Danfoss Heating

TPOne-S

Electronic Programmable Room Thermostat

Installation Guide

2TPOne-S

Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other

printed material. All trademarks in this material are property of the respective companies.

ErP Class

The products represented within this document are classiﬁed according

to, and allow completion of, the Energy Related Product (ErP) Directive

System Package ﬁche and the ErP system data label. ErP Labelling

obligation is applicable from 26th September 2015.

ERP Class Product Function and ErP Description

Additional

eﬃciency

gain

Modulating Room Thermostat, for use with

modulating heaters

An electronic room thermostat that varies the

ﬂow temperature of the water leaving the

heater dependent upon measured room tem-

perature deviation from room thermostat set

point. Control is achieved by modulating the

output of the heater.

ErP

Product

Class

SIMPLIFIED EU DECLARATION OF CONFORMITY

The simpliﬁed EU declaration of conformity referred to in Article 10(9) shall be

provided as follows:

Hereby, Danfoss A/S declares that the radio equipment type TPOne-S are in

compliance with Directive 2014/53/EU

The full text of the EU declaration of conformity is available at the following inter-

net address: heating.danfoss.com

Danfoss Heating 3

Installation Instructions

Speciﬁcations TPOne-S DBR

Operating Voltage 230V AC, 50 Hz

Setting temperature range 5-35°C -

Operating temprature range 0-45°C

Switch rating - 3A (1) at 230Vac

Switch type - SPST Type 1A

Transmission frequency 868.42 MHz

WiFi Speciﬁcation 802.11b/g (2.4GHz) -

Transmission range (in

normal buildings) up to 30m

Transmission power Max 1 mW

IP rating IP20 IP40

On/oﬀ control Yes

Chrono-proportional control Yes

Operating mode Heating -

Construction EN 60730-2-9 EN 60730-1

Control pollution situation Degree 2

Rated impulse voltage 2.5kV

Ball pressure test 75°C

Dimensions (mm) H66 x W155 x D30 H84 x W84 x D30

Software Classiﬁcation A

Important note RF products: Ensure that there are no large metal objects,

such as boiler cases or other large appliances, in line of sight between the

transmitter and receiver as these will prevent communication between

thermostat and receiver.

4TPOne-S

Mounting

Thermostat positioning:

MIN



30m MAX

Please note: This product should only be installed by

a qualiﬁed electrician or competent heating installer

and should be in accordance with the local wiring

regulations.

Note: These products use RF (Radio Frequency) technology to

communicate with each other and it is important that care is taken

during installation to ensure good wireless connection. Building

structure and materials may inﬂuence performance and large metal

objects such as boiler cases, appliances or mirrors in line of sight

between the thermostat and the receiver will prevent communication.

The receiver should be mounted near to the heat source leaving

a minimum distance of 30cm away from any metal enclosures or

appliance and positioned so that no large metal obstruction is between

the receiver and thermostat. The thermostat can be mounted remotely

up to 30m from the receiver while considering signal strength will

be reduce as it passes through walls and ceilings. Walls and ceilings

containing steel reinforcement or with metal foil lined insulation will

also have a signiﬁcant eﬀect on communication distance and may

block signal completely.

It is recommended that the RF connection should be checked

before permanently mounting the thermostat and where necessary

the location of the thermostat must be moved to ensure reliable

communication. The thermostat should be mounted at a height of

approximately 1.5m from the ﬂoor and away from draughts or heat

sources such as radiators, open ﬁres or direct sunlight.

Danfoss Heating 5

TPOne-S wiring

Wiring

DBR Receiver

1NL 234

230 VacCOM OUT

(Not Used)

230 Vac

Note: When using the table stand ONLY USE the power

supply and USB cable provided.

6TPOne-S

Comfort modes

User Interface

Display Navigation

Comfort Modes

Heating made easy: TPOne Comfort Modes simplify the way you

plan your heating day to day. You deﬁne your comfort modes in the

user schedule and manually override when you need, allowing you

to adapt your schedule to the way you live.

The Home, Away and Asleep comfort modes are linked to your

deﬁned comfort temperatures. The schedule follows the daily

routine you have set or you just choose the comfort mode required

and TPOne will recall the settings you have deﬁned.

