Before using the appliance, always read the safety warnings.

This appliance shall not be used by children.

Keep the appliance and its cord out of reach

of children.

1. DESCRIPTION

1.1 Description of appliance - A

A1. Main switch

A2. Grinding level selector (ne to coarse)

A3. Beans container

A4. Beans container lid

A5. Accessory holder lid

A6. Water tank lid

A7. Water tank

A8. Power cord

A9. Steam wand

A10. Coee outlet

A11. Hot water spout

A12. Portalter holder

A13. Coee grinder outlet

A14. Small cup grille support

A15. Small cup grille

A16. Mug or cup tray

A17. Mug or cup tray support

A18. Water level indicator

A19. Drip tray

1.2 Description of control panel - B

B1. Pressure gauge

B2. No water light

B3. Descale light

B4. Coee dose dial

B5. 1 or 2-cups selection button

B6. OK button: to deliver the beverage/conrm

B7. Coee Temperature button

B8. Mode selector dial:

• Espresso

• Long Black

• Hot water

• Descaling

B9. Steam button: to deliver steam

1.3 Description of accessories - C

C1. Portalter

C2. Dosing&Tamping Guide

C3. 1-cup coee lter

C4. 2-cups coee lter

C5. “Water hardness test“ indicator paper

C6. Descaler

C7. Softballs (* some models only)

C8. Milk pitcher

C9. Cleaning brush

C10. Cleaning needle for steam nozzle

C11. Tamper

C12. Tamping Mat (* some models only)

1.4 Recommended optional cleaning accessories

Visit Delonghi.com for more information.

Cleaner

EAN: 8004399333307

2. EXPLANATION OF LIGHTS

LIGHTS EXPLANATION OF LIGHTS OPERATION

All the lights ash briey Turning the machine on Self-diagnosis

The appliance is being turned on for the rst

time and the water circuit must be lled

Proceed as described in the Quick start guide.

(The indicators and show

the respective selections)

The machine is ready to use Prepare the machine, select the desired beverage

and press OK to start delivery

…→

LIGHTS EXPLANATION OF LIGHTS OPERATION

Flashing

The machine is warming up

Wait until the ideal delivery temperature has

been reached

Insucient water in tank (A7) or water

tank not inserted correctly

Fill the tank or extract the tank and put it back

correctly

Flashing

You are trying to deliver a beverage but

water tank (A7) is empty

Fill the tank

Because the beans are too nely

ground, the coee is delivered too

slowly or not at all

Remove the portalter (C1) and repeat the

operations to make the coee, bearing in mind

the instruction given in the quick start guide

relative to the grinding section

The lter (C3) or (C4) is blocked Clean as described in section “5. Cleaning and

maintenance”.

The tank (A7) has been inserted incorrectly

and the valves on the bottom are not open

Press the tank down lightly to open the valves

on the bottom

Scale in the water circuit Descale as described in section “9. Descaling”

1-dose beverage is selected All the process (from grinding to delivery) is

setted for preparing 1 cup

On 2-doses beverages are selected All the process (from grinding to delivery) is

setted for preparing 2 cups

MIN MED MAX

Choose 1 of the 3 temperatures

available

See Quick Guide for tips.

Flashing

General alarm Turn the machine o and wait 10 minutes

before turning on again. If the problem con-

tinues, contact customer services.

Flashing

Steam function is selected and running In a few seconds the appliance starts steam

delivery

On - red

Descaling must be performed Descale the appliance as described in section

“9. Descaling”

Flashing - On

Descaling is selected Press OK (B6) to run descaling cycle or turn the

selection knot to the beverage desired

…→

Red

Orange

Press both buttons (B5)

and (B7) for 3 seconds to

enter setting menu

Keep pressed steam but-

ton (B9) for 3 seconds

Enter the setting

Reset to default

values

➡ 9 minutes

➡ 1,5 hours

➡ 3 hours

Auto o

➡soft

➡

medium

➡

hard

Water hardness

➡No

➡

1 sec

➡

2 sec

Pre-infusion

delay

➡1st range

➡2nd range

Extra grinding

adjustment

Press the temperature button:

the light corresponding to the corrent setting ashes.

