DEGEN DE1128 Manuale utente
OPERATION MANUAL
FM STEREO AM SW DSP RECEIVER
MP3 PLAYER
DIGITAL RECORDER
REPEAT
LOUDSPEAKER
support firmware upgrade, please visit
http://www.degen.com.cn
DE1128
This unit is limited to Asia and Russian region
DE1128 unit
Operation Manual
Lithium Battery
USB Cable
Line-in Cable
Accessories
CONTENT
LOCATION OF CONTROLS............................................ 1
BATTERY POWER SUPPLY
........................................ 4
....................... 4
ADAPTOR CHARGING ..................................................... 5
CHARGING BY PC............................................................ 5
USING STRAPS............................................................. 6
USING BACKSTAND...................................................... 6
POWER ON/OFF........................................................... 7
FM RADIO
CHOSE BANDS.......................................................... 8
SELECT FREQUENCY RANGE.................................. 8
FM STEREO/MONO SELECTION................................ 9
VOLUME ADJUSTMENT............................................. 9
TUNE IN STATIONS
ANTENNA RECEPTION.............................................. 9
MANUAL/AUTO TUNING.......................................... 10
AUTO TUNING STORAGE(ATS)................................. 10
DIRECTLY INPUT FREQUENCY ................................ 11
STORING STATIONS MANUALLY............................... 12
LISTENING TO STORED MEMORY............................ 12
DELETE SINGLE/ALL MEMORIES............................. 13
FM RDS.................................................................. 14
RECORD RADIO....................................................... 15
LISTEN TO MP3 FILES
PLAY/PAUSE/STOP................................................. 16
SELECT REPEAT MODE.......................................... 16
SELECT EQUALIZER............................................... 16
SELECT TEMPO RATE............................................. 16
LYRICS DISPLAY..................................................... 16
LISTEN TO THE FILES IN THE SD CARD................... 17
DELETE FILES........................................................ 18
REPLACING THE BATTERY
BATTERY CONSUMPTION INDICATION
CHARGING THE BATTERY
CONTENT
A-B REPEAT
REPEAT..................................................................... 19
READ AND CONTRAST............................................... 1 9
USE AS AN ACTIVE LOUDSPEAKER(LINE-IN)........... 20
USE AS LOUDSPEAKER(MIC) ................................... 21
MIC RECORDING
SELECT REC TYPE.................................................... 22
START/PAUSE/STOP.................................................. 22
LISTEN TO RECORDED FILES.................................... 23
WORKING WITH EBOOK............................................. 24
SYSTEM SETTING
TIME SET................................................................... 26
DATE SET.................................................................. 26
CALENDAR INFO........................................................ 26
ALARM SET
NORMAL ALARM SET............................................. 27
ALARM ON............................................................ 28
(MIC RECORD/RADIO/MUSIC AUDIO/RADIO RECORD)
ALARM OFF.......................................................... 28
ALARM ACTIVATED/DEACTIVED............................ 28
BACKLIGHT TIMER.................................................... 29
LANGUAGE SELECTION............................................ 29
SLEEP TIMER............................................................ 29
POWER OFF MODE.................................................... 30
CONTRAST SETTING................................................. 30
MEMORY INFO.......................................................... 30
DATE FORMAT.......................................................... 31
TIME FORMAT........................................................... 31
FIRMWARE UPGRADE............................................... 32
KEY LOCK....................................................................... 33
SPECIFICATION.............................................................. 34
LOCATION OF CONTROLS
1
2 3
Volume -
In Radio Mode: M-
Radio/Music Mode Selection
Power On/Off
Volume +
In Radio Mode: M+
Escape/Main Menu
Tuning Knob: Rotate to Tune,
Press to Confirm/Enter
Display
Built-in MIC
1 1
1 2
1 3
1 4
1 5
1 6
1 7
1 8
1 9
2 02 12 2
2
LOCATION OF CONTROLS
1 3
1 2 FM Stereo/Mono Selection
In A-B Repeat Mode: Repeat
SW Button (press in SW mode to change M Bands)
In Music Mode: Enter Repeat Mode Selection
In A-B Repeat Mode: Contrast
Next Song/FF/Frequency +
Preview Song/REW/Frequency -
1 4
1 6
1 7
1 5
2 2
1 8
1 9
2 0
2 1
Play/Pause
2 3
Mute Button: Turn off speakers
AM Button
In Music Mode: Enter Sound Quality Mode Selection
In A-B Repeat Mode: Read
Speaker: Dual Stereo Speaker
1 1
Confirm/Enter Input
No. Buttons 0~9
Record Button
Hold: Directly Start Recording
Stop Button
MICRO SD Card Slot
Set Button: Enter Submenu
In Radio Mode: Confirm Memory Location Input
In Loudspeaker Mode: Line-in/Mic Signal Selection
3
LOCATION OF CONTROLS
Antenna
Battery Compartment
(Behind the Stand)
Back Stand
Earphone Port
Line-In Port
Tuning Knob
Mini-USB (Power In) Port
Lock/Unlock Radio
Strap Hole
External MIC Port
1. Full
4. Exhausted
2. Medium
3. Low
4
BATTERY POWER SUPPLY
Before initial use, open the battery compartment (behind
the back stand), make sure the lithium battery is installed.
INSTALLING THE BATTERY
1. Turn off the unit and open the battery cover.
2. Install the provided lithium battery according to the battery
polarity.
3. Close the battery cover.
BATTERY CONSUMPTION INDICATION
USB Jack
Left Side
5
CHARGING THE LITHIUM BATTERY
To charge the battery, connect the unit to the mini-USB port
and opposite end to a power source(5V DC/≥500mA, not
provided). While charging, the battery symbol shown on the
display “ ” moves from right to left, and stops when the
battery is full charged.
A computer with a USB jack can also be used as a power
source to charge the battery.
After installing the lithium battery, connect the unit and the
computer with the provided USB cable to charge the battery.
Note: 1. Please turn off the radio while charging the battery
to avoid interference. Do not turn on the unit when
the adaptor output current is less than 500mA.
2. After fully charging the battery, please first disconnect
the USB cable before turn on the radio.
3. Prior to first use, fully charge and drain the battery
three times to extend the battery’s life.
Caution: Do not use the unit when charged by PC, to avoid
damage to PC power.
6
USING STRAPS
USING BACK STAND
Open the stand on the rear of the unit to allow for an
upright position.
USING STRAPS
