Dell XPS 11 Manuale utente

XPS 11

Service Manual

Computer model: XPS 9P33

Regulatory model: P16T

Regulatory type: P16T001

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better

use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Trademarks used in this text: Dell™, the DELL logo, and XPS™ are trademarks of Dell Inc.

2013 - 10 Rev. A00

Contents | 3

Contents

Before Working Inside Your Computer 5

Before You Begin 5

Recommended Tools 5

Safety Instructions 6

After Working Inside Your Computer 7

Removing the Base Cover 8

Procedure 8

Replacing the Base Cover 10

Procedure 10

Removing the Battery 11

Prerequisites 11

Procedure 11

Replacing the Battery 12

Procedure 12

Postrequisites 12

Removing the Wireless Card 13

Prerequisites 13

Procedure 13

Replacing the Wireless Card 14

Procedure 14

Postrequisites 14

Removing the mSATA Card 15

Prerequisites 15

Procedure 15

Replacing the mSATA Card 16

Procedure 16

Postrequisites 16

4| Contents

Removing the Fan 17

Prerequisites 17

Procedure 17

Replacing the Fan 18

Procedure 18

Postrequisites 18

Removing the Display Assembly 19

Prerequisites 19

Procedure 19

Replacing the Display Assembly 23

Procedure 23

Postrequisites 23

Removing the System Board 24

Prerequisites 24

Procedure 24

Replacing the System Board 30

Procedure 30

Postrequisites 30

Entering the Service Tag in the BIOS 30

Removing the Palm-Rest Assembly 31

Prerequisites 31

Procedure 31

Replacing the Palm-Rest Assembly 33

Procedure 33

Postrequisites 33

Flashing the BIOS 34

Before Working Inside Your Computer | 5

Before Working Inside Your Computer

Before You Begin

CAUTION: To avoid data loss, save and close all open files and exit all open

programs before turning off your computer.

1Save and close all open files, exit all open programs, and turn off your computer.

Point to the lower or upper-right corner of the screen to open the charms sidebar

and click Settings→Power→Shut down.

NOTE: If you are using a different operating system, see the documentation of

your operating system for shut-down instructions.

2After the computer shuts down, disconnect it from the electrical outlet.

3Disconnect all cables — such as power and USB cables — from your computer.

4Disconnect all peripherals, including media cards, connected to your computer.

Recommended Tools

The procedures in this document require the following tools:

•Phillips screwdriver

•Torx #5 (T5) screwdriver

•Plastic scribe

6| Before Working Inside Your Computer

Safety Instructions

Use the following safety guidelines to protect your computer from potential damage and

ensure your personal safety.

WARNING: Before working inside your computer, read the safety

information that shipped with your computer. For more safety best practices,

see the Regulatory Compliance home page at dell.com/regulatory_compliance.

WARNING: Disconnect all power sources before opening the computer

cover or panels. After you finish working inside the computer, replace all covers,

panels, and screws before connecting to the power source.

CAUTION: Only a certified service technician is authorized to remove the

computer cover and access any of the components inside the computer. See the

safety instructions for complete information about safety precautions, working

inside your computer, and protecting against electrostatic discharge.

CAUTION: To avoid damaging the computer, make sure that the work surface is

flat and clean.

CAUTION: Before touching anything inside your computer, ground yourself

by touching an unpainted metal surface, such as the metal at the back of the

computer. While you work, periodically touch an unpainted metal surface to

dissipate static electricity, which could harm internal components.

CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,

not on the cable itself. Some cables have connectors with locking tabs or

thumb-screws that you must disengage before disconnecting the cable.

When disconnecting cables, keep them evenly aligned to avoid bending any

connector pins. When connecting cables, make sure that the ports and

connectors are correctly oriented and aligned.

CAUTION: To avoid damaging the components and cards, handle them by

their edges and avoid touching pins and contacts.

CAUTION: Press and eject any installed card from the media-card reader.

After Working Inside Your Computer | 7

After Working Inside Your Computer

CAUTION: Leaving stray or loose screws inside your computer may severely

damage your computer.

1Replace all screws and make sure that no stray screws remain inside your

computer.

2Connect any cables, peripherals, and other parts you removed before working on

your computer.

3Connect your computer to the electrical outlet.

4Turn on your computer.

8| Removing the Base Cover

Removing the Base Cover

WARNING: Before working inside your computer, read the safety information

that shipped with your computer and follow the steps in "Before Working Inside

Your Computer" on page 5. After working inside your computer, follow the

instructions in "After Working Inside Your Computer" on page 7.

For more safety best practices, see the Regulatory Compliance home page at

dell.com/regulatory_compliance.

Procedure

1Close the display, and turn the computer over.

2Release the system badge and turn it over.

1base cover 2system badge

Removing the Base Cover | 9

3Remove the screws that secure the base cover to the palm-rest assembly.

4Loosen the captive screws that secure the base cover to the palm-rest assembly.

5Place the computer with the rear side facing you, and gently pry up the base cover.

1screws (Torx) (6) 2base cover

3captive screws (4) 4screw (Phillips)

10 | Replacing the Base Cover

Replacing the Base Cover

WARNING: Before working inside your computer, read the safety information

that shipped with your computer and follow the steps in "Before Working Inside

Your Computer" on page 5. After working inside your computer, follow the

instructions in "After Working Inside Your Computer" on page 7.

For more safety best practices, see the Regulatory Compliance home page at

dell.com/regulatory_compliance.

Procedure

1Place the base cover on the palm-rest assembly and snap the base cover into place.

2Tighten the captive screws that secure the base cover to the palm-rest assembly.

3Replace the screws that secure the base cover to the palm-rest assembly.

4Turn the system badge over and snap it into place.
