DELTA DORE TYMOOV SET Manuale utente

EN Programming console for Tymoov motors

TYMOOV SET

Contents

1/ Recommendations.....................................................................................3

2/ Description ...................................................................................................3

3/ Connection / Setting of the stops ........................................................5

4/ Troubleshooting.......................................................................................10

5/ Technical specications ........................................................................10

DANGER!

Risk of death by electrocution in case of contact with the electrical components.

- Theconneconofthetubularmotortotheprogrammingconsole,andalsothenalconneconofthe

tubularmotortotheelectricalnetwork,mayonlybeperformedbyaceredprofessionalelectrician.

-Conneconworksmayonlybeperformedwhentheinstallaonisdisconnectedfromthepowersupply.

- Completelydisconnecttheelectricalsupplyandsecureittopreventreconnecon.

- Checkthattheinstallaonisnotsuppliedwithpower.

Use in accordance with the intended purpose

OnlyusetheprogrammingconsoleforthesengorcorreconofthelimitswitchesforTYMOOVtubular

motors.

Non-compliant use

Neverusetheprogrammingconsoleforthefollowingoperaons:

- Connuouscontrolofatubularmotor..

- Conneconandcontrolofotherelectricalreceivers

Recommendations1/ Recommendations

2/ Description

Theprogrammingconsoleisintendedforthecommissioning,adjustment,andthecorreconofthelimit

switchesofTymoovtubularmotors.

BuonA DireconofrotaonI/II+Stop

BuonB Programmingbuon

BuonC Buondedicatedtotheunusedgreywire

BuonA

BuonB BuonC

4 5

Tymoov FB Tymoov FE

❶Onlyconnectthemotorcablestotheconsole

withoutacontrolpointorintermediary

❷Supplypowertotheconsolebyconnecngthe

plugtothemainsoutlet

❸Sengstops

Automac Notaccessible 1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.

2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop.

Semi-automac Notaccessible

1st stop in automatic mode

SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.

2nd stop in manual mode

SetbuonAtoposionIorII,applyingtheoppositesengtothe1stautomacstop.

Whenthemotorstartsup,pressbuonBtwicebriey,andholda3rdpressunlyoureachthedesired

posion,withoutreleasing.

Ifnecessary,ne-tunebypressingbrieyonbuonB.

Set button A to STOP: the stops are saved.

Manual

SetbuonAtoposionIorII,dependingonthe

desireddireconofrotaon.

Setthestopsonthemotorusingtheadjusng

screws(seeinstruconsforthemotor)

Note: do not touch button B

1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.

Then,brieypressbuonBtwiceandholdthe3rdpressunlthedesiredposionisreached,before

releasing.

Ifnecessary,ne-tunebypressingbrieyonbuonB.

2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop.

Then,brieypressbuonBtwiceandholdthe3rdpressunlthedesiredposionisreached,before

releasing.

Ifnecessary,ne-tunebypressingbrieyonbuonB.

Set button A to STOP: the stops are saved.

❹Disconnecttheconsole

-Removetheplugfromthemainsoutlet

-Disconnectthemotorconneconcord

-Reconnectthetubularmotor

tothemainssupply(seeinstrucons).

Brown

Blue

Grey

Yellow / Green Black

Brown

Blue

Grey

Yellow / Green Black

3/ Connection / Seing of the stops

6 7

3/ Connection / Seing of the stops

Tymoov F2

❶Onlyconnectthemotorcablestotheconsole

withoutacontrolpointorintermediary

❷Supplypowertotheconsolebyconnecngthe

plugtothemainsoutlet

❸Sengstops

Automac

1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.Oncethestophas

beenreached,themotorwillbrieyacvateonce.

2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop.Oncethestopis

reached,themotorwillbrieyacvatetwice.

Semi-automac

Dependingontheinstallaonofthemotorandtheshuer,determinewhetherbuonsIandIIcontrolraising

(^)orlowering(v).

1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.Oncethestophas

beenreached,themotorwillbrieyacvateonce.

2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop(*).

Oncethestopisreached,posionbuonAtoSTOP.

Forthetopstop:performthefollowingsequenceusingshortpresses(<1second)onbuonA:^-Stop-^-

Stop,thenhold^unlthemotoracvatestwice.

Fortheboomstop:performthefollowingsequenceusingshortpresses(<1second)onbuonA:v-Stop-v

-Stop-v-Stop,thenholdvunlthemotoracvatestwice.

Manual

Dependingontheinstallaonofthemotorandtheshuer,determinewhetherbuonsIandIIcontrolraising

orlowering.

SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon(*).

Oncethestophasbeenreached,togglebuonAtotheStopposion.

StorethetopstopbyperformingthefollowingsequencewithbuonA:^-Stop-^-Stopthenhold^.

Tostoretheboomstop,performthefollowingsequencewithbuonA:v-Stop-v-Stop-v-Stop,then

holdv.

