Dell™ Inspiron™ 580:

Comprehensive Specifications

This document provides information that you may need when setting up,

updating drivers for, and upgrading your computer.

NOTE: Offerings may vary by region. For more information regarding the configuration

of your computer, click Start → Help and Support and select the option to view

information about your computer.

Processor Type

Inspiron 580

•Intel

Pentium

• Intel Core™ i3

•IntelCorei5

Memory

Memory connector four internally-accessible DDR3 DIMM

sockets

Memory-module capacities 1 GB, 2 GB, and 4 GB

Memory type 1066-MHz or 1333-MHz DDR3 DIMM;

non-ECC memory only

Memory configurations supported 4 GB, 6 GB, and 8 GB

NOTE: Memory configurations of more

than 4 GB require a 64-bit operating

system.

Computer Information

System chipset Intel H57

MiniSkywalker mini Comprehensive Specs .fm Page 1 Thursday, December 3, 2009 3:58 PM

Drives

Externally accessible

• two 5.25-inch bays for SATA

DVD-ROM, SATA DVD+/-RW Super

Multi Drive, or Blu-ray Disc™ combo

drive

• one 3.5-inch FlexBay for an optional

Media Card Reader

Internally accessible two 3.5-inch bays for SATA hard drives

External Connectors

Audio front panel — one headphone and one

microphone connector

back panel — six connectors for

7.1 channel support

Network adapter one RJ45 connector

USB two front panel and four back panel

USB 2.0-compliant connectors

Video one 15-pin VGA connector and

one 19-pin HDMI connector

System Board Connectors

Memory four 240-pin connectors

PCI one 124-pin connector

PCI Express x1 two 36-pin connector

PCI Express x16 one 164-pin connector

Power (System board) one 24-pin EPS 12V connector

(ATX-compatible)

Processor fan one 4-pin connector

Chassis fan one 3-pin connector

Front/Internal USB connector two 9-pin connectors

Front audio connector one 9-pin connector for 2-channel stereo

sound and microphone

SATA four 7-pin connectors

MiniSkywalker mini Comprehensive Specs .fm Page 2 Thursday, December 3, 2009 3:58 PM

Communications

Modem (optional) PCI modem

Wireless (optional) PCI Express WiFi card supporting

802.11a/b/g/n

Video

Integrated Intel GMA HD

Discrete PCI Express x16 card (optional)

Audio

Audio type integrated 7.1 channel, High Definition

Audio

Expansion Slots

PCI

Connectors

one

Connector size

124-pin

Connector data width (maximum)

32 bit

Bus speed

33 MHz

PCI Express x1

Connectors

two

Connector size

36-pin

Connector data width (maximum)

1 PCI Express lane

Bus speed

500 MB/s (bi-directional)

PCI Express x16

Connectors

one

Connector size

164-pin

Connector data width (maximum)

16 PCI Express lanes

Bus speed

16 GB/s (bi-directional)

MiniSkywalker mini Comprehensive Specs .fm Page 3 Thursday, December 3, 2009 3:58 PM

Battery

Coin-cell battery 3-V CR2032 lithium

Power

Wattage 300 W

Maximum heat dissipation 1574 BTU/Hr

Input voltage 115/230 VAC

Input frequency 50/60 Hz

Rated output current 7/4 A

Physical

Height 375.3 mm (14.77 inches)

Width 175.9 mm (6.92 inches)

Depth 440.4 mm (17.34 inches)

Weight (starting at) 8.7 kg (19.2 lb)

Computer Environment

Temperature range

Operating

10°C to 35°C (50°F to 95°F)

Storage

–40° to 65° C(–40° to 149°F)

Relative humidity (maximum) 20% to 80% (non-condensing)

Maximum vibration (using a random vibration spectrum that simulates user

environment)

Operating

0.25 GRMS

Non-Operating

2.2 GRMS

MiniSkywalker mini Comprehensive Specs .fm Page 4 Thursday, December 3, 2009 3:58 PM

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is

strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and Inspiron are trademarks of Dell Inc.; Intel and

Pentium are registered trademarks and Core is a trademark of Intel Corporation in the U.S. and other

countries; Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation

in the United States and/or other countries; Blu-ray Disc is a trademark of the Blu-ray Disc Association.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade

names other than its own.

Model: DCMF December 2009 Rev. A00

Maximum shock (for operating — measured with Dell Diagnostics running on the

hard drive and a 2-ms half-sine pulse; for non-operating — measured with hard

drive in head-parked position and a 2-ms half-sine pulse)

Operating

40G for 2 ms with a change in velocity of

20 in/s (51 cm/s)

Non-Operating

50G for 26 ms with a change in velocity

of 320 in/s (813 cm/s)

Altitude (maximum)

Operating

–15.2 to 3048 m (–50 to 10,000 ft)

Storage

–15.2 to 10,668 m (–50 to 35,000 ft)

Airborne contaminant level G2 or lower as defined by

ISA-S71.04-1985

Computer Environment

(continued)

MiniSkywalker mini Comprehensive Specs .fm Page 5 Thursday, December 3, 2009 3:58 PM
