Daikin EKRTWA Manuale utente

OPERATION MANUAL

Operation manual

Room thermostat English

Bedienungsanleitung

Raumthermostat Deutsch

Manuel d'utilisation

Thermostat d'ambiance Français

Gebruiksaanwijzing

Kamerthermostaat Nederlands

Manual de operación

Termostato de la habitación Español

Manuale d'uso

Termostato ambiente Italiano

∂Á¯ÂÈÚ›‰ÈÔ ÏÂÈÙÔ˘ÚÁ›·˜

£ÂÚÌÔÛÙ¿ÙË˜ ‰ˆÌ·Ù›Ô˘ EÏÏËÓÈÎ¿

Manual de operações

Termóstato de ambiente Portugues

Användarhandbok

Rumstermostat Svenska

Driftshåndbok

Romtermostat Norsk

EKRTWA

Room thermostat

1D_OM_4PW56102-1.book Page 1 Thursday, August 27, 2009 10:52 AM

131224

1 2 3 4 5 6 7 8

16 17 191815 222120 23

1D_OM_4PW56102-1.book Page 1 Thursday, August 27, 2009 10:52 AM

EKRTWA

Room thermostat

4PW56102-1

Operation manual

The English text is the original instruction. Other languages are

translations of the original instructions.

WARNINGS

■Never let the thermostat get wet, this may cause an electric

shock or ﬁre.

■Never press the buttons of the thermostat with a hard,

pointed object. The thermostat may be damaged.

■Never inspect or service the thermostat yourself, ask a

qualiﬁed service person to do this.

Contents

1. Main features..........................................................................2

2. Buttons on front cover and LCD.............................................3

3. Getting started ....................................................................... 5

4. Description of the function modes and menus.......................7

5. Using the thermostat ..............................................................9

6. Setting up codes in the user menu....................................... 15

7. Troubleshooting .................................................................... 18

8. Maintenance......................................................................... 19

9. APPENDIX: factory-deﬁned programs .................................20

EKRTWA Room thermostat Operation manual

THANK YOU FOR PURCHASING THIS THERMOSTAT.

READ THE MANUAL ATTENTIVELY BEFORE USING

THE INSTALLATION. AFTER READING THE MANUAL,

STORE IT IN A SAFE PLACE FOR FUTURE USE.

1D_OM_4PW56102-1.book Page 1 Thursday, August 27, 2009 10:52 AM

Operation manual

EKRTWA

Room thermostat

4PW56102-1

1. Main features

The EKRTWA is a state of the art programmable electronic

thermostat, which regulates your Daikin system, where comfort,

simplicity and energy saving go hand in hand. It is the wired

room thermostat option kit, mainly used for new installations.

The main features are:

■Room temperature control, based on the measurements of

the internal sensor.

■Cooling and heating mode (with possibility to disable cooling

function if not required).

■Off function (with integrated frost protection).

■Comfort and reduced function modes, using the comfort and

reduced setpoint respectively.

■Holiday function mode.

■Weekly schedule timer with 2 custom (◊1+◊2) and 5

predeﬁned (π1~π5) schedules.

- The predeﬁned schedules use the comfort and reduced

setpoints of the comfort or reduced function mode.

- The custom schedules use independent, programmed

setpoints (up to 12 setpoints per day).

-You can lock the schedule timer which allows a temporary

override with the comfort or reduced setpoint by means of

a single key push.

- It is possible to link a custom schedule to cooling and

heating mode.

- Comfort startup control. The schedule timer will

automatically start up in advance, trying to reach the

programmed setpoint at the programmed time.

■Clock (with day and month).

■Key lock function.

■Automatic daylight saving time change.

■Setpoint limitation. Your installer has the possibility to modify

the lower and upper limit of the setpoints. Refer to “Setting

up codes in the installer menu” (code 6® 12+6® 13) in the

installation manual.

1D_OM_4PW56102-1.book Page 2 Thursday, August 27, 2009 10:52 AM

EKRTWA

Room thermostat

4PW56102-1

Operation manual

2. Buttons on front cover and LCD

Refer to ﬁgure 1 at the inside of the front cover.

Refer to ﬁgure 2 at the inside of the front cover.

1Left and right buttons (<and >). Used to select

modes.

2Up and down buttons (+or -). Used to change

values.

3OK - Schedule timer button (=).

Used to:

- conﬁrm setpoints or save selections

- enable/disable locked schedule timer

4LCD

1Cooling/heating mode selection

2Comfort function mode

3Schedule timer function mode

4Reduced function mode

5OFF function mode (with integrated frost protection)

6Holiday function mode

7Schedule timer setting menu

8Date and clock setting menu

9Manual override of scheduled mode

10 Day of the week

11 Error occurred: intervention needed

12 Active user or installation menu or error occurred. Refer

to "Troubleshooting" on page 18.