Themotoracvatesoncewhenmemorisingtherststop,andtwiceforthe2nd.

❹Disconnecttheconsole

-Removetheplugfromthemainsoutlet

-Disconnectthemotorconneconcord

-Reconnectthetubularmotortothemainssupply(seeinstrucons).

(*)Possibleacvaonofstepwisemode(slowmovement)

Forthetopstop,performthefollowingsequencewithbuonA:^-Stop-v-Stop,thenhold^.

Fortheboomstop,performthefollowingsequencewithbuonA:^-Stop-v-Stop,thenholdv.

Brown

Blue

Grey

Yellow / Green Black

8 9

Tymoov RE2/RP2

❶Onlyconnectthemotorcablestotheconsole

withoutacontrolpointorintermediary

❷Supplypowertotheconsolebyconnecngthe

plugtothemainsoutlet

Whenswitchedonfortherstme,withbuonAinposionI:

themotorwillaquickcycletowarnthatnotransmierispaired.

Themotorisautomacallysettopendingpairingfor5minutes.

❸Sengstops

Automac

1st stop: BuonAatposionI,pressbuonBfor2secondstoacvatethemotor.Whenthemotorhas

detectedits1ststop(toporboom),itacvatesonce.

2nd stop: pressbuonBfor2secondstoacvatethemotor.Whenthemotorhasdetectedits2ndstop,it

acvatestwice.

Thestopsarememorised.

Semi-automac

1st stop in automatic mode:

BuonAatposionI,pressbuonBfor2secondssothatthemotoracvates(ifthedireconofrotaon

doesnotcorrespondtothestopthatyouwishtoset,brieypressbuonB,thenpressbuonBonceagain

for2secondssothatthemotoracvatesagain,intheoppositedirecon).Oncethestophasbeenreached,

themotorwillacvateonce.

2nd stop in manual mode:

BuonAalwaysinposionI,pressbuonBfor2secondstoacvatethemotor.

BrieypressbuonBtostopatthedesiredposion.

Forthetopstop,perform2shortpressesonbuonB,thenalongpress(longerthan2seconds).

Fortheboomstop,perform3shortpressesonbuonB,thenalongpress(longerthan2seconds).

Themotoracvatestwicetoconrmthatthe2ndstophasbeenmemorised.

Manual

BuonAtoposionI.

PressbuonBfor2secondsunlthemotoracvates.

Tostopthemotor,brieypressbuonB.

Fortheboomstop,perform3shortpressesandalongpress(>2seconds)onbuonB.

Forthetopstop,perform2shortpressesandalongpress(>2seconds)onbuonB.

Themotoracvatesoncewhenthe1ststophasbeenstored.

Tosetthe2ndstop:repeattheprocedurefromthestart.

Themotorwillacvatetwicetoconrmthatthe2ndstophasbeensaved.

❹Disconnecttheconsole

-Removetheplugfromthemainsoutlet

-Disconnectthemotorconneconcord

-Reconnectthetubularmotortothemainssupply(seeinstrucons).

Brown

Blue

Grey

Yellow / Green Black

Black

Brown

3/ Connection / Seing of the stops

4/ Troubleshooting

Youwishtosetthestopsagain.

Youmustrsterasetheexisngstops.

Tymoov FE

PressbuonB,thensetbuonAtoposionIorII.

Aer5seeconds,themotorbrieyacvatesonce.

Thestopshavenowbeendeleted.

Tymoov F2

-Lowertheshuercompletely,

-SetbuonAtoSTOPwithin5secondsoftheshuerstopping,

-Then,performthefollowingsequenceofpresses:v-Stop-v-Stop(<3secondsbetweeneachpress),

thenpressandholdv.

Themotorbrieyacvatestwice.The2stopsareerased.

-Settheshuertothetopposion,

-SetbuonAtoSTOPwithin5secondsoftheshuerstopping,

-Then,performthefollowingsequenceofpresses:^-Stop-^-Stop(<3secondsbetweeneachpress),then

pressandhold^.

Themotorbrieyacvatestwice.The2stopsareerased.

Tymoov RE2/RP2

BuonAatposionI,

pressbrieyonbuonBtomovethemotortowardsitstoporboomstop.

Inthe5secondsfollowingthestoppingoftheshuer,setbuonAtoSTOPandwaitfor10seconds.

Then,whileholdingbuonBpresseddown,togglebuonAtoIandonlyreleasebuonBwhenthemotor

acvatestwice.

Thestopsarenowerased.

• Operating voltage: 230 V / 50 Hz

• Max. power : 6 (4) A / 250 V AC

• Operating temperature: 0 à 40 °C

• Storage temperature: -10°C to +60 °C / Max. air humidity 90 %

• Protection rating: II

• Cable length: 2.88 m

5/ Technical specifications

www.deltadore.com

11/22