The TPOne Standby Mode allows you to switch your heating oﬀ

when not required although the thermostat continues to monitor

the room temperature and call for heating should there be a risk of

frost damage.

Danfoss Heating 7

Comfort Modes

Home

Home Mode selects the home comfort

temperature typically when the home is

occupied during the day. The required

temperatures for Home mode are selectable

in the Temperature setting (see User Menu

> Temperatures.) A separate Home AM and

Home PM temperature can be chosen and

these are automatically set according to the

time of the day.

Note: When in Home mode if the home button

is pressed again a 1, 2 or 3 hour heating boost

is selected and the current home period is

extended by the chosen time period. The

chosen boost period is displayed under the

Home icon on the display.

Away

Away Mode selects the away comfort

temperature typically when the home is

unoccupied during the day. The required

temperature for Away mode is selectable in

the Temperature setting (see User Menu >

Temperatures).

Asleep

Asleep Mode selects the nightime comfort

temperature which is set between the end

of the last home period of the day and the

beginning of the ﬁrst home period of the

following day. The required temperature for

Asleep mode is selectable in the Temperature

setting (see User Menu > Temperatures).

Standby

The TPOne can be placed in Standby

Mode. While in Standby the TPOne will

not control the heating system other than

to protect against frost damage (see User

Menu > Installer Settings > Frost Protect for

information on frost protect). Standby can

be cancelled by pressing the Standby button

again or by selecting another comfort mode.

Note: the standby option places the heating

control in standby only, if Hot Water is set

up this is not aﬀected. To switch Hot Water

control oﬀ see User Menu > Hot Water > Mode

8TPOne-S

Navigation

Press Menu to access the intuitive text menu.

The common feature User Menu will be

displayed ﬁrst. Additional settings can found

in the User Setting option and more advance

settings can be found in the Installer Setting

option.

OK Select /

Conﬁrm

Press OK to select menu options or conﬁrm

settings. OK will be shown on the display

when it can be used or is required.

Menu

Back

Press to exit a menu option. Pressing 

while in a setting will result in that setting

change not be accepted. will also exit the

menu system. will be shown on the display

when it can be used

Naviga-

tion

The Navigation buttons are used to navigate

the TPOne menus and change setting values.

The up & down buttons are also used to

manually change the required temperature.

Navigation arrows will be shown on the

display when these buttons can be used.

Danfoss Heating 9

Button

Lock

Indicates that Button Lock has been activated to

avoid unintentional setting changes. To activate

buttons while button lock is active press the OK

button for 5 seconds. The Button Lock setting is

found in the Installer Menu.

Heat

Calling

When the current room temperature is below the

required room set temperature the TPOne will call

for heating from the connected heat source. This is

indicated by the Heat Calling icon.

Hot

Water

Calling

Where the TPOne-S has been set up for control

of domestic hot water the TPOne will call for

hot water heating according to the user set

schedule. This is indicated by the Hot Water

Calling icon.

The TPOne-S is connected by radio signal to a

receiver. The Radio Frequency icon will be displayed

to conﬁrm that this connection is active and that the

TPOne-S is controlling the heating.

If connection is lost the icon will go oﬀ and a warning

will be shown at the top of the display.

Important Note: Ensure that there are no large metal

objects, such as boiler cases, other large appliances

or mirrors in line of sight between the transmitter

and receiver as these will prevent communication

between the TPOne-S and receiver.

Display

Info & Settings Status Icons Dates &

Warnings

21.5°

16:35 Mon

NOTE:

TPOne monitors several conditions and will provide warning or

information messages when necessary. Details on these can be

found on pages 26-29.

10 TPOne-S

Setup Wizard/ Unit

The setup wizard will run when power is ﬁrst applied to the TPOne.

Once set the further changes can be made in the user and installer

setting menus.

 OK

RF Pairing

Language

English 

 OK

Set Date

 04 - 02 - 2016 

 OK





Set Time

 24hr - 10 : 45 

 OK





READY

DBR Receiver

21.

10:45 Thurs

Press button on

reciever to conﬁrm

Press OK to pair

Hot Water Setup

 OFF 

 OK
