guide

8

Figure 3-3

Step 6 Make sure your smartphone is connected to the same Wi-Fi, then tap "Next'.

Figure 3-4

Step 7 Fill in the password of your Wi-Fi, then tap "Next".

Dahua C Series Wi-Fi Camera Quick Start Guide

9

Figure 3-5

Step 8 Input your device password, the default password is "admin".

Figure 3-6

Step 9 Your camera is successfully added. You can set up your time zone and start

preview.

Dahua C Series Wi-Fi Camera Quick Start Guide

10

Figure 3-7

Note

If you have more cameras, please follow step 4-9 to add them one by one.

If you want to change the Wi-Fi signal, please reset the camera to factory default and

repeat step 4-9 to add the device.
