Operation guide
1. ON/OFF
DecaLED® Touch Panel DMX 4 can be connected to a DC power at any voltage from 12V to 24V. When the
indicator of POWER button lights up, the unit powers on and resumes the output setting of last time.
In normal mode, to touch POWER key and hold on for 2s, DecaLED® Touch Panel DMX 4 switches to the state
of standby. At this time, the output is shut down. Touch the power key once again and hold on for 2s, the unit
is powered on.
Setting Shortcut for Power ON/OFF
If this shortcut is not set, you will need to touch and hold the ON/OFF button for 2 seconds to turn the controller
on or off. If the shortcut is set, the DecaLED®Touch Panel DMX 4 will respond immediately with a single touch
of the ON/OFF button.
• Touch “Program” key and “Power” key simultaneously and hold on for about 10 seconds until all keys ash
momentarily once.
• Touch “Power” key once, DecaLED® Touch Panel DMX 4 changes to standby condition. Directly touch any
key on the panel, DecaLED® Touch Panel DMX 4 starts up.
• To delete power shortcut, touch “Program” key and “Power” key simultaneously and hold on for about 10
seconds until all keys ash once.
Setting Fadetime for Power ON/OFF
• To set power on/off fadetime, follow the procedures below:
• Touch “Power” key and hold on for 5 seconds till all LED indicators ash once. Then release the Power key
and the key ashes repeatedly.
• Touch any one of these keys--1, 2, 3, 4, Program, Color, Brightness or Speed.
• All indicators ash momentarily once to conrm the setting.
• The existing mode ends and changes to normal mode automatically.
Different keys represent different fadetime:
Keys 1 2 3 4 P/C/B/S
Fadetime 1s 2s 3s 4s 0s (no fade)
2. Built-in Program
Hold on pressing “Program” key for about 1s to enable built-in Program Menu, the key clicks and the indicator
is lit. Then rotate the touch toggle to select a desired built-in program. There are 10 built-in programs plus an
Auto Program for user selection (“Auto Program” is the sequential running of these 10 built-in programs).
The process of selecting the built-in programs produces clicks and each click will activate one program.
3. Brightness
To enable Brightness Menu, hold on pressing “Brightness” key for about 1s, the key clicks and the indicator lights
up. Then rotate the touch toggle to adjust the brightness as you wish. In clockwise, the brightness increases; In
anti-clockwise, the brightness decreases.
NOTE: The value of brightness can be adjusted in the range of 0 to 255.
4. Speed
To enable Speed Menu, hold on pressing the “Speed” key for about 1s, the key clicks and the indicator lights
up. Then rotate the touch toggle to adjust the speed of running built-in programs in the range of 0.2s~10min.
In clockwise, the speed will increase;In anti-clockwise, the speed will decrease.
When you rotate the toggle to reach 10min, the click disappears and all the four gure keys ash repeatedly.
Then you select the speed which you wish by pressing any of the gure keys. Different gure keys stand for
different speed -- “1” for 10min, “2” for 20min, “3” for 30min and “4” for 40min.
