Delta ERD12 Manuale utente

Vers. 1 – 26/11/2018

USER MANUAL

MODELS:

ERD12 • ERD13 • ERD21 • ERD22

Delta Cabinet Upright Stainless

Chiller and Freezer

LTD

distributed by

Table of Contents

Important safety instructions................................3

Unpacking and installation...................................3

Electrical connection............................................4

Start-up of the cabinet.........................................4

Thermostat...........................................................5

Defrosting.............................................................6

Maintenance and cleaning...................................6

Service..................................................................6

Disposal................................................................6

LTD

Important safety instructions

1. To obtain full use of the cabinet, we recommend reading this instruction manual.

2. It is the user’s responsibility to operate the appliance in accordance with the instructions

given.

3. Contact your dealer immediately in case of any malfunctions.

4. Place the cabinet in a dry and ventilated place.

5. Keep the cabinet away from strongly heat-emitting sources and do not expose it to direct

sunlight.

6. Always keep in mind that all electrical devices are sources of potential danger.

7. Do not store inflammable material such as thinner, gasoline etc. in the cabinet.

8. We declare that no asbestos nor any CFC are used in the construction.

9. The oil in the compressor does not contain PCB.

Unpacking and installation

Remove the wooden pallet and the packing. External surfaces are supplied with a protection foil,

which must be removed before installation

To ensure correct function it is important that the cabinet is level. The cabinet is supplied with legs,

these can be adjusted. See fig. 1.1.

Fig. 1.1

Important safety instructions

1. To obtain full use of the cabinet, we recommend reading this instruction manual.

2. It is the user’s responsibility to operate the appliance in accordance with the in-

structions given.

3. Contact your dealer immediately in case of any malfunctions.

4. Place the cabinet in a dry and ventilated place.

5. Keep the cabinet away from strongly heat-emitting sources and do not expose it

to direct sunlight.

6. Always keep in mind that all electrical devices are sources of potential danger.

7. Do not store inammable material such as thinner, gasoline etc. in the cabinet.

8. We declare that no asbestos nor any CFC are used in the construction.

9. The oil in the compressor does not contain PCB.

Unpacking and installation

Remove the wooden pallet and the packing. External surfaces are supplied with

a protection foil, which must be removed before installation. To ensure correct

function it is important that the cabinet is level.

If the cabinet is supplied with legs these an be adjusted. See g. 1.1.

lf you want to build in your cabinet please note the following:

• There must be at least 15 cm free space above the cabinet in order for the

cooling system to work satisfactorily.

• There must be sufcient space at the hinge side to clean and replace the shelves

and clean around the hinge.

Electrical connecting

The cabinet operates on 230 V/50 Hz.

The wall socket should be easily accessible.

All earthing requirements stipulated by the local electricity authorities must be observed. The

cabinet plug and wall socket should then give correct earthing. If in doubt, contact your local

supplier or authorized electrician.

The flexible cord fitted to this appliance has three cores for use with a 3-pin 13-Amp or 3-pin 15-

Amp plug. If a B.S. 1363 (13-Amp) fused plug is used, it should be fitted with a 13-Amp fuse.

The wires in this mains lead are coloured in accordance with the following code:

Green/Yellow: Earth, Blue: Neutral, Brown: Live.

The main electrical connections must be done by skilled electricians.

Start-up of the cabinet

Before use, we recommend that the cabinet is cleaned, see the section on maintenance and cleaning.

Important !

If the cabinet has been vertically placed during transport, please wait 2 hours before starting up the

cabinet.

Connect the cabinet to a socket and turn on the switch on the control panel, see fig. 1.9.

Fig. 1.9

Connect the cabinet to a socket and

turn on the switch on the control

panel, see g. 1.3.

Electrical connecting

The cabinet operates on 230 V/50 Hz. The wall socket should be easily accessible.

All earthing requirements stipulated by the local electricity authorities must be

observed. The cabinet plug and wall socket should then give correct earthing. If in

doubt, contact your local supplier or authorized electrician.

The exible cord tted to this appliance has three cores for use with a 3-pin 13-

Amp or 3-pin 15- Amp plug. If a B.S. 1363 (13-Amp) fused plug is used, it should

be tted with a 13-Amp fuse.

The wires in this mains lead are coloured in accordance with the following code:

Green/Yellow: Earth, Blue: Neutral, Brown: Live.

The main electrical connections must be done by skilled electricians.

Start-up of the cabinet

Before use, we recommend that the cabinet is cleaned, (see the section on

maintenance and cleaning).

If the cabinet has been vertically placed during transport, please wait 2 hours

before starting up the cabinet. Connect the cabinet to a socket and turn on

the switch on the control panel, see g. 1.2.

Important!

Fig. 1.2

Fig. 1.3

Display set temperature:

Press this key and the display will show the set temperature. Press the

key again to return to normal reading.

Set new temperature:

Press this key and the display shows the set temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will ash with the

new value and will then return to normal reading.

Thermostat

The thermostat is placed in the control panel, see fig. 2.0.

Fig. 2.0

The thermostat has been pre-set and in most cases it is not necessary to adjust the settings.

