Daxten MONITOR SPLITTER Manuale utente
f
Monitor Splitter - VGA Splitter
Images say more
than words!
The Daxten Monitor Splitter, sometimes known as a VGA splitter or video
splitter, allows a user to display their video image over multiple monitors.
This is an ideal product for training, exhibitions, demonstrations and class-
room situations. A variety of models are available for every use, including
distance applications up to 250 feet from the CPU. Premium models offer
maximum video clarity across all resolutions.
Available in 2, 4, and 8 port versions
Plug & Play
Operating system and software independent
Also available as a Micro Splitter with a 1 GHz bandwidth for a high
resolution up to 1600 x 1200
www.daxten.com
Monitor Splitter - VGA Splitter
Daxten Limited
5 Manhattan Business Park
Westgate
London W5 1UP
Tel: 020 8991 6200
Fax: 020 8991 6299
Part No.
1020-02M Micro Splitter 2 Port 1 GHz
1020-02EK Monitor Splitter E 2 Port
1020-04EK Monitor Splitter E 4 Port
1020-08EK Monitor Splitter E 8 Port
www.daxten.com
Technical specification Monitor Splitter:
Dimensions (HxWxD):
• 2 and 4 port: 156 x 80 x 32 mm
• 8 port: 185 x 132 x 55 mm
Supports resolution up to 1280 x 1024
Video bandwidth: 400 MHz
Support all operating systems incl. DOS,
UNIX (Linux), Windows 95, 98, NT, OS/2
Max. distance from Splitter to PC: 7,5 m (25ft)
cable included
No external power supply for 2 and 4 port
versions
Technical specification Micro Splitter:
Dimensions (HxWxD):
100 x 60 x24 mm
Supports resolution up to 1600 x 1200
Video bandwidth: 1 GHz
Configuration Monitor Splitter 2-Port Configuration Micro Splitter Splitter 2-Port
