Delta Electronics DUP-B Series Manuale utente

DOP-B_M_EN_20100531

Preface

Thank you very much for purchasing DELTA’s DOP-B Series Human Machine Interface

(hereinafter “HMI” ) products.

This manual will be helpful in the installation, operation and specifications of Delta HMI

product and HMI Screen Editor software program. Before using the product, please read this

user manual to ensure correct use.

You should thoroughly understand all safety precautions (DANGERS, WARNINGS and STOPS)

before proceeding with the installation, wiring and operation. If you do not understand please

contact your local Delta sales representative. Place this user manual in a safe location for

future reference.

Using This Manual

Contents of this manual

This manual is a user guide that provides the information on how to install

and operate Delta HMI products and Screen Editor software program.

Who should use this manual

This user manual is intended for the following users:

Those who are responsible for designing.

Those who are responsible for installing or wiring.

Those who are responsible for operating or programming.

Important precautions

Before using the product, please read this user manual thoroughly to ensure correct

use and store this manual in a safe and handy place for quick reference whenever

necessary. Besides, please observe the following precautions:

Install the product in a clean and dry location free from corrosive and

inflammable gases or liquids.

Ensure that HMI is correctly connected to a ground. The grounding method

must comply with the electrical standard of the country.

Do not modify or remove wiring when power is applied to HMI.

Before starting the operation, make sure the emergency stop equipment can

be energized and work at any time.

Do not touch the power supply during operation. Otherwise, it may cause

electric shock.

Revision May, 2010 i

Preface

NOTE

The content of this manual may be revised without prior notice. Please consult our distributors or

download the most updated version at http://www.delta.com.tw/industrialautomation.

ii Revision May, 2010
