Decimator DMON?12S Manuale utente

DMON‐12SHardwareManualforFirmwareVersion1.1



DMON-12S

1to12Channel

(3G/HD/SD)‐SDIMulti‐Viewer

withSDIandHDMIoutputs

OperatingManualforFirmwareVersion1.1



DMON‐12SHardwareManualforFirmwareVersion1.1

Introduction



ThankyouforpurchasingtheDMON‐12S12Channel(3G/HD/SD)‐SDIMulti‐ViewerwithHDMIandSDI

outputs.TheDMON‐12Sisatrulyportableconverter,whichincorporatesourneweasytouseLCDandbutton

controlsystem.Thisgivesyoueasyaccesstomostoftheamazingfeaturesthathavebeenunavailablewithout

acomputeruntilnow.Thedaysofhavingtoplaywithcomplicateddipswitchesorhavingtocarryarounda

computertochangeasimplesettingaregone.



TheDMON‐12Sfeaturesthefollowing:

Lowcostminiature(3G/HD/SD)‐SDI1to12channelMulti‐Vieweror12to1inputmultiplexer

CustomLayoutswithvariousstandardlayouts

16CharacterUMDoverlayperwindowwithindividualenables,custompositioningandsize

16ChannelAudioMeteringoverlayperwindowwithindividualenables,custompositioningandsize

SafeActionandSafeTitleoverlayperwindowwithindividualenablesandadjustment

CentreCrossoverlayperwindowwithindividualenable

AudioIDoverlay

TalliescanbeappliedtoeitherTallyBoxes(Default),OutsideSafeActionAreaorBorder

Tallyboxesallowsforupto4TalliesperwindowwithTallyBoxes(Green,Red,BlueandYellow)

LoadandrestoreCustomLayouts

FastswitchingbetweeninputsusingFull‐Screenscaling

SelectableoutputformatinbothFull‐ScreenandMulti‐Viewermode

Lowlatencybufferingforeachinputallowingnon‐synchronousinputs

Linked(3G/HD/SD)‐SDIandHDMIoutputs

12x(3G/HD/SD)‐SDIinputswithautodetection(26Formatssupportedintotal)

Eachwindowisindependentoftheothers,allowingany3G/HD/SDformatofanyframeratetobe

displayedsimultaneously

Variableaspectratiosperquadrant

Pass‐Throughmodeallowinganyofthe12inputstobeselectedforoutput

InPass‐Throughmodetheselectedinputispassedthroughtoboththe(3G/HD/SD)‐SDIandHDMI

outputs

TheDMON‐12SisatrulyportableconverterthatincorporatesourneweasytouseLCDandbutton

controlsystem.Thisgivesyoueasyaccesstomostoftheamazingfeatureswithoutusingcomplicated

LED/buttoncontrol,dipswitchesorhavingtocarryaroundacomputertochangeasimplesetting.

Thisunitalsoincludes:

‐32GPIon37‐pinD‐SUBconnectorforDynamicTalliesandRemoteSwitching

‐RS422/485on37‐pinD‐SUBconnectorforDynamicUMDandTalliesviaTSLprotocol

‐USBportforcontrolandfirmwareupdates

‐Heavydutymetalbox

‐MetalThreadLockingDCPowerSocket

‐PowerSupply,HDMICableandUSBCable



DMON‐12SHardwareManualforFirmwareVersion1.1

MainMenus

UponpoweruptheunitwillstartintheMainMenupointingtoInputStatus.

TheMainMenusare:

1. InputStatus

2. Control

3. Routing

4. Colours

5. UMDs

6. AudioMeters

7. Graticules

8. GPI

9. Setup

Pressthe<and>buttonstomoveleftorrightthroughthemenus.

ToenterintoamenupresstheENTERbutton.



Notes:

1. Defaultsarehighlightedinyellow.

2. Whenanoptionischanged,ahighlightedSwillappearinthetoprightoftheLCDscreenandwill

disappearwhentheoptionsaresavedafter10seconds.Avoidpoweringdowntheunitduringthis

time.

3. YoucanalwaysreturntotheMainMenubypressingtheBACKbuttontwice.

4. Asyoumovethroughthemenuschangingparameters,theywillbeinstantlyappliedtotheoutput

signal.



InputStatus:(Has3states)



WhenpressingenterintheInputStatusmenu,willcyclebetweenthestatusforinput1‐4,5‐8and9‐12.



(Default)

1:3G1080p59.94

2:HD720p50

3:SD480i59.94

4:HD1080i59.94

CurrentformatonSDIInput1

CurrentformatonSDIInput2

CurrentformatonSDIInput3

CurrentformatonSDIInput4



(AfterpressingENTERonce)

5:3G1080p60

6:3G1080p60

7:3G1080p60

8:3G1080p59.94

CurrentformatonSDIInput5

CurrentformatonSDIInput6

CurrentformatonSDIInput7

CurrentformatonSDIInput8



(AfterpressingENTERtwice)

9:HD1080p24

10:HD720p50

11:SD480i59.94

12:HD1080i59.94

CurrentformatonSDIInput9

CurrentformatonSDIInput10

CurrentformatonSDIInput11

CurrentformatonSDIInput12



Control:(HasSUB‐MENUs)



Control

HDMI Output Type

HDMI RGB444 2C

MainMenu<==

SubMenu

ParameterWindow

WhenhighlightedintheMainMenu,presstheENTERbuttontoenterthissub‐menu.

