DANE-ELEC SO SPEAKY - Manuale utente
1. NOTICES ......................................................................................................................3
2. CAUTION:.....................................................................................................................4
3. PRODUCT PERFORMANCES.....................................................................................4
4. ACCESSORIES............................................................................................................7
5. PRODUCT USAGE.....................................................................................................10
6. SYSTEM SETUP ........................................................................................................18
7. APPENDIX..................................................................................................................18
- 2 -
Many thanks for choosing this product. For your better usage of this product, please
read this User Manual carefully first regarding points for attention and product
operation and functions.
National patent has been registered for this product described here. Any imitation will
be regarded as pirate, and should assume legal liability accordingly.
This product complies with national low-voltage electronic appliances safety standards,
and acquires American FCC certificate with Standard Part 15 Class B, and European
Union CE certificate with Standard EN55022 Class B, EN61000-6-3, EN61000-6-1.
The Serial No. stickers on the product and package are important proof for guaranteed
repairs against defects. Users need to present the Serial No. sticker for repair. The
company will not grant rights of repair if the sticker is damaged or illegible. Users can
enjoy after-sales service of replacement within the first three months, and repair within
twelve months free of charge.
Not all the using environment is suitable for this product. The after-sales service is
provided only with respect to quality issues and in accordance with promised
guarantee terms. The company will not hold liability for any data loss caused by the
product.
The company will not notify users individually any change of design and specification
because of technical or other reasons.
1. Notices
1. In order to shorten the time of searching files, we suggested you that you should
create 3 folders for “music” “picture” and “Movie” in your HDD or other big capacity
device of memory card, then put the corresponding file to each folder.
2. Not all the media files can be played, so please choose the correct media file.
3. Card reader cannot be connected with PC.
- 3 -
2. Caution:
1. Please do not use this product in environments of high-temperature or high-humidity.
2. Magnetic fields with special frequencies may affect data transfer.
3. Please do not move or strike the media player when it is used.
4. Please use the power adapter we offered. Other Power adapter not offered by our
company may make the product stop working or damage the product itself.
5. Please make the power off when it contacts other device.
6. High-temperature will appear when it is used, as this is a high-integration product. This
will not affect the product itself, so no need to worry.
3. Product Performances
3.1 Feature:
1. The So Speaky can work with big capacity of hard drive for huge storage of movies,
music and pictures.
2. The So Speaky support multi popular memory cards.
3. The So Speaky can connect to Home Theater for family enjoyment.
4. The So Speaky can be use as external storage device.
5. The So Speaky is with multiple output ports for connection of TV, VGA monitor and
amplifier.
6. The So Speaky support DVD navigation function.(Support DVD IFO file format
- 4 -
7. The So Speaky support DVD wide-screen video display on a wide-screen TV, support
multi-angle and multi-language function.
8. The So Speaky can display lyrics and be output sound signal at the same time under
playing the song files of MP3 and WMA format.(Support music LRC file format)
9. The So Speaky can set different EQ mode when the music playing.
10. The So Speaky is shape and aluminum housing.
- 5 -
3.2 Specification
HD capacity supported: up to 500GB.
Max HD partition: 4 primary partitions
HD files system:FAT32
Media files supported:
1.Subtitle: SRT,SSA,SMI
2.Audio: MP3 ,WMA,AAC,DTS
3.Video:MPEG1/2/MPEG4.XVID.DIVX.VCD.DVD(*.mpg;*.mpeg;*.dat;*.avi;*.vob;*.ifo)
4. Image: JPEG,MJPEG
Memory cards supported: CF.SD.MS. MMC.XD in FAT32 or FAT16 format
(important notice: the memory card reader slots on the machine only for media input
function, not for computer card reader function, so when Media player connected to
PC as a USB hard disk, then card reader slots are out of function). SDHC card are not
supported.
output Mode: Composite video + L&R audio channels, VGA, Progressive scan
component video .
USB port: High speed USB2.0
Audio out: Analog stereo.
Video out: CVBS.VGA .YPbPr
Image resolution: 720*480(NTSC, YPbPr)/720*576(PAL, YPbPr)/640*480(VGA)
Power supply: AC100~240V 50/60Hz
Power dissipation：30W (Max)
- 6 -
4. Accessories
No. Name Quantity
1 So Speaky 1 pc
2 Power Adapter 1 pc
3 Remote Controller 1 pc
4 AV cable 1 pc
5 Progressive scan component video cable 1 pc
6 USB cable 1 pc
7 Quick Start Guide 1 pc
8 CD So Util 1 pc
9 Batteries 2 pc
Functions of Remote Controller:
Key Function
POWER Turns the unit on/off
MUTE Turns the sound on/off
SETUP Enter setup of menu
ZOOM Zoom in images
MODE When picture SlideShow, it changes the transition mode
between pictures. When music playing it changes the
pre-equalized modes.
- 7 -
ANGLE Rotation the images. Select to view the same scene from
different angle, if the DVD recorded with multiple angles.
SUB-T Selection key for MPEG4 Subtitle file. it activates and
deactivates the subtitles while video playing. Can use the up
button or down button to select a subtitle language that is
available on the DVD.
VIDEO Video output mode switching.
DISPLAY Display information of media file. In DVD mode, select the
button can view the time, title or chapter on playing.
AUDIO Switching Audio channel
MENU Pressing once it returns to main menu from Picture, Video or
Music section. Pressing twice returns to the storage unit
menu (if there is more than one).
Up
Down
Left
Right
ENTER Enter.
Stop.
- 8 -
Pause/play.
Previous.
Next.
Skip backward.
Skip forward.
VOL+ Increase the volume.
VOL- Decrease the volume.
REPEAT Change Repeat play mode.
INTERVAL TIME Change the transition time between pictures when
SlideShow.
SLIDE SHOW Plays pictures in continuous mode.
OTB One Touch Backup ---Backup the data of memory card into
the hard driver directly.
One key press needed only.
Music Play music
DVD play Use the DVD key, you can enter into DVD navigation function
P/N Choice PAL/ NISC/MUIT-SYSTEM TV type.
SR Playback DVD with Slow forward mode.
SF Playback DVD with Slow reverse mode.
Preview
On/off
Be able to select preview on or preview off on in file mode
- 9 -
5. Product Usage
5.1 Device Connection
Connect the device as shown on the pictures, turn on power and follow below steps:
1. You want to use AV(CVBS) mode: press INPUT CHOICE key of the TV, and turn to
AV INPUT MODE. If image cannot appear, press VIDEO key of the So Speaky remote
controller and wait for a few seconds than press again, until it turns to CVBS mode,
then menu will appear on TV.
AV OUTPUT MODE
- 10 -