13 Selected program (schedule timer) or code

14 Room temperature or setpoint (when ﬂashing)

15 Thermostat ON (heating or cooling requested)

1D_OM_4PW56102-1.book Page 3 Thursday, August 27, 2009 10:52 AM

Operation manual

EKRTWA

Room thermostat

4PW56102-1

16 AM - PM indication

17 Room temperature symbol

18 Degrees type indication (°C or °F)

19 When manually overriding a schedule or when consulting

the active scheduled setpoints by pressing +or -,

the current and next setpoint together with the starting

hour of the next action are displayed.

•tis shown in case the next action setpoint goes up.

•uis shown in case the next action setpoint goes down.

•tu is shown in case the setpoints are equal.

20 Actual time

21 “Low batteries” indication

22 Key lock function

23 Next scheduled temperature setpoint

1D_OM_4PW56102-1.book Page 4 Thursday, August 27, 2009 10:52 AM

EKRTWA

Room thermostat

4PW56102-1

Operation manual

3. Getting started

3.1. Setting the clock and date

After installation you ﬁrst need to set the clock before you can

actually use the thermostat.

1Activate the advanced mode by pressing > during 5

seconds in OFF mode (D).

Refer also to "Description of the function modes and menus"

on page 7.

2Navigate to the date and clock setting menu (G) by pressing

>and then press =.

3Set the hour, minutes, day of the week (&= Monday,

I= Tuesday,...), day, month and year by pressing +or

-and conﬁrm each time by pressing =.

The value that you modify ﬂashes.

3.2. Setting the desired mode: heating or cooling

1Press <to go to comfort mode (A).

2Press <during 5 seconds to go to the heating/cooling

selection mode.

3Press <or >to switch to the desired mode.

Oor Pis ﬂashing.

4Press =to save your selection.

The thermostat returns to the schedule timer mode (B).

NOTE This is only possible if cooling mode is available.

1D_OM_4PW56102-1.book Page 5 Thursday, August 27, 2009 10:52 AM

Operation manual

EKRTWA

Room thermostat

4PW56102-1

3.3. Setting the desired setpoint

1Navigate to the comfort mode Aby pressing <or >to

set the comfort setpoint.

Refer also to "Description of the function modes and menus"

on page 7.

2Raise or drop the setpoint by pressing +or -.

The current setpoint ﬂashes.

3Press =to save your settings.

The room temperature is displayed (R).

1D_OM_4PW56102-1.book Page 6 Thursday, August 27, 2009 10:52 AM

EKRTWA

Room thermostat

4PW56102-1

Operation manual

Description of the function modes and menus

4.1. Modes in the standard menu AB C D

Press <or >to switch to the desired mode.

The zcursor will move.

Icon Description

AComfort mode. Use this mode for a ﬁxed temperature

on comfort level (comfort setpoint default on

21.0°C/70.0°F in heating mode, 24.0°C/75.5°F in cooling

mode).

BSchedule timer mode. Use this mode to let your

installation be controlled by the schedule timer. The

actions programmed in the schedule timer will be

executed automatically according to the actual time.

This function mode uses the scheduled temperature

setpoint.

The functionality of the locked/unlocked schedule timer

mode is explained in "Manually overriding a schedule"

on page 11.

It is advised to lock the schedule timer mode by pressing

=. A line will appear underneath the icon (S).

CReduced mode. Use this mode for a ﬁxed temperature

on reduced level (reduced setpoint default on

17.0°C/63.0°F in heating mode, 28.0°C/82.5°F in cooling

mode).

DOFF mode. Use this mode to switch off your installation.

Integrated frost protection remains activated (frost

protection default on 4.0°C/39.5°F).

1D_OM_4PW56102-1.book Page 7 Thursday, August 27, 2009 10:52 AM

Operation manual

EKRTWA

Room thermostat

4PW56102-1

4.2. Modes and menus in the advanced menu EFG

To activate advanced modes, navigate to OFF mode (D) and

press >during 5 seconds.

Icon Description

EHoliday mode. Use this mode to set a ﬁxed temperature

during a long absence. To exit the holiday mode, set the

duration to "?". Refer to "Using the holiday mode" on

page 14.

FSchedule timer setting menu. Use this menu to choose

a factory-deﬁned schedule or create a custom one.

GDate and clock setting menu. Use this menu to set

date and time.

1D_OM_4PW56102-1.book Page 8 Thursday, August 27, 2009 10:52 AM
