Model 720T
Owner's Guide
i
©1999 Directed Electronics, Inc.
Limited Lifetime
Consumer Warranty
For a period of one calendar year from the date of purchase of this auto-security
device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or
replace (with a comparable reconditioned model), free of cost, any electronic control
module which proves to be defective in workmanship or material under normal use,
SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL
AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY
INSTALLED. If warranty service is necessary you must have a clear copy of your sales
receipt containing all of the information shown on the following page.
After the first calendar year, from the date of purchase of this auto-security device,
Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace
(with a comparable reconditioned model) any electronic control module which proves
to be defective in workmanship or material under normal use FOR A CHARGE OF
$45.00, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PRO-
FESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS
ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy
of your sales receipt containing all of the information shown on the following page.
This warranty contains the entire agreement relating to warranty and supersedes all
previous and contemporaneous representations or understandings, whether written or
oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS
CONTENTS.
This warranty is void if the product has been damaged by accident, unreasonable use,
neglect, improper service or other causes not arising out of defects in materials or
construction. This warranty is nontransferable and does not apply to any unit that
has been modified or used in a manner contrary to its intended purpose and does not
cover batteries. The unit in question must be returned to the manufacturer, postage
prepaid. This warranty does not cover labor costs for the removal, diagnosis, trou-
bleshooting or reinstallation of the unit. For service on an out-of-warranty product a
flat rate fee by model is charged. Contact your authorized dealer to obtain the ser-
vice charge for your unit.
These systems are a deterrent against possible theft. Directed Electronics, Inc. is not
offering a guarantee or insuring against the theft of the automobile or its contents
and disclaims any liability for the theft of the vehicle and/or its contents. Directed
Electronics does not authorize any person to create for it any other obligation or lia-
bility in connection with this security system.
ii ©1999 Directed Electronics, Inc.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD-
ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM-
MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU-
SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-
RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF
NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR
ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH
SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT
NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING,
REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL
LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE
ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR
THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or
consequential damages. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
IMPORTANT NOTE:
This product warranty is automatically void if its date code or serial number is
defaced, missing, or altered. This warranty will not be valid unless you have com-
pleted the warranty card and mailed it to Directed Electronics, Inc. within 10 days
after purchase to the address listed on the warranty registration card.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
■Date of purchase
■Your full name and address
■Authorized dealer's company name and address
■Type of system installed
■Year, make, model and color of the automobile
■Automobile license number
■Vehicle identification number
■All security options installed on automobile
■Installation receipts
1
©1999 Directed Electronics, Inc.
Table of Contents
Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
What Is Included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Silent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Panic Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Shock Sensor Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Adjusting the Shock Sensor Warn-Away™. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
To Test and Adjust the Current Warn-Away™Setting. . . . . . . . . . . . . . . . . . . . . 7
Adjusting the Shock Sensor Full Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
To Test and Adjust the Current Full Trigger Setting . . . . . . . . . . . . . . . . . . . . . 8
Code Hopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Security and Convenience Expansion Options . . . . . . . . . . . . . . . . . . . . . . . 10
Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2©1999 Directed Electronics, Inc.
Transmitter Configuration
Arm
Disarm
Panic
Shock Sensor Adjustment
LED
Silent Mode
Shock Sensor Adjustment
3
©1999 Directed Electronics, Inc.
What is Included
■The control module
■A pair of two-button transmitters
■The siren and voice command module, on-board the control
module
■A Stinger®Doubleguard®dual-stage shock/impact sensor, on-
board the control module
■The red status LED indicator light
Important Information
Congratulations on the purchase of your state-of-the-art vehicle
security system. This system has been designed to provide years
of trouble-free operation. This owner’s guide should help you to
get the most out of your system. Please take the time to read it
thoroughly prior to using the system.
This device complies with Part 15 of FCC rules. Operation is subject
to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interfer-
ence received, including interference that may cause undesired
operation.
FCC/ID Notice
4©1999 Directed Electronics, Inc.
Caution: Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate this device.
The system requires no specific maintenance. Your remote control
is powered by a miniature 12V battery, type GP23A, that will last
approximately one year under normal use. When the battery weakens,
operating range will be reduced and the LED on the remote will dim.
Your warranty card must be returned and the bar-code serial num-
ber must not be removed. If the warranty card is not returned you
don’t have a warranty. It is also necessary to keep your proof of
purchase which reflects that the product was installed by an
authorized dealer. Make sure you receive the warranty card from
your dealer.
Transmitter Functions
Button
The arm, disarm and panic functions are controlled by .
Button
Silent Mode™and shock sensor adjustment are controlled by .
Your Warranty
System Maintenance
5
©1999 Directed Electronics, Inc.
Using Your System
You can turn on, or arm, the system by pressing on your trans-
mitter for one second. When the system arms, the voice command
module will announce “SYSTEM ARMED” and the parking lights will
flash once (optional). While the system is armed, the status LED
will flash approximately twice per second, indicating that the sys-
tem is actively protecting your vehicle.
When armed, your vehicle is protected in the following ways:
■Light impacts will trigger the Warn Away™signal. When trig-
gered, the voice command module will announce “PROTECTED
BY SECURITY SYSTEM - STAND BACK” and the parking lights
will flash for a few seconds (optional).
■Heavy impacts will trigger the system. The trigger sequence
is 30 seconds of constant siren and flashing parking lights
(optional).
■The current sensor monitors the electrical system and can
detect an interior light if a door is opened. If the current sen-
sor is being used to detect door entry, the domelight in the
vehicle must be working and left in the “door” position. If
the domelight does not illuminate when a door is opened, the
current sensor cannot detect the entry.
■The optional starter kill prevents the vehicle’s starter from
cranking.
Arming
6©1999 Directed Electronics, Inc.
To turn off, or disarm the system, press again. The voice com-
mand module will announce “SYSTEM DISARMED” and the parking
lights will flash twice (optional).
Your system includes a High Security Disarm feature. During the
trigger sequence, using the remote transmitter to disarm the sys-
tem will only stop the trigger sequence (the siren will stop); how-
ever, the system will remain armed. This is extremely useful if you
must stop the system from sounding, but are unable to visually
check the vehicle. The trigger will stop, but the vehicle will remain
protected.
To disarm the system with the transmitter during a trigger, press
on your transmitter. The siren will stop sounding. Next press
once more and the system will chirp two times and the system
will disarm.
To temporarily turn off the voice command module, use Silent
Mode™. Simply press briefly before arming or disarming, and
the voice confirmation will be eliminated for that one operation
only. If you want the arm/disarm voice command module turned
off permanently, consult with your dealer, or the installation guide.
Silent Mode
High Security Disarm
Disarming
