Delta Electronics PMC Series Manuale utente

Instruction Manual PMC-12V060W1N□

www.DeltaPSU.com

1. Safety Instructions

• Toensuresufcientconvectioncooling,alwaysmaintainasafetydistanceof

≥20mmfromallventilatedsurfaceswhilethedeviceisinoperation.

• The device is not recommended to be placed on low thermal conductive

surface,forexample,plastics.

• Notethattheenclosureofthedevicecanbecomeveryhotdependingonthe

ambienttemperature andloadofthepowersupply.Donot touchthe device

whileitisinoperationorimmediatelyafterpoweristurnedOFF.Riskofburning!

• Donottouchtheterminalswhilepowerisbeingsupplied.Riskofelectricshock.

• Preventanyforeignmetal,particlesorconductorstoenterthedevicethrough

theopeningsduringinstallation.Itcancause:Electricshock;SafetyHazard;

Fire;Productfailure

• Warning: When connecting the device, secure Earth connection before

connecting L and N. When disconnecting the device, remove L and N

connectionsbeforeremovingtheEarthconnection.

2. Device Descriptions

RefertoFig.1.:

䐟Input&Outputterminalblockconnector

䐠DCvoltageadjustmentpotentiometer

䐡DCOKcontrolLED(Green)

3. Installation of the Device

RefertoFig.2.:

䑵Mounting holes for power supply assembly onto the mounting surface. The

powersupplyshallbemountedonminimum2mountingholesusingM3screw

minimum5mmlength.

䑶This surface belongs to customer’s end system or panel where the power

supplyismounted.

䑷Connector

• Useexiblecable(strandedorsolid)withthefollowingsizes:

• The torque at the Connector shall not exceed 13 Kgf.cm. The insulation

strippinglengthshouldnotexceed0.275”or7mm(RefertoFig.3).

4. Installation of Mounting Accessories

RefertoFig.4.:

• OnlyuseM3screw≤6mmthroughthebasemountingholes.Thisistokeepa

safetydistancebetweenthescrewandinternalcomponents.

• Recommendedmountingtighteningtorque:4~8Kgf.cm.

REV.00

Fig. 1. Device Descriptions

PMC-12V060W1NA (Standard Connector) PMC-12V060W1NJ (IP20 Connector)

PMC-12V060W1NL (Front Face Connector)

Fig. 3. Wire Type Fig. 4. Mounting Screw

Lug Stripped wire

Mounting

accessories

Mounting

screw

Chassis of

the device

6mm max.

7 mm

Fig. 2. Mounting Orientation

Side Mounting (Vertical) Base Mounting (Vertical) Side Mounting (Horizontal)

Side Surface

Top Surface

Ventilated Surface

Base Surface

Ventilated Surface

Side Surface

Ventilated Surface

Side Surface

PMC-12V060W1NH (Harness Connector)

PMC-12V060W1NA PMC-12V060W1NJ PMC-12V060W1NL

AWG22-14 AWG22-12 AWG22-12

Ventilated Surface

Side Surface

PMC-12V060W1N□

www.DeltaPSU.comREV.00

1. 安全規範

• 與通風表面保持至少20mm的安全距離，以確保對流冷卻充分。

• 本產品不適合擺放在低熱導體，例如:塑膠。

• 受環境溫度及產品負載的影響，本機外殼溫度會很高，因此在上電時或切斷電

源後短時間內不要觸摸本機，以免燙傷。

• 請勿在上電時觸摸連接端子，以防電擊危險。

• 安裝過程中，應避免金屬元件或金屬導體通過空隙或通風孔進入到產品內，

否則會引起下列狀況。

－電擊;安全危害;火災;產品異常

• 警告:在連接產品電源供應時，產品必須先接地然後才接L和N。當要解開電源

供應時，必須先把L和N解開然後才把接地解開。

2. 產品外觀介紹

依據圖一:

䐟輸入/輸出連接端子

䐠直流電壓調節電位器

䐡直流電控制OK指示燈（綠色）

3. 產品固定方式

依據圖二:

䑵在把產品安裝在固定表面時，將螺絲鎖入此固定孔。產品應該用長度至少5mm

的M3螺絲鎖入至少兩個固定孔。

䑶此固定表面為客戶系統表面。

䑷輸入/輸出連接端子。

• 可以使用以下多股或實心的電線:

• 扭矩不應該超過13Kgf.cm。剝線的長度不應該超過0.275″或者7mm(依據圖

三)。

4. 配件組合安裝

依據圖四:

• 在把配件裝上產品時，請使用長度不超過6mm的M3螺絲鎖入產品底面的固定

孔。這是為了確保螺絲和內部元件間有足夠的絕緣距離。

• 建議配件固定螺絲扭矩為4~8Kgf.cm。

1. 安全规范

• 与通风表面保持至少20mm的安全距离，以确保对流冷却充分。

• 本产品不适合摆放在低热导体，例如:塑胶。

• 受环境温度及产品负载的影响，本机外壳温度会很高，因此在上电时或切断电

源后短时间内不要触摸本机，以免烫伤。

• 请勿在上电时触摸连接端子，以防电击危险。

• 安装过程中，应避免金属元件或金属导体通过空隙或通风孔进入到产品内，

否则会引起下列状况。

－电击;安全危害;火灾;产品异常

• 警告:在连接产品电源供应时，产品必须先接地然后才接L和N。当要解开电源

供应时，必须先把L和N解开然后才把接地解开。

2. 产品外观介绍

依据图一:

䐟输入/输出连接端子

䐠直流电压调节电位器

䐡直流电控制OK指示灯（绿色）

3. 产品固定方式

依据图二:

䑵在把产品安装在固定表面时，将螺丝锁入此固定孔。产品应该用长度至少5mm

的M3螺丝锁入至少两个固定孔。

䑶此固定表面为客户系统表面。

䑷输入/输出连接端子。

• 可以使用以下多股或实心的电线:

• 扭矩不应该超过13Kgf.cm。剥线的长度不应该超过0.275″或者7mm(依据图

三)。

4. 配件组合安装

依据图四:

• 在把配件装上产品时，请使用长度不超过6mm的M3螺丝锁入产品底面的固定

孔。这是为了确保螺丝和内部元件间有足够的绝缘距离。

• 建议配件固定螺丝扭矩为4~8Kgf.cm。

使用说明书使用說明書

PMC-12V060W1NA PMC-12V060W1NJ PMC-12V060W1NL

AWG22-14 AWG22-12 AWG22-12

PMC-12V060W1NA PMC-12V060W1NJ PMC-12V060W1NL

AWG22-14 AWG22-12 AWG22-12
