Dell Inspiron 1564 Manuale utente

Dell™ Inspiron™ 1564

Comprehensive Specifications

This document provides information that you may need when setting up,

updating drivers for, and upgrading your computer.

NOTE: Offerings may vary by region. For more information regarding the configuration

of your computer, click Start → Help and Support and select the option to view

information about your computer.

Processor

Ty p e I n t e l ®Core™ i5

Intel Core i3

L1 cache 32-KB instruction and 32-KB data first-

level cache for each core

L2 cache 256-KB shared instruction/data second-

level cache for each core

L3 cache Up to 4-MB shared instruction/data

third-level cache shared among all cores

Computer Information

System chipset Intel HM55

Data bus width 64 bits

DRAM bus width 64 bits

Flash EPROM 4 MB

December 2009

Pryce CS.fm Page 9 Thursday, December 17, 2009 4:29 PM

Memory Card Reader

Card reader controller Realtek RTS5159

Card reader connector 7-in-1 combo card reader

Flash cards supported

• Secure Digital (SD) memory card

• Secure Digital High Capacity (SDHC)

memory card

• Multi Media Card (MMC)

• MMC+

•MemoryStick

•MemoryStickPro

• xD-Picture Card (type - M and

type - H)

Memory

Memory connectors two internally-accessible SODIMM

connectors

Memory capacities 1 GB, 2 GB, and 4 GB

Memory type DDR3 1066 MHz

Memory configurations 2 GB, 3 GB, 4 GB, 6 GB, and 8 GB

NOTE: For instructions on upgrading memory, see the Service Manual at

support.dell.com/manuals.

Connectors

Audio one microphone-in connector

one stereo headphone/speaker connector

Mini-Card one half-size Mini-Card connector

HDMI one 19-pin connector

Network adapter one RJ45 connector

USB three 4-pin USB 2.0-compliant

connectors

Video one 15-hole connector

Pryce CS.fm Page 10 Thursday, December 17, 2009 4:29 PM

Communications

Modem interface (optional) External V.92 56K USB modem

Network adapter 10/100 Ethernet LAN on system board

Wireless internal WLAN Mini-Card with WiFi

802.11a/b/g/n, and Bluetooth®wireless

technology

Video

Discrete video type integrated on system board

Discrete video controller and memory ATI M92-LP 512 MB DDR3

ATI Park 1 GB DDR3

UMA video type integrated on system board

UMA video controller Intel HD Graphics

UMA video memory up to 1752 MB of shared memory

LCD interface Low-voltage differential signaling

(LVDS)

Audio

Audio type 2-channel High Definition

Audio controller Realtek ALC269Q-GR

Stereo conversion 24-bit (analog-to-digital and digital-to-

analog)

Internal interface Intel High Definition audio

Speakers 2 x 2 watt speakers

Volume controls keyboard function keys

Camera

Camera resolution 1.3 megapixel

Video resolution 640 x 480 at 30 fps (maximum)

Diagonal viewing angle 66°

Pryce CS.fm Page 11 Thursday, December 17, 2009 4:29 PM

Display

Type 15.6-inch HD WLED with TrueLife

Height 193.54 mm (7.62 inches)

Width 344.23 mm (13.55 inches)

Diagonal 396.42 mm (15.6 inches)

Luminance 220/200 nits

Maximum resolution 1366 x 768

Refresh rate 60 Hz

Operating angle 0° (closed) to 140°

Horizontal viewing angle 40/40

Vertical viewing angle 15/30 (H/L)

Pixel pitch 0.252 x 0.252 mm

Controls brightness can be controlled through

keyboard shortcuts (see the Dell

Te c h n o l og y G u id e for more information)

Keyboard

Number of keys 102 (U.S. and Canada): 103 (Europe);

106 (Japan); 105 (Brazil)

Layout QWERTY/AZERTY/Kanji

Touch Pad

X/Y position resolution (graphics table

mode)

240 cpi

Width 79.7 mm (3.13 inches) sensor-active area

Height 47.7 mm (1.87 inches) rectangle

Pryce CS.fm Page 12 Thursday, December 17, 2009 4:29 PM

Battery

6-cell “smart” lithium ion

Depth

53.1 mm (2.09 inches)

Height

22.3 mm (0.88 inches)

Width

274.5 mm (10.8 inches)

Weight

0.35 kg (0.77 lb)

9-cell “smart” lithium ion

Depth

53.12 mm (2.09 inches)

Height

42.9 mm (1.69 inches)

Width

314.45 mm (12.38 inches)

Weight

0.52 kg (1.15 lb)

Voltage 11.1 VDC

Charge time (approximate) 4 hours when the computer is turned off

Life span (approximate) 300 discharge/charge cycles

Temperature range

Operating

0° to 35° C (32° to 95°F)

Storage

–40° to 65° C (–40° to 149°F)

Coin-cell battery CR-2032

AC Adapter

Input voltage 100–240 VAC

Input current 1.5 A

Input frequency 50–60 Hz

Output power 65 W or 90 W

Output current 3.34 A (65 W) (continuous)

4.62 A (90 W) (continuous)

Pryce CS.fm Page 13 Thursday, December 17, 2009 4:29 PM

Rated output voltage 19.5 ±1 VDC

Temperature range

Operating

0° to 35°C (32° to 95°F)

Storage

–40° to 65°C (–40° to 149°F)

Physical

Height 20.0 mm to 32.8 mm (0.78 inches to 1.3

inches)

Width 380.0 mm (14.96 inches)

Depth 248 mm (9.76 inches)

Weight (with 6-cell battery) configurable to less than 2.54 kg (5.6 lb)

Computer Environment

Temperature range

Operating

0° to 35°C (32° to 95°F)

Storage

–40° to 65°C (–40° to 149°F)

Relative humidity (maximum)

Operating

10% to 90% (non-condensing)

Storage

5% to 95% (non-condensing)

Maximum vibration (using a random vibration spectrum that simulates user

environment)

Operating

0.66 GRMS

Non-Operating

1.30 GRMS

AC Adapter

(continued)

Pryce CS.fm Page 14 Thursday, December 17, 2009 4:29 PM

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is

strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and Inspiron are trademarks of Dell Inc.; Intel is a

registered trademark and Core is a trademark of Intel Corporation in the U.S. and other countries; Microsoft,

Windows, and the Windows Vista start button logo are either trademarks or registered trademarks of

Microsoft Corporation in the United States and/or other countries; Bluetooth is a registered trademark

owned by Bluetooth SIG, Inc. and is used by Dell under license.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade

names other than its own.

Regulatory Model: P08F series Regulatory Type: P08F001 December 2009 Rev: A00

Maximum shock (for operating — measured with Dell Diagnostics running on the

hard drive and a 2-ms half-sine pulse; for non-operating — measured with the hard

drive in head-parked position and a 2-ms half-sine pulse)

Operating

110 G

Non-Operating

160 G

Altitude (maximum)

Operating

–15.2 to 3048 m (–50 to 10,000 ft)

Storage

–15.2 to 10,668 m (–50 to 35,000 ft)

Airborne contaminant level G2 or lower as defined by ISA-S71.04-

1985

Computer Environment

(continued)

Pryce CS.fm Page 15 Thursday, December 17, 2009 4:29 PM
