Dell XPS 8700 Manuale utente

Trademarks used in this text: Dell™, the DELL logo, and XPS™are trademarks of Dell Inc.

Intel®is a registered trademark and Core™is a trademark of Intel Corporation in the U.S. and other countries.

Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under license.

2013 ‑ 10 Rev. A00

Regulatory model: D14M | Type: D14M001

Computer model: XPS 8700

Specifications

8700

Dimensions

Height (front and back) 406.80 mm (16.0 inches)

Width 185.34 mm (7.3 inches)

Depth 444.26 mm (17.5 inches)

Average Weight 13.8 kg (30.42 lb)

NOTE: The weight of your computer may vary

depending on the configuration ordered and

the manufacturing variability.

System Information

Model XPS 8700

Processor Intel Core i5 (4th Generation)

Intel Core i7 (4th Generation)

L2 cache 256 KB

L3 cache up to 8 MB

System chipset Intel Z87

DMI speed 5.0 GT/s

Processor data width 64 bits

RAID support (internal SATA

drives only)

RAID 0, RAID 1, RAID 5 and RAID 10

Memory

Connectors four internally‑accessible DDR3L DIMM sockets

Type unbuffered, Non‑ECC, quad‑channel DDR3

Speed up to 1600 MHz

Capacities 4 GB and 8 GB

Configurations supported 4 GB, 8 GB, 12 GB, 16 GB, 24 GB and 32 GB

Minimum 4 GB

Maximum 32 GB

Ports

Back Panel Ports

Network adapter one RJ45 port

USB • two USB 2.0 ports

• four USB 3.0 ports

Audio • four audio output/headphone ports

• one audio input port

• one microphone port

Video • one DisplayPort

• one HDMI port

Front Panel Ports

USB • two USB 3.0 ports

Top Panel Ports

USB • one USB 2.0 port

• one USB 2.0 port with PowerShare

Audio • one audio output/headphone port

• one microphone port

Communications

Network adapter 10/100/1000 Mbps integrated network card

Wireless Wi‑Fi and Bluetooth wireless technology

Video

Video controller

Discrete one PCI‑Express x16, single‑width, full length

graphics card

Video Memory

Discrete upto 2 GB (GDDR5)

Audio

Type integrated high‑definition 7.1 channel audio

Controller REALTEK ALC3861

Storage

Interface • SATA 3.0

• mSATA

Hard drives three

Drives supported three 3.5‑inch hard drives

Solid‑state drives (SSD)

(optional)

one

Drives supported one mSATA SSD

Optical drives two

Drives supported • DVD+/‑RW

• Blu‑ray reader

• Blu‑ray disc writer

Media-card reader

Type one 19‑in‑1 slot

Cards supported • Compact Flash I, II

• Compact Flash MD

• Secure Digital (SD)

• Secure Digital mini SD

• Secure Digital HC Class 2, 4, 6

• Multi Media Card (MMC)

• Multi Media Card Plus

• RS MMC

• Multi Media Card (MMC) Mobile

• Secure Digital Extended Capacity (SDXC)

• Memory Stick (MS)

• Memory Stick Pro

• Memory Stick Duo

• Memory Stick Pro Duo

• Memory Stick Pro‑HG Duo

• Memory Stick XC

• Smart Media

• Smart Media xD

Expansion Bus

PCI Express x1:

Connectors two

Connector size 36‑pin

PCI Express x4:

Connectors one

Connector size 64‑pin

PCI Express x16:

Connectors one

Connector size 164‑pin

PCI Express mini‑card

Connectors two

Connector size 52‑pin

Power

Input voltage 100‑240 VAC

Input frequency 50 Hz/60 Hz

Rated input current 8.0 A/4.0 A

Computer Environment

Temperature range

Operating 10 °C to 35 °C (50 °F to 95 °F)

Storage –10 °C to 45 °C (14 °F to 113 °F)

Relative humidity (maximum) 20% to 80% (noncondensing)

NOTE: Maximum vibration (using a random vibration spectrum that simulates

user environment)

Operating 0.25 GRMS

Storage 2.20 GRMS

NOTE: Maximum shock (Measured with hard drive in operating status and

a 2‑ms half‑sine pulse for operating. Also measured with hard drive in

head‑parked position and a 2‑ms half‑sine pluse for storage)

Operating 40 G for 2 ms with a change in velocity of

20in/s (51 cm/s)

Storage 50 G for 26 ms with a change in velocity of

320in/s (813 cm/s)

Altitude (maximum)

Operating –15.20 m to 5000 m (–50 ft to 16,404 ft)

Storage –15.20 m to 10,668 m (–50 ft to 35,000 ft)

Airborne contaminant level G2 or lower as defined by ISA‑S71.04‑1985