DMON‐12SHardwareManualforFirmwareVersion1.1

Pressthe<and>buttonstomoveleftorrightrespectivelythroughthe12menusbelowandpresstheBACK

buttontogobacktotheMainMenuwhenfinished.

ThecurrentvalueforeachSubMenuisshownintheParameterWindow.



1.Control/HDMIOutputType(Parameter)

ThisisthecurrentHDMIoutputtypeforoutput1.

Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingtypes:

1.) DVIRGB444  DVI‐DRGB4:4:4

2.) HDMIRGB4442C HDMIRGB4:4:4with2‐ChannelsofAudio

3.) HDMIYCbCr4442CHDMIYCbCr4:4:4with2‐ChannelsofAudio

4.) HDMIYCbCr4222CHDMIYCbCr4:2:2with2‐ChannelsofAudio

5.) HDMIRGB4448C HDMIRGB4:4:4with8‐ChannelsofAudio

6.) HDMIYCbCr4448CHDMIYCbCr4:4:4with8‐ChannelsofAudio

7.) HDMIYCbCr4228CHDMIYCbCr4:2:2with8‐ChannelsofAudio



2.Control/OutputSelect(Parameter)

ThisisthecurrentsourcefortheHDMIandSDIoutputs.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthefollowingsources:

1.) Multi‐View

2.) Window1

3.) Window2

4.) Window3

5.) Window4

6.) Window5

7.) Window6

8.) Window7

9.) Window8

10.) Window9

11.) Window10

12.) Window11

13.) Window12



3.Control/MVOutputFormat(Parameter)

ThisisthecurrentoutputformatfortheMulti‐Viewer.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthe26videoformatslistedbelowandtheBACKbutton

toleavethisSUB‐MENU.

1.SD720x487i59.9411.HD1920x1080p30 21.HD1280x720p25

2.SD720x576i5012.HD1920x1080p29.97 22.HD1280x720p24

3.HD1920x1080i6013.HD1920x1080p25 23.HD1280x720p23.98

4.HD1920x1080i59.9414.HD1920x1080p24 24.3G1920x1080p60

5.HD1920x1080i5015.HD1920x1080p23.98 25.3G1920x1080p59.94

6.HD1920x1080psf2416.HD1280x720p30 26.3G1920x1080p50

7.HD1920x1080psf23.98 17.HD1280x720p29.97



4.Control/MVWindows(Parameter)

Thisisthecurrentnumberofwindowsshownonthemulti‐viewoutput.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthenumberofwindowsdisplayedfrom1to12.

DefaultWindowsdisplayedis12windows.



DMON‐12SHardwareManualforFirmwareVersion1.1

5.Control/MVLayout(Parameter)

Thisisthecurrentlayoutofthemulti‐viewer,thereare32layoutsselectableperformatandmulti‐viewer

windownumber.10ofthesearepredefinedlayouts.Whenthesubmenuishighlighted,presstheENTER

buttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthefollowinglayouts:

1.) 100%

2.) 100%withBorder

3.) 90%

4.) 90%withBorder

5.) 100%withGap

6.) 100%withBorder+Gap

7.) 90%withGap

8.) 90%withBorder+Gap

9to30)Custom

31.)ToptoBottom

32.)LefttoRight



Notes:

Forevery‘Format’and‘NumberofWindows’thereare32layouts.

E.g.fora1920x1080i60formatshowing12windowsthereare32layoutstiedtothisoutput,ifthenumberof

windowsischangedto11therearealso32separatelayoutsattachedtothissetting.

FullScreenPassthroughwillalsousetheselectedlayoutfor1window.



6.Control/MVAudioSource(Parameter)

ThisselectswhichwindowtheaudioisextractedfromfortheMulti‐Vieweroutput.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthefollowingsources:

1.) Window1

2.) Window2

3.) Window3

4.) Window4

5.) Window5

6.) Window6

7.) Window7

8.) Window8

9.) Window9

10.) Window10

11.) Window11

12.) Window12



7.Control/MVReference(Parameter)

ThisisreferencefortheMulti‐Viewer.

Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingsources:

1.) Window1

2.) Free‐Run



8.Control/PassScaled(Parameter)

WhentheOutputSelectischangedtowindow1to12,thisparameterdetermineswhethertheoutputis

scaledorpassedthroughunchangedfromtheselectedwindow.Whentheoutputisscaled,theselected

layoutforwindow1isused.Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowing

selections:

1.) Yes

2.) No



DMON‐12SHardwareManualforFirmwareVersion1.1

9.Control/FormatStatus(Parameter)

WhenaninputisdetectedtheDMON‐12Swilldisplaytheformatdetectedinthetopleftofeachwindowby

defaultunlessthelocationhasbeenmodifiedviatheUSBControlPanel.Whenthesubmenuishighlighted,

pressENTERtotogglethroughthefollowingselections:

1.) Showfor5sec

2.) ShowAlways

3.) Off



10.Control/AudioSourceID(Parameter)

TheAudioSourceIdentificationiconwillappearwhenselectingwhichwindowtheaudiowillbepassedfrom

totheoutputwheninmulti‐viewermode.Thisoptiontoggleswhethertheiconisshowntoindicatethe

windowsourcetheaudioiscomingfrom.ThisiconappearsinfrontoftheFormatStatus.Whenthesubmenu

ishighlighted,pressENTERtotogglethroughthefollowingselections:

1.) Showfor5sec

2.) ShowAlways

3.) Off



11.Control/ApplyTallyto(Parameter)

TheApplytallytoparameterallowstheselectionofthe3differenttypesoftallyindicators.Whenatallyis

triggereditcanbedisplayedasasmallboxonthebottomleft(defaultposition)oftheinputswindoworas

borderaroundthewindow.TheTallycanalsofilltheoutsideofthesafeactionbox.Whenthesubmenuis

highlighted,pressENTERtotogglethroughthefollowingselections:

1.) Border

2.) OutSafeAction

3.) TallyBoxes



11.Control/TallyTransparency(Parameter)

TheTallytransparencyfeaturechangesthetransparencyofthetallybox/border/OutsidesafeAction.When

thesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:

1.) 0%

2.) 25%

3.) 50%



Routing:(HasSUB‐MENUs)



Routing

Window 1 Source

Input 1

MainMenu<==

SubMenu

ParameterWindow

WhenhighlightedintheMainMenu,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightrespectivelythroughthe12menusbelowandpresstheBACK

buttontogobacktotheMainMenuwhenfinished.

ThecurrentvalueforeachSubMenuisshownintheParameterWindow.



1.Routing/Window1Source(Parameter)

ThisistheinputsourceforWindow1.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthefollowingsources:

1.) Input1  (defaultforWindow1)

2.) Input2  (defaultforWindow2)

3.) Input3  (defaultforWindow3)

4.) Input4  (defaultforWindow4)

5.) Input5 (defaultforWindow5)

DMON‐12SHardwareManualforFirmwareVersion1.1

6.) Input6 (defaultforWindow6)

7.) Input7 (defaultforWindow7)

8.) Input8 (defaultforWindow8)

9.) Input9 (defaultforWindow9)

10.) Input10 (defaultforWindow10)

11.) Input11 (defaultforWindow11)

12.) Input12 (defaultforWindow12)



PleasenotethatWindows1to6sourcesarethesameasabove.



Colours:(HasSUB‐MENUs)



Colours

Background Color

Black

MainMenu<==

SubMenu

ParameterWindow

WhenhighlightedintheMainMenu,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightrespectivelythroughthe10menusbelowandpresstheBACK

buttontogobacktotheMainMenuwhenfinished.

ThecurrentvalueforeachSubMenuisshownintheParameterWindow.



1.Colours/BackgroundColour(Parameter)

ThisisbackgroundcolourfortheMulti‐Viewer.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthefollowingcolours:

1.) Black

2.) Blue

3.) Green

4.) Cyan

5.) Red

6.) Magenta

7.) Yellow

8.) White



2.Colours/BorderColour(Parameter)

ThisisbordercolourfortheMulti‐Viewer.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthefollowingcolours:

1.) Black

2.) Blue

3.) Green

4.) Cyan

5.) Red

6.) Magenta

7.) Yellow

8.) White



DMON‐12SHardwareManualforFirmwareVersion1.1

3.Colours/UMDForeground(Parameter)

ThisistheUMDcolourandtransparencysettingforthetext.

Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.

Pressthe<and>buttonstomoveleftorrightthroughthefollowingcolours:

1.None10.Black(Transparent25%) 19.Blue(Transparent0%)

2.Black(Transparent50%) 11.Blue(Transparent25%) 20.Green(Transparent0%)

3.Blue(Transparent50%) 12.Green(Transparent25%) 21.Cyan(Transparent0%)

4.Green(Transparent50%) 13.Cyan(Transparent25%) 22.Red(Transparent0%)

5.Cyan(Transparent50%) 14.Red(Transparent25%) 23.Magenta(Transparent0%)

6.Red(Transparent50%) 15.Magenta(Transparent25%) 24.Yellow(Transparent0%)

7.Magenta(Transparent50%)16.Yellow(Transparent25%) 25.White(Transparent0%)

8.Yellow(Transparent50%)17.White(Transparent25%)

9.White(Transparent50%) 18.Black(Transparent0%)



4.Colours/UMDBackground(Parameter)

ThisistheUMDcolourandtransparencysettingforthebackgroundoftheUMDs.
