About Warning

WARNING: A WARNING indicates a potential for property damage, personal injury, or

death.

Dell OptiPlex And Dell Precision

System Board Mode Configuration

Introduction

This tech sheet covers the configuration process required after installing a new

system board in your Dell desktop computer. Follow these instructions carefully

to make sure that the computer is configured for the correct management mode.

1

Remove the computer cover to read the label that is attached to the inside of

the cover.

You will see the configuration-mode label like one below. Numbers or options

will vary depending on the order when you purchased the computer.

chassis cover

inside

label

. . .

6

AMT ME Lockout

J0TTM

03 - 2011

body.fm Page 9 Monday, March 7, 2011 2:44 PM

FILE LOCATION: C:\Projects\aa_Working\iAMT Guide\iAMT7\R418K\body.fm

DELL CONFIDENTIAL – PRELIMINARY 3/7/11 – FOR PROOF ONLY

NOTE: If the original configuration-mode label is damaged, or otherwise illegible,

contact Dell to obtain your configuration-mode number (see your computer

documentation for contact information).

2

Note the large mode number on the label. This number is important for step 7

of this procedure and you may want to write it down.

3

Replace the system board. For more information, see your system

documentation on

support.dell.com

.

4

Replace the computer cover. For more information, see your system

documentation on

support.dell.com

.

5

Disconnect any USB mass storage devices (such as hard drives or flash keys).

6

Disconnect the network cable.

7

Turn the computer on. When the initialization screen appears, enter the

mode number you obtained from the label inside the chassis.

WARNING: Once selected, you cannot change the management mode. If you make

the wrong selection, your computer may not operate as it should.

8

When a prompt appears to continue with your selection, enter

Y

if

yes

.

After the initialization completes, the computer shuts down.

9

Reconnect any USB mass storage devices (such as hard drives or flash keys).

10

Reconnect the network cable.

11

Restart the computer.
