Dedicated Micros EcoSense Istruzioni operative originali

EcoSense

Installation &

Operation Guide

EcoSense

Whilst every attempt is made to ensure these manuals are accurate and current, Dedicated Micros reserve the right to alter or

modify the specication of the machine described herein without prejudice.

Contents

Introduction ........................................................................... 3

Features ............................................................................... 4

Important Safeguards ........................................................... 6

Installing the Unit .................................................................. 8

Installation .......................................................................... 10

Accessing & Conguring the Unit ....................................... 17

Remote Control .................................................................. 19

Navigating The Conguration Menus ................................. 24

System Settings.................................................................. 25

Display Settings .................................................................. 38

Camera Settings ................................................................. 44

Record Settings .................................................................. 48

Alarm Settings ......................................................................... 57

Network Settings ................................................................ 69

Oracle Dome Conguration ................................................ 79

Unit Operation .................................................................... 91

Operating the Viewer .......................................................... 91

Appendix A........................................................................ 110

Appendix B ........................................................................111

Appendix C ....................................................................... 113

Appendix D ...................................................................... 114

Appendix E ....................................................................... 115

EcoSense

Introduction

What is the…

EcoSense ?

The EcoSense from Dedicated Micros provides low cost multi channel recording with simultaneous

playback and viewing; ideal for the cost conscious user who needs reliable, networked, high

performance CCTV at an affordable price.

Available with 4, 8 or 16 camera inputs, all offering telemetry control, the EcoSense has built in

Alarm functionality and onboard Activity detection software.

The state of the art touch sensitive front panel and the accompanying Infra-Red (IR) Remote Control

make for simple, quick operation. Dedicated Micros trademark plug and play intuitive set-up, user-

friendly interface with colour coded ‘softkeys’ and conguration menus common to both local monitor

and web interface; help keep installation and operator training to a minimum.

The EcoSense offers a global record rate of up to 200pps (dependant on model) at CIF and can

record up to 16 cameras (dependant on model) simultaneously in MPEG-4 or JPEG format. The

Prole Record feature enables an operator to set different recording rates and resolutions across

scheduled, normal and alarm modes for all cameras.

As standard, the unit includes internal storage with a CD/DVD-R Writer and USB ports for external

video archiving.

Among the many other features included as standard on the EcoSense are; multiway display,

multiple language support, telemetry control, audio recording, activity detection and remote

monitoring using NetVu ObserVer (utilising DM’s unique TransCoding capabilities to provide uent

live and replay images). The EcoSense is undoubtedly the ideal product when high-performance

video recording and transmission is required at an affordable cost.

For further information, please visit the website:

www.dedicatedmicros.com

or contact Dedicated Micros customer services in your region.

EcoSense

Features

• 4, 8 or 16 camera input options

• True global record rate of up to 200pps at CIF

• Simultaneous Live viewing and Recording

• D1/4CIF/2CIF/CIF record rate at 3/3/6/12pps per camera

• JPEG or MPEG-4 recording and transmission

• Touch sensitive front control panel

• Easy to use on-screen, colour coded softkeys

• Field serviceable hard drives

• Telemetry support

• All DVR functions fully supported by Keyboard/IR Remote Control

• Scalable Record Settings

• Single, Picture in Picture and Multiway displays

• Live and playback viewing locally and over Ethernet

• Built in activity detection

• Built in DVD writer and USB ports for download of video archive to external

ash memory

• Web pages provide easy remote conguration

• Alarm Inputs & Outputs

• Optional external keyboard available

The unit has NetVu Connected technology built-in to ensure maximum compatibility with future

developments in networked security. NetVu Connected technology enables the Unit to fully interact

with other NetVu Connected compatible products from Dedicated Micros including the DV-IP

Decoder, NetVu ObserVer and PDA Viewers. Providing interoperability between the worlds leading

security companies, NetVu Connected uses industry standard networking protocols supported by a

wide range of third party integration products and SDKs to ensure future on-going compatibility.

COMMON CONFIGURATION INTERFACE

A Common Conguration interface is displayed when the unit’s conguration screens are accessed

locally at the unit or remotely via a web browser. This unied system ensures that the installer is

familiar with the conguration screens irrespective of their location to the unit, minimising training

and familiarisation time and increasing the speed of installation and alteration.