Press the temperature button again to change the setting:

Turn the knob (B8)

to select the position

corresponding to the

function to set

Select the setting

x3 sec

LIGHTS EXPLANATION OF LIGHTS OPERATION

Flashing

Descaling proceeds.The machine deliv-

ers descaling solution

Proceed by completing the descaling cycle

(see“9. Descaling”)

Flashing - On

The rst phase of the descaling cycle

is complete. You now need to proceed

with rinsing.

Press OK to start rinsing.

Flashing

The machine proceeds with the rinsing

phase to complete the descaling cycle.

Proceed by completing the descaling cycle

(see“12. Descaling”)

3. MENÙ SETTINGS

Red

Orange

Red

White

Red

White

…→

Press the OK (B6) button

to conrm.

Save new

settings: Please note:

The appliance automatically

exits the menù setting after 30

seconds of inactivity

4. CUSTOMISING THE QUANTITY OF BEVERAGES

1. Prepare the appliance to

deliver the beverage you

want to make. Prepare the

coee dose and attach the

portalter (C1) to the coee

outlet (A10).

2. Turn the dial (B8) to

select the drink to be

programmed.

3. Keep pressed the OK

button (B6) until the de-

sired quantity in cup is

reached.

4. Once released the but-

ton, the quantity is

programmed.

Please note:

• You can programme beverages quantities, but not steam.

• Programming changes the quantity of the beverages, but

not the amount of coee ground.

• “X2” beverages can be programmed separately.

1 2 3 4

Coee

Recipe

Default

quantity

Programmable quantity

35 ml from 25 to 90 ml

70 ml from 50 to 180 ml

100 ml • water: from 25 to 120 ml

• espresso: from 25 to 60 ml

200 ml • water: from 50 to 240 ml

• espresso: from 50 to 120 ml

250 ml from 65 to 300ml

5. CLEANING AND MAINTENANCE

Important!

• Do not use solvents, abrasive detergents or alcohol to clean the coee machine.

• Do not use metal objects to remove encrustations or coee deposits as they could scratch metal or plastic surfaces.

• If the appliance is not used for more than a week, before using it again, we recommend you perform a rinse cycle.

Danger!

• While cleaning, never immerse the coee maker in water. It is an electrical appliance.

• Before cleaning the outside of the appliance, turn it o, unplug from the mains socket and allow to cool.

✕✓✕ ✕ ✕

✓✕ ✕ ✕ ✕

✓✕ ✕ ✓✕

✕✓ ✓ ✕✓

6. CLEANING THE GRINDER

1. Clean the attachment area with a brush;

2. Use the brush (C9) to clean the coee funnel.

1 2

7. WATER HARDNESS

7.1 Water hardness

The descale light (B3) comes on after a period of time established according to water hardness. The machine can also be pro-

grammed according to the actual hardness of the water supply in the various regions, in which case descaling may be required less

frequently.

1. Remove the“TOTAL HARD-

NESS TEST” indicator paper

(C5) from its pack.

2. Immerse the paper

completely in a glass of

water for one second.

3. Remove the paper from

the water and shake

lightly.

4. Set the appliance as indi-

cated in section“3. Menù

settings”.

After about a minute, 1, 2, 3, or 4 red squares form, depending

on the hardness of the water. Each square corresponds to one

level.

Total Hardness Test result Button Level

soft water

medium

water

hard or

very hard

water

8. CLEANING THE STEAM NOZZLE

1. After every use, remove

with a soft damp cloth

any milk residues from

the steam wand (A9) and

the nozzle.

2. Use the steam for a deeper

cleaning.

3. To maintain the better

usability of the nozzle,

when clogged, use the

Cleaning Tool (C10) for

opening the hole.

1 2 3

123

9. DESCALING

1. IF PRESENT, REMOVE

THE WATER SOFTENER

DEVICE.

Pour the des-

caler into the tank (A7)

up to the level A

marked inside the tank

(equal to one 100ml

packet).

2. A

dd water (1 liter) up

to t

he level B.

Then put the water tank

back in the appliance.

3. Turn the mode selector

dial (B8) to : the OK

light (B6) turns to orange

and the descaling light

(B3) ashes.

4. Make sure the portalter is

not attached and position a

recipient under the coee

outlet (A10), hot water

spout (A11) and steam

wand (A9).

5. Keep pressed for at least

3 seconds the OK

button:

the OK light begins to

ash; descaling starts.

12.

