Delta R10000-UNBX Manuale utente

OMPLIES WITH

•

ASME A

/ CSA B125.1

■

R10000-UN (Case Qty 12)

■

R10000-UNBX (Case Qty 3)

■

R10000-UNBXT (Case Qty 3)

■

R10000-UNWS (Case Qty 12)

■

R10000-PX (Case Qty 12)

■

R10000-PXWS (Case Qty 12)

■

R10000-IP (Case Qty 12)

■

R10000-IPWS (Case Qty 12)

Submitted Model No.:

_________________________________________________

Specific Features:

____________________________________________________

STANDARD SPECIFICATIONS:

• Forged brass body.

• Back-to-Back installation capabilities.

• Can be tested with air (200 PSI) or

water (300 PSI) without valve using

supplied test cap.

• Square plasterguard allows for right

angle cuts.

• Thin wall mounting.

• For use with Multi Choice

Universal

single or dual function trim. Cartridge

ships with trim.

UPC

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue

models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue

models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue

www.specselect.com for finish options and product availability.

models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or

www.specselect.com for finish options and product availability.

models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or

WARRANTY

• Lifetime Faucet and Finish Limited

Warranty to the original consumer

purchaser to be free from defects in

material and workmanship.

• 5 Year Limited Warranty for usage

in all industrial, commercial and

business applications.

R10000-UN

R10000-UNBX

R10000-UNBXT

R10000-UNWS

R10000-

PXWS

R10000-

IPWS

MULTICHOICE

™

UNIVERSAL

ROUGH VALVE

BODY

(102 mm)

3/8

(86 mm)

1/8

(54 mm)

4" (54 mm)

(102 mm) (54 mm)

(102 mm)

(54 mm)

(70 mm)

Stringer

Finished Wall

R10000-UN

R10000-UNBX

R10000-UNBXT

(102 mm)

1/16

(135 mm)

R10000-UNWS

55 E. 111th Street, Indianapolis, Indiana 46280

395 Matheson Blvd. E., Mississauga, ON L4Z 2H2

DSP-B-R10000 R

(54 mm)

3/8

(86 mm)

1/8

(54 mm)

(70 mm)

Stringer

Finished Wall

(102 mm)
