DeLonghi PACEX390LVYN Manuale utente

1 2 3

E F G H

DESCRIPTION OF THE ACCESSORIES

Congratulations on your purchase.

Use this quick set-up guide, and the user manual, to fully use all of the features and functions of your De’Longhi product.

Air exhaust hose (shown with

adapters already attached)

Foam stripping

Additional bracket

CST remote control

Window outlet vent End of season accessories bag End of season dust cover

ON/STAND-BY (on/off)

button

Decrease key

Arctic Whisper button

Swing button (ﬂap swing)

ECO REAL FEEL button

Indication LED

Increase key

Fan button

Timer button

Function selection button

MODE (air conditioning,

dehumidifying, fan)

The CST remote control senses temperature and humidity like a thermostat for a

personalized custom cool around you.

By keeping the CST remote nearby, it will track humidity and temperature around

you making sure you’ll always enjoy your desired comfort.

• Keep the CST remote control

placed on a table or a ﬂat sur-

face. Do not hold the CST remote

control in your hand for long

time to avoid altering the read-

ing of the sensors.

• The remote control must be no

more than about 33 ft (10 me-

ters) away from the appliance

(even in non line of sight).

• The CST sensors are also disabled if the CST remote control is positioned at a

distance less than 3.3 ft from the unit.

What led means....

3 fast ﬂashes (white) at the touch of each button

It blinks every 30 seconds

(white)

data transmission

It blinks periodically entering pairing

White color: batteries good status.

Red color: batteries beginning to be exhausted.

STEP

Window

bracket

Additional

bracket

STEP

from 20” to 47”

STEP

Click

EASY SET UP - ALL PARTS INCLUDED - NO TOOLS REQUIRED!

IMPORTANT NOTES TO PREVENT LEAKINGS:

1) Make sure air conditioner is on a level surface to prevent any conden-

sate leakage.

2) Before you move the unit, unplug the unit from the wall, and drain

any condensation from the drainage hose located on the back of

the unit into container. If you are in an especially humid region, you

should do this regularly to prevent potential leaking. Make sure drain

cap is back on tightly before resuming use.

For additional questions or comments, please call our Customer Service Hotline at 1-800-322-3848 (Toll Free – U.S. Only)

www.delonghiusa.com

Step 1- Placement

Select the best window for the air conditioner.

The window kit will ﬁt from a 20” to 47”

opening. You will need some clearance for the

hose and a convenient 3 hole grounded electrical

outlet within 5 ½ feet. Choose a window that is

centrally located so it is best positioned to cool

the entire room.

Do not install on same electrical circuit as other

major appliances.

Step 4 - Hose assembly

A - Insert and lock the accessory for window

bracket, already assembled to the air

exhaust hose, into the slot of the window

bracket.

B - Position the hose adapter ‘s tabs in a

vertical axis.

C - Attach assembled hose to the back of the air

conditioner.

Step 5- Plug the unit in

Be sure it is a 3 hole grounded outlet within

5 ½ feet of air conditioner.

Step 6- Turn unit on and set to your

desired temperature

See user manual to be able to use all func-

tions and features of this product.

Step 2 - Window kit

Take the window kit (3) and install in selected

window.

If there is still window area exposed, add the

additional window bracket (2) to ﬁll the space.

Step 3- Fix the bracket

Fix the bracket by the wing nut.

If desired, attach the provided stripping foam to

the top of the window bracket and then lower

the window onto the bracket.

5715113871_00_1219
