Dell E2219HN Manuale utente

1

22" LCD Color Monitor

Service

Service

Service

SAFETY NOTICE

ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE

CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING

ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.

CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

Dell E2219HN

6

Tools: 2 Power screwdrivers (φ=5mm,L=60mm); 1 small cross screwdriver; turnbuckle driver;

Setting: Power screwdriver torque A=12 kgF. Cm; torque B=6 kgF. Cm; torque C=4 kgF. Cm torque

D=0.7 kgF. Cm.

Note: Firstly, put the monitor on a soft, flat and clean surface, wear gloves.

Step Figure

Description

Remove

screws.

1. Place the machine

flat on the work table.

2. Remove rear cover

screws.

Remove the

rear cover.

Remove the

screws & tear

the tape and

tear the foil.

1. Remove the foil on

the shieldplate.

2. Remove the six

corners screw.

3. Remove the tape o

f

the fixed wire.

Pull the line.

1. Unplug the backlight

line and the function

key line.

2. Pull off the wire

tape, then pull the line

out.

Mechanical Instruction

7

Remove the

shieldplate.

1. Remove the

shieldplate.

2. Remove the mylar.

Remove the

PCB.

1. Remove the tape

for the fixed wire.

2. Remove screws.

Remove the

PCB.