When turning on the cabinet the display will show the current temperature in the cabinet.

Display set temperature:

Press this key and the display will show the set temperature. Press the key again to return to

normal reading

Set new temperature:

Press this key continuously for more than 3 seconds and the display shows the set

temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will flash with the new value and will

then return to normal reading.

Alarm codes:

‘P1’ Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

‘P2’ Flashing in the display: indicates that the evaporator sensor is defective.

This does not influence the operation of the cabinet, but should be repaired as soon as

possible.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the

contents of the cabinet is changed frequently it may become necessary to defrost the cabinet

manually.

Pressing this key continuously for more than 3 seconds will start a manual defrosting and

then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and evaporates.

Thermostat

The thermostat is placed in the control panel, see fig. 2.0.

Fig. 2.0

The thermostat has been pre-set and in most cases it is not necessary to adjust the settings.

When turning on the cabinet the display will show the current temperature in the cabinet.

Display set temperature:

Press this key and the display will show the set temperature. Press the key again to return to

normal reading

Set new temperature:

Press this key continuously for more than 3 seconds and the display shows the set

temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will flash with the new value and will

then return to normal reading.

Alarm codes:

‘P1’ Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

‘P2’ Flashing in the display: indicates that the evaporator sensor is defective.

This does not influence the operation of the cabinet, but should be repaired as soon as

possible.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the

contents of the cabinet is changed frequently it may become necessary to defrost the cabinet

manually.

Pressing this key continuously for more than 3 seconds will start a manual defrosting and

then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and evaporates.

Thermostat

The thermostat is placed in the control panel, see g. 2.0.

The thermostat has been pre-set and in most cases it is not necessary to adjust the

settings.

When turning on the cabinet the display will show the current temperature in the

cabinet.

Thermostat

The thermostat is placed in the control panel, see fig. 2.0.

Fig. 2.0

The thermostat has been pre-set and in most cases it is not necessary to adjust the settings.

When turning on the cabinet the display will show the current temperature in the cabinet.

Display set temperature:

Press this key and the display will show the set temperature. Press the key again to return to

normal reading

Set new temperature:

Press this key continuously for more than 3 seconds and the display shows the set

temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will flash with the new value and will

then return to normal reading.

Alarm codes:

‘P1’ Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

‘P2’ Flashing in the display: indicates that the evaporator sensor is defective.

This does not influence the operation of the cabinet, but should be repaired as soon as

possible.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the

contents of the cabinet is changed frequently it may become necessary to defrost the cabinet

manually.

Pressing this key continuously for more than 3 seconds will start a manual defrosting and

then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and evaporates.

Thermostat

The thermostat is placed in the control panel, see fig. 2.0.

Fig. 2.0

The thermostat has been pre-set and in most cases it is not necessary to adjust the settings.

When turning on the cabinet the display will show the current temperature in the cabinet.

Display set temperature:

Press this key and the display will show the set temperature. Press the key again to return to

normal reading

Set new temperature:

Press this key continuously for more than 3 seconds and the display shows the set

temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will flash with the new value and will

then return to normal reading.

Alarm codes:

‘P1’ Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

‘P2’ Flashing in the display: indicates that the evaporator sensor is defective.

This does not influence the operation of the cabinet, but should be repaired as soon as

possible.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the

contents of the cabinet is changed frequently it may become necessary to defrost the cabinet

manually.

Pressing this key continuously for more than 3 seconds will start a manual defrosting and

then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and evaporates.

Thermostat

The thermostat is placed in the control panel, see fig. 2.0.

Fig. 2.0

The thermostat has been pre-set and in most cases it is not necessary to adjust the settings.

When turning on the cabinet the display will show the current temperature in the cabinet.

Display set temperature:

Press this key and the display will show the set temperature. Press the key again to return to

normal reading

Set new temperature:

Press this key continuously for more than 3 seconds and the display shows the set

temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will flash with the new value and will

then return to normal reading.

Alarm codes:

‘P1’ Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

‘P2’ Flashing in the display: indicates that the evaporator sensor is defective.

This does not influence the operation of the cabinet, but should be repaired as soon as

possible.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the

contents of the cabinet is changed frequently it may become necessary to defrost the cabinet

manually.

Pressing this key continuously for more than 3 seconds will start a manual defrosting and

then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and evaporates.

Thermostat

The thermostat is placed in the control panel, see fig. 2.0.

Fig. 2.0

The thermostat has been pre-set and in most cases it is not necessary to adjust the settings.

When turning on the cabinet the display will show the current temperature in the cabinet.

Display set temperature:

Press this key and the display will show the set temperature. Press the key again to return to

normal reading

Set new temperature:

Press this key continuously for more than 3 seconds and the display shows the set

temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will flash with the new value and will

then return to normal reading.

Alarm codes:

‘P1’ Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

‘P2’ Flashing in the display: indicates that the evaporator sensor is defective.

This does not influence the operation of the cabinet, but should be repaired as soon as

possible.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the

contents of the cabinet is changed frequently it may become necessary to defrost the cabinet

manually.

Pressing this key continuously for more than 3 seconds will start a manual defrosting and

then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and evaporates.

