DeLonghi MELODY 3 Manuale utente
www.dolce-gusto.com
USER MANUAL
MELODY 3
2
OVERVIEW........................................3
PRODUCTRANGE................................4-5
FIRST USE.........................................6
PREPARING A BEVERAGE.............................7
RECOMMENDATIONS FOR A SAFE USE / ECONOMY MODE .8
CLEANING........................................9
DESCALING AT LEAST EVERY 3-4 MONTHS............12-13
IF NO LIQUID COMES OUT... . . . . . . . . . . . . . . . . . . . . . . . 10-11
TROUBLESHOOTING.............................14-15
SAFETY PRECAUTIONS..............................16
TABLE OF CONTENTS
3
OVERVIEW
1.3 l 5-45 °C
41-113 °F
~3 kg
A = 20.0 cm
A
C
B
230 V / 50 Hz / max. 1500 W
max. 15 bar
NO, SE, FI, DK, ES, IT, CH, UK, DE
B = 30.4 cm
C = 31.5 cm
1 4 7 10
2 5 8 11
3 6 9
Water tank
Hot
Cold
Selection lever
Locking handle
Power button Capsule bin
Stop Capsule holder Drip tray
Drip grid
17/23mm
17/18mm
C
17/23mm
0-12
OFF
ON
STOP
8
1
2
6
3 4 5
7
9
10
11
4
PRODUCT RANGE
Espresso
Espresso Intenso
60 ml
Espresso Ristretto
40 ml
Latte Macchiato
220 ml
50 ml
170 ml
Espresso Intenso
40 ml
Cappuccino
240 ml
40 ml200 ml
Lungo
120 ml
Chococino®
210 ml
110 ml
100 ml
Hot Beverage
ESPRESSO
LUNGO
CAPPUCCINO
Espresso
Espresso Intenso
60 ml
Espresso Ristretto
40 ml
Latte Macchiato
220 ml
50 ml
170 ml
Espresso Intenso
40 ml
Cappuccino
240 ml
40 ml200 ml
Lungo
120 ml
Chococino®
210 ml
110 ml
100 ml
Espresso
Espresso Intenso
60 ml
Espresso Ristretto
40 ml
Latte Macchiato
220 ml
50 ml
170 ml
Espresso Intenso
40 ml
Cappuccino
240 ml
40 ml200 ml
Lungo
120 ml
Chococino®
210 ml
110 ml
100 ml
Espresso
Espresso Intenso
60 ml
Espresso Ristretto
40 ml
Latte Macchiato
220 ml
50 ml
170 ml
Espresso Intenso
40 ml
Cappuccino
240 ml
40 ml200 ml
Lungo
120 ml
Chococino®
210 ml
110 ml
100 ml
CHOCOCINO
12
12
5
PRODUCT RANGE
LATTE MACCHIATO
AROMA / GRANDE CAFFÈ CREMA
CAPPUCCINO ICE
Latte Macchiato
220 ml
50 ml
170 ml
Aroma
200 ml
GrandeCaffèCrema
200 ml
Aroma
200 ml
Latte Macchiato
220 ml
50 ml
170 ml
Aroma
200 ml
CaffèCremaGrande
200 ml
Aroma
200 ml
CappuccinoIce
240 ml
105 ml135 ml
Latte Macchiato
220 ml
50 ml
170 ml
Aroma
200 ml
GrandeCaffèCrema
200 ml
Aroma
200 ml
Cold Beverage
12
12
6
FIRST USE
STOP
STOP
STOP
Rinse water tank at rst.
Fill water tank with fresh, drinking water. Place
cap and insert water tank to machine.
Switch machine on. Power button starts
blinking red while machine is heating up for
approx. 30 seconds. Afterwards power button
lights steady green and machine is ready.
30 sec
ON
Push selection lever to the “HOT” position.
Machine starts rinsing.
Open locking handle and insert empty capsule
holder. Close locking handle.
Place capsule bin under outlet.
Push selection lever to the “COLD” position.
Machine starts rinsing.
After approx. 60 seconds push selection lever
to the “STOP” position. Empty capsule bin and
rell water tank with fresh, drinking water.
Make sure that the selection lever is in “STOP”
position. Then plug the power plug into a
mains power socket.
After approx. 60 seconds push selection lever
to the “STOP” position. Machine stops rins-
ing and power button blinks red for about 5
seconds.
1
4
7
2
5
8
Remove protection foil from drip grid. Place
drip grid on drip tray. Then insert drip tray at
desired position of machine.
~60 sec
~60 sec
3
6
9
7
PREPARING A BEVERAGE
STOP
Push selection lever to the “HOT” position.
Beverage preparation starts.
Take cup from drip tray. Open locking handle.
Adjust drip tray position according to the
chosen beverage (see page 4-5). Place cup on
drip tray.
After reaching the desired level push selection
lever to the “STOP” position. Machine stops
preparation.
Pull out capsule holder and remove used cap-
sule. Put used capsule in capsule bin.
Open locking handle and pull out capsule
holder. Insert capsule in capsule holder and
insert it back in machine. Close locking handle.
After nishing preparation the power button
blinks red for about 5 seconds. During that
time do not open locking handle!
Rinse and dry capsule holder with water from
both sides. Insert capsule holder to machine.
Enjoy your beverage!
Switch machine on. Power button starts
blinking red while machine is heating up for
approx. 30 seconds. Afterwards power button
lights steady green and machine is ready.
30 sec
5 sec
1
4
7
2
5
8
3
6
9
8
Never ll hot water into the water tank! Never open the locking handle during
beverage preparation!
After nishing preparation the power
button blinks red for about 5 seconds.
During that time do not open locking
handle!
ECONOMY MODE
RECOMMENDATIONS FOR A SAFE USE
Never push selection lever while locking
handle is opened!
Do not touch used capsule after
beverage preparation! Hot surface, risk
of burns!
5 sec
After 5 minutes of non-usage the machine
automatically shuts down (Economy Mode).
5 min
ON OFF
9
CLEANING
Rinse drip tray with water and clean it with a
brush. You can also put it in a dishwasher.
Rinse and dry capsule holder with water from
both sides. You can also put it in a dishwasher.
Rinse and clean water tank. Afterwards rell
with fresh, drinking water and insert it to ma-
chine. The water tank is not dishwasher proof!
Switch machine on. Power button starts
blinking red while machine is heating up for
approx. 30 seconds. Afterwards power button
lights steady green and machine is ready.
30 sec
Place drip grid on drip tray. Then insert drip
tray at desired position of machine. Clean ma-
chine with a soft damp cloth. Dry it afterwards
with a soft dry cloth.
Open locking handle and insert empty capsule
holder. Close locking handle and place cap-
sule bin.
STOP
After approx. 10 seconds push selection lever
to the “STOP” position. Empty and clean cap-
sule bin. You can also put it in a dishwasher.
Push selection lever to the “HOT” position.
Machine starts rinsing.
~10 sec
1
4
7
2
5
8
3
6
10
IF NO LIQUID COMES OUT...
STOP
Turn selection lever to neutral position.No liquid comes out and the machine makes
a loud noise.
The capsule may be blocked and under pres-
sure.
Then lift the locking handle and remove the
capsule holder.
Check if there is water in the water tank: if not,
rell and move lever again to hot/cold posi-
tion to continue preparation; if yes proceed as
follows:
Do not use force to lift the locking handle.
Throw away the capsule.
Wait for 20 minutes to reduce the pressure.
21
1
4
3
2
5
3
20 min
A
Check if locking handle can be lifted easily: NO - see section A (below) / YES – see section B (next page)
