Dell™ Inspiron™ 1464
Comprehensive Specifications
This document provides information that you may need when setting up,
updating drivers for, and upgrading your computer.
NOTE: Offerings may vary by region. For more information regarding the configuration
of your computer, click Start → Help and Support and select the option to view
information about your computer.
Processor
Ty p e I n t e l ®Core™ i5
Intel Core i3
L1 cache 32-KB instruction and 32-KB data
first-level cache for each core
L2 cache 256-KB shared instruction/data
second-level cache for each core
L3 cache Up to 4-MB shared instruction/data
third-level cache shared among all cores
Computer Information
System chipset Intel HM55
Data bus width 64 bits
DRAM bus width 64 bits
Flash EPROM 4 MB
December 2009
Mikkelsen CS.fm Page 1 Tuesday, December 8, 2009 6:07 PM
Memory Card Reader
Card reader controller Realtek RTS5159
Card reader connector 7-in-1 combo card reader
Flash cards supported
• Secure Digital (SD) memory card
• Secure Digital High Capacity (SDHC)
memory card
• Multi Media Card (MMC)
• MMC+
•MemoryStick
•MemoryStickPro
• xD-Picture Card (type - M and
type - H
Memory
Memory connectors two internally-accessible SODIMM
connectors
Memory capacities 1 GB, 2 GB, and 4 GB
Memory type DDR3 1066 MHz
Memory configurations 2 GB, 3 GB, 4 GB, 6 GB, and 8 GB
NOTE: For instructions on upgrading memory, see the Service Manual at
support.dell.com/manuals.
Connectors
Audio one microphone-in connector
one stereo headphone/speaker connector
Mini-Card one half-size Mini-Card connector
HDMI one 19-pin connector
Network adapter one RJ45 connector
USB three 4-pin USB 2.0-compliant
connectors
Video one 15-hole connector
Mikkelsen CS.fm Page 2 Tuesday, December 8, 2009 6:07 PM
Communications
Network adapter 10/100 Ethernet LAN on system board
Wireless internal WLAN Mini-Card with WiFi
802.11a/b/g/n, and Bluetooth®wireless
technology
Video
Discrete video type integrated on system board
Discrete video controller and memory ATI M92-LP 512 MB DDR3
ATI Park 1 GB DDR3
UMA video type integrated on system board
UMA video controller Intel Graphics Media Accelerator HD
UMA video memory up to 1752 MB of shared memory
LCD interface Low-voltage differential signaling
(LVDS)
Audio
Audio type 2-channel High Definition
Audio controller Realtek ALC269Q-GR
Stereo conversion 24-bit (analog-to-digital and digital-to-
analog)
Internal interface Intel High Definition audio
Speakers 2 x 2 watt speakers
Volume controls keyboard function keys
Camera
Camera resolution 1.3 megapixel
Video resolution 640 x 480 at 30 fps (maximum)
Diagonal viewing angle 66°
Mikkelsen CS.fm Page 3 Tuesday, December 8, 2009 6:07 PM
Display
Type 14.0-inch HD WLED with TrueLife
Height 173.95 mm (6.85 inches)
Width 309.4 mm (12.2 inches)
Diagonal 355.6 mm (14.0 inches)
Luminance 220/200 nits
Maximum resolution 1366 x 768
Refresh rate 60 Hz
Operating angle 0° (closed) to 140°
Horizontal viewing angle 40/40
Vertical viewing angle 15/30 (H/L)
Pixel pitch 0.252 x 0.252 mm
Controls brightness can be controlled through
keyboard shortcuts (see the Dell
Te c h n o l og y G u i d e for more information)
Keyboard
Number of keys 86 (U.S. and Canada); 87 (Europe); 90
(Japan)
Layout QWERTY/AZERTY/Kanji
Touch Pad
X/Y position resolution (graphics table
mode)
240 cpi
Width 79.7 mm (3.13 inches) sensor-active area
Height 47.7 mm (1.87 inches) rectangle
Mikkelsen CS.fm Page 4 Tuesday, December 8, 2009 6:07 PM
Battery
6-cell “smart” lithium ion
Depth
53.12 mm (2.09 inches)
Height
22.3 mm (0.88 inches)
Width
274.5 mm (10.8 inches)
Weight
0.35 kg (0.77 lb)
9-cell “smart” lithium ion
Depth
53.12 mm (2.09 inches)
Height
42.9 mm (1.69 inches)
Width
274.5 mm (10.8 inches)
Weight
0.56 kg (1.23 lb)
Voltage 11.1 VDC
Charge time (approximate) 4 hours when the computer is turned off
Life span (approximate) 300 discharge/charge cycles
Temperature range
Operating
0° to 35° C (32° to 95°F)
Storage
-40° to 65° C (-40° to 149°F)
Coin-cell battery CR-2032
AC Adapter
Input voltage 100–240 VAC
Input current 1.5 A
Input frequency 50–60 Hz
Output power 65 W or 90 W
Output current 3.34 A (65 W) (continuous)
4.62 A (90 W) (continuous)
Rated output voltage 19.5 ±1 VDC
Mikkelsen CS.fm Page 5 Tuesday, December 8, 2009 6:07 PM
Temperature range
Operating
0° to 35°C (32° to 95°F)
Storage
–40° to 65°C (–40° to 149°F)
Physical
Height 20.8 mm to 32.8 mm (0.82 inches to 1.3
inches)
Width 340.0 mm (13.4 inches)
Depth 242.5 mm (9.5 inches)
Weight (with 6-cell battery) configurable to less than 2.24 kg (4.9 lb)
Computer Environment
Temperature range
Operating
0° to 35°C (32° to 95°F)
Storage
–40° to 65°C (–40° to 149°F)
Relative humidity (maximum)
Operating
10% to 90% (non-condensing)
Storage
5% to 95% (non-condensing)
Maximum vibration (using a random vibration spectrum that simulates user
environment)
Operating
0.66 GRMS
Non-Operating
1.30 GRMS
Maximum shock (for operating — measured with Dell Diagnostics running on the
hard drive and a 2-ms half-sine pulse; for non-operating — measured with the hard
drive in head-parked position and a 2-ms half-sine pulse)
Operating
110 G
Non-Operating
160 G
AC Adapter
(continued)
Mikkelsen CS.fm Page 6 Tuesday, December 8, 2009 6:07 PM
____________________
Information in this document is subject to change without notice.
© 2009 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is
strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and Inspiron are trademarks of Dell Inc.; Intel is a
registered trademark and Core is a trademark of Intel Corporation in the U.S. and other countries; Microsoft,
Windows, and the Windows Vista start button logo are either trademarks or registered trademarks of
Microsoft Corporation in the United States and/or other countries; Bluetooth is a registered trademark
owned by Bluetooth SIG, Inc. and is used by Dell under license.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the
marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade
names other than its own.
Regulatory Model: P09G series Regulatory Type: P09G001 December 2009 Rev: A00
Altitude (maximum)
Operating
–15.2 to 3048 m (–50 to 10,000 ft)
Storage
–15.2 to 10,668 m (–50 to 35,000 ft)
Airborne contaminant level G2 or lower as defined by ISA-S71.04-
1985
Computer Environment
(continued)
Mikkelsen CS.fm Page 7 Tuesday, December 8, 2009 6:07 PM