The Unit includes a unique colour-coded menu structure and onscreen Graphical User Interface

(GUI). Context sensitive, the menu structure always represents the area of the menu the user is in,

allowing them to quickly select the options and settings they need without having to trawl through

menu pages and options. The colour coded buttons displayed on the monitor match those on the

touch screen front panel and IR Remote Control, whilst control can also be conducted through an

attached USB Mouse or supported Keyboard (DM/KBC1 / DM/KBC2).

EcoSense

Design of the manual

The manual has three parts:

1. Installation Shows details of how to install the unit and connect external devices.

2. Conguration Shows details of the unit’s menus.

3. Operation Shows quick reference details on how to control the unit.

The order and layout of these pages has been designed to help the setup process. It is

recommended that the menus are edited sequentially (as they appear on the page), to enable

accurate, easy and efcient setup.

EcoSense

Important Safeguards

Read Instructions

All the safety and operating instructions should be read before the unit is operated.

Power Sources

This unit should be operated only from the type of power source indicated on the manufacturer’s

label.

Servicing

Do not attempt to service this unit yourself as opening or removing covers may expose you to

dangerous voltage or other hazards.

Refer all servicing to qualied service personnel.

Ventilation

Ensure unit is properly ventilated to protect from overheating.

All the safety and operating instructions should be read before the unit is operated.

To prevent re or shock hazard, do not expose this equipment to rain or moisture. The lightning ash

with arrowhead symbol within an equilateral triangle is intended to alert the user of this equipment

that there are dangerous voltages within the enclosure which may be of sufcient magnitude to

constitute a risk of electric shock.

This is a class A product. In a domestic environment this product may cause radio interference in

which case the user may be required to take adequate measures.

Lightning Strike

The unit has some in-built protection for lightning strike, however it is recommended that isolation

transformers be tted to the system in areas where lightning is a common occurrence.

Regulatory Notes and FCC and DOC Information

(USA and Canadian Models Only)

Warning: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at their own expense.

If necessary, the user should consult the dealer or an experienced radio/television technician for

corrective action. The user may nd the following booklet prepared by the Federal Communications

Commission helpful: “How to Identify and Resolve Radio-TV Interference Problems”.

This booklet is available from the US Government Printing Ofce, Washington, DC20402,

Stock No. 004-000-00345-4.

This reminder is provided to call the CCTV system installer’s attention to Art. 820-40 of the NEC that

provides guidelines for proper grounding and, in particular, species that the cable ground shall be

connected to the grounding system of the building, as close to the point of cable entry as practical.

EcoSense

CE Mark

If this product is marked with the CE symbol it indicates compliance with all applicable directives.

Directive 89/336/EEC.

A ‘Declaration of Conformity’ is held at Dedicated Micros Ltd.,

1200 Daresbury Park, Daresbury, Cheshire, WA4 4HS, UK.

Laser

The unit supports an integrated CD writer, the following are additional warnings associated with

installing and operating the CD writer, please pay particular attention to this information.

• Caution - Use of controls or adjustments or performance of procedures other than those

specied herein may result in hazardous radiation exposure.

• To prevent exposure to laser emanations (harmful to the eyes), do not attempt to

disassemble this unit.

EcoSense

Installing the Unit

Before you start

Check the contents of the box

The following items are included in the box:

Remove all items from the packaging and check the items listed below are present.

• EcoSense DVR (either 4, 8 or 16 input)

• IR Remote Control

• 12v DC Power Adaptor

• EcoSense Software CD

• Quick Start Guide

If any of these items are missing please contact Dedicated Micros Technical Support team.

Note: Before installing the unit, carefully read all Safety Instructions and the following information

on where the unit should be located.

Choosing a location for installation

• The unit is designed to be desk, shelf or rack mounted. Rack mounting brackets are

available as an optional accessory.

• Ensure the unit is properly ventilated to protect from overheating.

• Ensure there is a 3cm gap on both sides of the unit.

• Ensure the IR receiver on the front of the unit faces the operator position, and is not

more than 10 feet (3 metres) from the operator.

• Ensure the unit is not located anywhere it could be subject to mechanical shocks.

• The unit should be located in an area with low humidity and a minimum of dust. Avoid

places like damp basements or loft spaces.

• If the unit is to be installed in a closed assembly, the maximum operating temperature

must not exceed 40°C (104°F).

• Ensure there is reliable earthing of the mains outlet when tted to supply connections

(other than direct connection to the branch circuit).

• Any branch circuit supplying the unit must be rated at 15Amps.

