Daviscomms BR802 Flex Manuale utente
User Manual
Contents
Introduction 1
Getting Started
Pager Features 3
Battery Information 6
Battery Installation and Removal 7
Button Definition 8
Pager On 9
Pager Off 9
Backlight 9
Main Menu Screen 10
Function Menu 11
Alert Mode 12
Quick Access to Vibrate Mode 13
Time and Date 14
Private Time 15
Alarm(One Time/Daily) 16
Pager Control 17
Set Contrast 18
Auto Scroll 19
Reminder Alert 20
Set Zoom 21
Messages
Button Definition for Inbox and
Saved Folders 22
Button Definition for Info Folder 23
Inbox Folder 24
Inbox Folder Function Menu 25
Receiving Messages 27
Error & Priority Messages 28
Message Full Indication &
Duplicate Messages 29
Info Folder (Information Service) 30
Info Folder Function Menu 31
Saved Folder 33
Saved Folder Function Menu 34
1
Feature Name Change
Other Features
Low Battery Alert
Out of Range
Power Up Message
Auto Backlight 37
Depleted Battery Shutdown
Over the Air Programming
Care for your pager
Maintenanace 37
38
35
36
37
2
3
Getting Started
Pager Features
The Br 802 Flex offers a wide range of useful features.
- 4 Lines, 20 English character screen
- Up to 30 Inbox messages
- Up to 15 Info slots with 5 history per slot
- 16 Saved slots for messages transferred from Inbox or Info folder
- 8 user selectable pleasing alerts
- Vibrate alert and vibra call
- Quick access to vibrate mode
- 3 speed auto scrolling option
- Private Time
- Backlight display for ease of reading
- Message zoom
- Unread message indication
- Alarm (One Time/Daily)
- Changeable naming per Group message, Info slot, Info folder,
Saved folder and Inbox folder
TM
Getting Started
- Error message indication*
- Message preview
- Message full indication
- Continous message indication
- Unread message indication
- Duplicate message indication*
- Priority message indication
- Group message alert
- Info message alert
- Unread message reminder alert
- Low battery alert*
- Real time clock and date display
- Adjustable LCD contrast
- Battery life gauge
- Out of range indication*
4
5
Getting Started
- Power up message*
- Auto Backlight on upon reception of message*
- Depleted battery shutdown*
- Over the air programming*
*optional features are set by the service provider
6
Battery Information
This pager is designed to operate on one 'AA' size alkaline battery
(Do not use battery type other than AA battery)
If the display shows the battery level is low.
Replace the battery as described on page 7
The time and any stored messages will remain in memory up to
one minute after the removal of battery.
WARNING - use of a battery other than an Energizer E91 OR a Duracell
MN1500 1.5 AA battery may impair intrinsic safety UL rating of this device
7
Battery Installation and
Removal
- Place the pager face down on
the palm of your hand
- Unlock the door and slide it out
as shown
- Insert new battery into battery
compartment
- Ensure that the battery polarity is
corrct as indicated on the housing.
- To close, slide the battery door
back into position and lock it
8
- Backward Button : navigate back
- Forward Button : navigate forward
- Function Button : access the function menu
- Read/On button : read messages/hold to turn pager on
- Down button : navigate down/hold to quick access to
vibrate mode
- Up button : navigate up
Button Definition
Backward
Button
Forward
button
Up
Button
Down
Button
Read/On
Button
Function
Button
Getting Started
Pager ON
Press and hold for 2 seconds to turn on the pager.
Pager OFF
Press button once from the Main Menu screen to go to the Function
Menu screen, then press button five times to select TURN OFF
function.
Press button, "TURN OFF" is displayed.
Press button again to confirm turning your pager off, or button to
cancel.
Backlight
Press and hold for 2 seconds to turn ON the backlight manually
Press and hold for 2 seconds to turn OFF the backlight manually