Please note

• Before use, read the instructions and the labelling on the descaler pack.

• It is important to use De’Longhi descaler only. Using unsuitable descaler and/or performing descaling incorrectly may result

in faults not covered by the manufacturer’s guarantee.

• Descaler could damage delicate surfaces. If the product is accidentally spilt, dry immediately.

2 3

RED

Minutes

De’LonghiAppliances s.r.l.

ViaL. Seitz, 47 31100 Treviso - ITALY

Tel.+39 0422 4131

5413218631/04.15

Decalciﬁcanteper macchine da caffè

Descalerfor coffee machines

Détartrantpour machines à café

Entkalkerfür Kaffeemaschinen 2 L

Please note

• In case you start the descaling cycle by mistake, you can press the OK button

for 10 seconds; the rinsing cycle can not be stopped (from step 9).

6. The descale programme starts and the descaler liquid

comes out of the steam wand and coee outlet.The des-

cale programme removes limescale deposits from inside

the appliance by automatically performing a series of

rinses and pauses until the tank is empty.

Delivery stops and the OK light turns to white. This indi-

cates that it is necessary to proceed with rinsing: see next

page.

When the light (B3) comes

on, it is time to proceed descal-

ing the machine. The descaling

cycle can be run in any moment.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali DeLonghi Macchina per il caffè

DeLonghi

DeLonghi Magnifica ESAM 3300 Manuale utente

DeLonghi

DeLonghi DINAMICA PLUS ECAM370.95.T Manuale utente

DeLonghi

DeLonghi PRIMADONNA ELITE Manuale utente

DeLonghi

DeLonghi Nespresso Lattissima Touch Manuale utente

DeLonghi

DeLonghi ECP3 Series Manuale utente

DeLonghi

DeLonghi DCm04 series Manuale utente

DeLonghi

DeLonghi NESCAFE dolce gusto Manuale utente

DeLonghi

DeLonghi EC 250 B Manuale utente

DeLonghi

DeLonghi La Specialista Maestro Manuale utente

DeLonghi

DeLonghi DCF112 Manuale di istruzioni per l'installazione

DeLonghi

DeLonghi EC9 UK Manuale utente

DeLonghi

DeLonghi BCO264B Manuale di istruzioni per l'installazione

DeLonghi

DeLonghi DINAMICA PLUS ECAM37 95 Series Manuale utente

DeLonghi

DeLonghi ECAM21.11X Manuale utente

DeLonghi

DeLonghi Icona ECO 310.W Manuale utente

DeLonghi

DeLonghi Fully Automatic Coffee Center Machine... Manuale utente

DeLonghi

DeLonghi ECAM45.76 Series Manuale utente

DeLonghi

DeLonghi ESAM 4000 Manuale utente

DeLonghi

DeLonghi ECAM28.46X Manuale utente

DeLonghi

DeLonghi EC1341 Series Manuale utente

DeLonghi

DeLonghi ESAM 04.110 Manuale utente

DeLonghi

DeLonghi ESAM 2000 Manuale utente

DeLonghi

DeLonghi EC-610 Manuale utente

DeLonghi

DeLonghi SER3017 Manuale utente

Manuali Macchina per il caffè popolari di altre marche

Taurus

Taurus Livorno 6 Manuale utente

Delta-q

Delta-q QUICK Manuale utente

Bunn

Bunn LCA-1 Guida alla risoluzione dei problemi

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Istruzioni per l'installazione

Saeco

Saeco Vienna Plus Sup 018M Manuale utente

INCAPTO

INCAPTO BXCO1470E Manuale utente

Bosch

Bosch TASSIMO finesse TAS16B Series Manuale utente

Exido

Exido 245-072 Manuale utente

Animo

Animo OptiVend Choco Manuale utente

Siemens

Siemens TQ505DF Series Manuale utente

Krups

Krups KT406511 Manuale utente

Cimbali

Cimbali M32 Classic Manuale utente

Philips

Philips HL3844N Manuale utente

Bosch

Bosch TES 515 SERIES Manuale utente

Tekmatix

Tekmatix TMFM - 65 Manuale utente

Scarlett

Scarlett SC-CM33005 Manuale utente

LAVAZZA

LAVAZZA CLASSY PLUS Manuale utente

Black & Decker

Black & Decker DLX900 Istruzioni per l'installazione
