Denon PMA-1600NE Manuale utente
PMA-1600NE
INTEGRATED AMPLIFIER
ENGLISH
FRANÇAIS
ESPAÑOL
Quick Start Guide
Guide de démarrage rapide / Guía de inicio rápido
Lisez-moi en premier.... / Lea esto primero....
Read Me First....
1
Welcome Before You Begin
What’s In the Box
Quick Start Guide
Integrated
Amplifier
CD-ROM
(Owner’s Manual)
Power cord
Safety Instructions Remote control
unit (RC-1213)
Warranty
(for North America
model only)
R03/AAA batteries
Thank you for choosing a Denon amplifier. This guide
provides step-by-step instructions for setting up your
amplifier.
Please do not return this unit to the store – call for
assistance.
If you need help… :
If you need additional help in solving problems, contact
Denon customer service in your area.
For details, see the Denon homepage. www.denon.com
2
Required for Basic connections
CD player
Speaker systems
Speaker cables
Optional
Computer USB cable
• These drawings are for illustrative purposes only and may
not represent the actual product(s).
3
1Install batteries in the
remote control unit
Batteries
There are seven steps to the setup
process.
1Install batteries in the remote control unit
2Connect the speakers to the amplifier
3Connect the CD player to the amplifier
4Plug the power cord into a power outlet
5Begin CD playback
6Installing the Windows driver software
7Enjoying music using PC or Mac
Setup
4
2Connect the speakers to the amplifier
(L)
w q
(R)
w q
Connecting the speaker cables
qPeel off about 3/8 inch (10 mm)
of sheathing from the tip of the
speaker cable, then either twist
the core wire tightly or apply
solder to it.
wTurn the speaker terminal
counterclockwise to loosen it.
eInsert the speaker cable’s core
wire to all the way into the
speaker terminal.
rTurn the speaker terminal
clockwise to tighten it.
5
3Connect the CD player to the amplifier
AUDIO
OUT
R L
L
R
L
R
CD player
6
4Plug the power cord into a power outlet
Power cord (supplied)
Connect to household
power outlet
(AC 120 V, 60 Hz)
7
5Begin CD playback
2
Press the power operation button.
Turn VOLUME on the main unit to adjust the volume to
the lowest level before turning on the power.
Set the input source to “CD”.
“CD” is displayed on the display of this unit.
Play the CD player.
Adjust the volume.
1
2
3
4
2
4
4
1
8
6Installing the Windows driver software
Download the dedicated driver from the
“Download” section of the PMA-1600NE
page of the Denon website (http://www.
denon.com/pages/home.aspx) onto your PC.
Unzip the downloaded le, and
double-click the exe le.
Install the driver.
qSelect the language to use for the installation.
wClick “OK”.
q
w
1
2
3
eThe wizard menu is displayed. Follow the
instructions on the screen.
rWhen the wizard is completed, click “Yes”.
r
NOTE
• The driver software cannot be installed correctly if your
PC is connected to the unit by a USB cable.
• If the unit and your PC are connected by a USB cable
and the PC is switched on before installation, disconnect
the USB and restart the PC.
• Please see the FAQ at www.denon.com if you
experience any issues getting audio to play from your PC
through the PMA-1600NE. You may also want to check
the support pages for your audio player application.
NOTE
• The installation of the driver software is not necessary in
the following cases.
• When you do not play back the music from a PC using
USB-DAC of this unit.
• When using a Mac OS.
9
7Enjoying music using PC or Mac
nConnect to PC or Mac
Connect to PC or Mac.
Computer on which
the driver software
and audio player
software are installed
USB 2.0 cable
(Sold separately)
Type B
Type A
Press Xon this unit.
• When the unit power is turned on, the computer
automatically finds and connects to the unit.
1
2
nListen to PC or Mac Audio
Press USB-DAC to change
the input source to “USB-
DAC”.
Set the audio signal destination to this unit on
the computer.
• Windows 7, Windows 8, Windows 8.1 or
Windows 10
• Mac OS X 10.10, 10.11 or macOS 10.12
System Requirements
[Windows OS]
qClick the “Start” button and click “Control Panel”
on the PC.
• The control panel setting list is displayed.
wClick the “Sound” icon.
• The sound menu window is displayed.
1
2
