Dell INSPIRATION 15 Manuale utente

Views

Specifications

and/or other jurisdictions. All other marks and names mentioned herein may be trademarks of their respective

companies.

2014 - 01 Rev. A03

Regulatory model: P28F | Type: P28F001/P28F003

Computer model: Inspiron 3521/3537

NOTE: The images in this document may differ from your computer

depending on the configuration you ordered.

1511

Dell - Internal Use - Confidential

1 Power-status light

Indicates the power state of the computer.

White light — Power adapter is connected and the

battery is fully charged.

2 Hard-drive activity light

Turns on when the computer reads from or writes to the

hard drive.

3 Battery-status light

Indicates the battery state of the computer.

Solid yellow light — Battery charge is low.

Blinking yellow light — Battery charge is critical.

4 Wireless-status light

Turns on when wireless is turned on.

5 Media-card reader

Reads from and writes to media cards.

3 4 5

Views

Specifications

Front

Left

Right

Base

Display

Front

1 Power-adapter port

Connect a power adapter to provide power to your

computer and charge the battery.

2 HDMI port

Connect a TV or another HDMI-in enabled device.

Provides video and audio output.

3 Network port

Connect an Ethernet (RJ45) cable from a router or a

broadband modem for network or internet access.

The two lights next to the connector indicate the

connectivity status and network activity.

4 USB 3.0 ports (2)

Connect peripherals such as storage devices, printers,

and so on. Provide data transfer speeds up to 5 Gbps.

5 USB 2.0 port

Connect peripherals such as storage devices, printers,

and so on. Provides data transfer speeds up to

480 Mbps.

6 Headset port

Connect a headphone, a microphone, or a headphone

and microphone combo (headset).

1 2 3 4 5 6

Views

Specifications

Front

Left

Right

Base

Display

Left

1 USB 2.0 port (supports Windows debugging)

Connect peripherals such as storage devices, printers,

and so on. Provides data transfer speeds up to

480 Mbps.

This USB port can be used for Windows debugging.

2 Optical drive

Reads from and writes to CDs and DVDs.

3 Security-cable slot

Connect a security cable to prevent unauthorized

movement of your computer.

321

Views

Specifications

Front

Left

Right

Base

Display

Right

1 Power button

Press to turn on the computer if it is turned off or in

Sleep state.

Press to put the computer in Sleep state if it is turned on.

Press and hold for 10 seconds to force shut-down the

computer.

NOTE: You can customize the power-button behavior in Power

Options. For more information, see Me and My Dell at

dell.com/support.

2 Left-click button

Press to left click.

3 Touchpad

Move your finger on the touchpad to move the mouse

pointer. Tap to left-click.

4 Right-click button

Press to right click.

Views

Specifications

Front

Left

Right

Base

Display

Base

1 Digital microphone

Provides high-quality digital sound input for audio

recording, voice calls, and so on.

2 Camera

Allows you to video chat, capture photos, and record

videos.

3 Camera-status light

Turns on when the camera is in use.

21 3

Views

Specifications

Front

Left

Right

Base

Display

Specifications

Views

Battery

System

Information Memory Ports and

Connectors

Dimensions and

Weight

Computer

Environment

Storage

Touchpad Power AdapterCamera

Communications Video Audio

Display

Media-card

reader Keyboard

Dimensions and Weight

Non-touch Touch

Height (front to back):

With 4-cell battery 0.98 in to 1.09 in

(24.85 mm to 27.60 mm)

1.07 in to 1.19 in

(27.25 mm to 30.15 mm)

With 6-cell battery 0.98 in to 1.25 in

(24.85 mm to 31.80 mm)

1.07 in to 1.37 in

(27.25 mm to 34.80 mm)

Width 14.80 in (376 mm)

Depth 10.20 in (259 mm)

Weight (maximum):

With 4-cell battery 4.85 lb (2.20 kg) 5.51 lb (2.50 kg)

With 6-cell battery 5.18 lb (2.35 kg) 5.84 lb (2.65 kg)

NOTE: The weight of your laptop varies depending on the configuration ordered

and the manufacturing variability.

Specifications

Views

Battery

System

Information Memory Ports and

Connectors

Dimensions and

Weight

Computer

Environment

Storage

Touchpad Power AdapterCamera

Communications Video Audio

Display

Media-card

reader Keyboard

System Information

Inspiron 3521 Inspiron 3537

Computer model Inspiron 3521 Inspiron 3537

Processor • Intel Celeron Dual Core

(2nd generation)

• Intel Pentium Dual Core

(2nd generation)

• Intel Core i3 ULV (3rd generation)

• Intel Core i5 ULV (3rd generation)

• Intel Core i7 ULV (3rd generation)

• Intel Celeron Dual Core

(4th generation)

• Intel Pentium Dual Core

(4th generation)

• Intel Core i3 ULV (4th generation)

• Intel Core i5 ULV (4th generation)

• Intel Core i7 ULV (4th generation)

L1 cache 64 KB per core

L2 cache 256 KB per core

L3 cache Up to 4 MB

Chipset Intel HM76 Integrated in processor

www

Specifications

Views

Battery

System

Information Memory Ports and

Connectors

Dimensions and

Weight

Computer

Environment

Storage

Touchpad Power AdapterCamera

Communications Video Audio

Display

Media-card

reader Keyboard

Memory

Connectors Two internally-accessible SODIMM connectors

Type:

Inspiron 3521 Dual-channel DDR3

Inspiron 3537 Dual-channel DDR3L

Speed Up to 1600 MHz

Configurations supported 2 GB, 4 GB, 6 GB, 8 GB, and 16 GB

Specifications

Views

Battery

System

Information Memory Ports and

Connectors

Dimensions and

Weight

Computer

Environment

Storage

Touchpad Power AdapterCamera

Communications Video Audio

Display

Media-card

reader Keyboard

Ports and Connectors

External:

Network One RJ45 port

USB • Two USB 3.0 ports

• One USB 2.0 port

• One USB 2.0 port with Windows debugging

HDMI One HDMI port

Audio One headphone and microphone combo (headset) port

Internal:

Mini-card One full mini-card slot for Wi-Fi and Bluetooth combo card