• It is recommended that an uninteruptable power source be connected to the unit in

case of power failure (to ensure continuous operation of the unit).

Electrical Connections

Please ensure the following are available and have been tested prior to the installation:

• Mains point

• Network point

• Network cable

• Active video signals i.e. at least one working camera feed

• PC with CD ROM drive and connection to the same network as the DVR

(Recommended).

EcoSense

Quick Overview Of Default Record Settings

Units provide out of the box:

High performance recording on ALL cameras with minimal conguration.

Consistent recording duration and smooth motion video per camera regardless of the number of

cameras connected.

Continuous 3pps MPEG4 recording on all cameras, on all channel variants (default out of the box).

Complete Flexibility

It is possible to set the unit’s record congurations based on specic priorities.

The Prole Record

feature allows different record rates and quality settings to be used for unset, set and override

modes for all cameras. This can ensure event images are recorded at high quality, whilst normal

‘non event’ images are recorded at a reduced setting, minimising storage requirements.

With true global record rates of up to 200pps (PAL) and 240pps (NTSC), the unit offers recording of

up to 3pps on each camera, out of the box, at a record duration of 7, 14 or 30 days (the default is

14 days).

Note: It is the Installer/Owner’s responsibility to ensure that the record duration is set to the

necessary requirements of the application.

EcoSense

Installation

Front Panel connections

Data

CD/DVR Internal CD/DVR drive

USB USB2.0 connector

IR Infra-Red receiver for use with Remote Control

Rear Panel connections

16 Input model

8 Input model

4 Input model

Indice

Altri manuali Dedicated Micros Registratore digitale

Dedicated Micros

Dedicated Micros D4 Istruzioni per l'installazione e il funzionamento

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manuale utente

Dedicated Micros

Dedicated Micros Eco9 Manuale utente

Dedicated Micros

Dedicated Micros SDA-32-6T Manuale utente

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manuale utente

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manuale utente

Dedicated Micros

Dedicated Micros D3 Manuale utente

Dedicated Micros

Dedicated Micros SD Range Manuale utente

Dedicated Micros

Dedicated Micros NetVu Connected DS2 Istruzioni per l'installazione e il funzionamento

Dedicated Micros

Dedicated Micros DV-IP Series Manuale utente

Dedicated Micros

Dedicated Micros TransVu Express Manuale utente

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manuale utente

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manuale utente

Dedicated Micros

Dedicated Micros SD Range Istruzioni operative

Dedicated Micros

Dedicated Micros Digital Sprite 2 Istruzioni per l'installazione e il funzionamento

Dedicated Micros

Dedicated Micros D4 Manuale utente

Dedicated Micros

Dedicated Micros SD Excel Manuale utente

Dedicated Micros

Dedicated Micros Digital Sprite 2 Istruzioni per l'installazione e il funzionamento

Dedicated Micros

Dedicated Micros DV-IP NV4 Manuale utente

Dedicated Micros

Dedicated Micros Eco4 Series Istruzioni operative originali

Dedicated Micros

Dedicated Micros Digital Sprite 2 Manuale utente

Dedicated Micros

Dedicated Micros SD Range Istruzioni operative

Dedicated Micros

Dedicated Micros Eco4 Series Manuale utente

Dedicated Micros

Dedicated Micros NetVu Uniplex UP/MAN/002/M Guida all'installazione

Manuali Registratore digitale popolari di altre marche

FLIR

FLIR M3100E Series Manuale utente

VTRACKPRO

VTRACKPRO FPRO300 Manuale utente

Swann

Swann NVR-7085 models Manuale utente

XtendLan

XtendLan DVR-1670C Manuale utente

urmet domus

urmet domus 1093/004AHD Manuale utente

Holux

Holux M1 Manuale utente

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuale utente

Whistler

Whistler D16VRS Manuale utente

Defender Security

Defender Security 82-20235 Manuale utente

MISUMI

MISUMI MP-WF100M Manuale utente

Speco

Speco D8HU Manuale utente

UST

UST DDR-E04AA Istruzioni per l’uso

Consolidated

Consolidated Digital Video Recorder Manuale utente

Mace

Mace DVR0404RW Guida rapida

RCA

RCA RTD315W Manuale utente

FSM

FSM Colibri Grande PRO Manuale utente

Hauppauge

Hauppauge HD PVR 2 Manuale utente

Identivision

Identivision ICR-PH161i PIONEER Manuale utente