Alarm codes:

PF1 – Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

PF2 – Flashing in the display: indicates that the evaporator sensor is defective. This

does not inuence the operation of the cabinet, but should be repaired as soon as

possible.

Maintenance and cleaning

Switch the cooler off at the socket.

The cabinet must be periodically cleaned. Clean the external and internal surfaces of the cabinet

with a light soap solution and subsequently wipe dry. External surfaces can be maintained using

steel oil.

Do NOT use cleansers containing chlorine or other harsh cleansers, as these can damage the

stainless steel surfaces and the internal cooling system.

Clean the condenser and the compressor compartment using a vacuum cleaner and a stiff brush.

Do NOT hose the compressor compartment with water as this can cause short circuits and damage

on the electrical parts.

Service

The cooling system is a hermetically sealed system and does not require supervision, only cleaning.

If the cabinet fails to cool, check if the reason is a power cut.

If you cannot locate the reason to the failure of the cabinet, please contact your supplier. Please

inform model and serial number of the cabinet. You can find this information on the rating label

which is placed inside the cabinet in the top right hand side.

Disposal

Disposal of the cabinet must take place in an environmentally correct way. Please note existing

regulation on disposal. There may be special requirements and conditions which must be observed.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet

is opened or the contents of the cabinet is changed frequently it may become

necessary to defrost the cabinet manually.

Pressing this key continuously for more than 3 seconds will start a

manual defrosting and then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and

evaporates.

Maintenance and cleaning

Switch the cooler off at the socket.

The cabinet must be periodically cleaned. Clean the external

and internal surfaces of the cabinet with a light soap

solution and subsequently wipe dry. External surfaces can be

maintained using steel oil.

Remove the condenser lter (see g. 2. 1), and clean it with a

vacuum cleaner and if necessary a light soap solution.

Do NOT use cleansers containing chlorine or other harsh

cleansers, as these can damage the stainless steel surfaces

and the internal cooling system.

Clean the condenser and the compressor compartment using a vacuum cleaner and

a stiff brush.

Do NOT hose the compressor compartment with water as this can cause short

circuits and damage on the electrical parts.

Service

The cooling system is a hermetically sealed system and does not require

supervision, only cleaning. If the cabinet fails to cool, check if the reason is a power

cut.

If you cannot locate the reason to the failure of the cabinet, please contact your

supplier. Please inform model and serial number of the cabinet. You can nd this

information on the rating label which is placed inside the cabinet in the top right

hand side.

Disposal

Disposal of the cabinet must take place in an environmentally correct way. Please

note existing regulation on disposal. There may be special requirements and

conditions which must be observed.

Thermostat

The thermostat is placed in the control panel, see fig. 2.0.

Fig. 2.0

The thermostat has been pre-set and in most cases it is not necessary to adjust the settings.

When turning on the cabinet the display will show the current temperature in the cabinet.

Display set temperature:

Press this key and the display will show the set temperature. Press the key again to return to

normal reading

Set new temperature:

Press this key continuously for more than 3 seconds and the display shows the set

temperature.

Press this key to increase the set temperature.

Press this key to lower the set temperature.

Press this key to save the new settings. The display will flash with the new value and will

then return to normal reading.

Alarm codes:

‘P1’ Flashing in the display: indicates that the cabinet sensor is defective.

The cabinet will strive to keep the set temperature until it has been repaired.

‘P2’ Flashing in the display: indicates that the evaporator sensor is defective.

This does not influence the operation of the cabinet, but should be repaired as soon as

possible.

Defrosting

The cabinet defrosts automatically with pre-set intervals. If the door to the cabinet is opened or the

contents of the cabinet is changed frequently it may become necessary to defrost the cabinet

manually.

Pressing this key continuously for more than 3 seconds will start a manual defrosting and

then return to normal operation.

Defrosted water runs to a container placed in the compressor compartment and evaporates.

g. 2. 1

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Delta Congelatore

Delta

Delta ERD124 Manuale utente

Manuali Congelatore popolari di altre marche

Siemens

Siemens GU..D SERIES Manuale utente

Omcan

Omcan FR-CN-0155 Manuale utente

Beko

Beko FNE290E24W Manuale utente

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuale utente

Electrolux

Electrolux EUF2042AOX Manuale utente

Dometic

Dometic CoolFreeze CFX95DZ Manuale utente

Electrolux

Electrolux EUF7000W1 Manuale utente

Polar Electro

Polar Electro CT330 Manuale utente

MPM

MPM MPM-145-SK Series Manuale utente

SAF

SAF PRESTOTIG 200AC/DC Guida rapida

Zanussi

Zanussi ZFT11407WA Manuale utente

AEG

AEG A63190GT Manuale utente

AEG

AEG A81000TNW0 Manuale utente

Matsui

Matsui MUC50S15E Manuale utente

NEFF

NEFF G4344X8 Manuale utente

Frigidaire

Frigidaire FV 1246 H Manuale utente

Frigidaire

Frigidaire FFC13K1AW Manuale utente

Electrolux

Electrolux EU 2400C Manuale utente
