Denon D-T1 Manuale utente
D-T1
CD RECEIVER SYSTEM
Quick Start Guide
Guide de démarrage rapide / Guía de inicio rápido
Lisez-moi en premier.... / Lea esto primero....
Read Me First....
ENGLISH
FRANÇAIS
ESPAÑOL
1
Thank you for choosing a Denon CD receiver
system. This guide provides step-by-step
instructions for setting up your CD receiver
system.
Please do not return this unit to the store
– call for assistance.
If you need help… :
If you need additional help in solving
problems, contact Denon customer service
in your area.
For details, see the Denon homepage.
www.denon.com
Welcome Before You Begin
What’s In the Box
Quick Start Guide
FM indoor antenna
Safety Instructions AM loop antenna
Notes on radio Remote control unit
(RC-1229)
Warranty
(for North America
model only)
R03/AAA batteries
CD receiver Speaker systems
Power cord Speaker cables
• These drawings are for illustrative purposes only and may not represent the actual
product(s).
2
Before You Begin
1Connection
R
L
Connect the left and right speakers to
the D-T1.
Insert the
batteries into
the remote.
Connect the power
cord from the
D-T1 to a power outlet.
1
2 3
nConnecting a FM/AM antenna
wq e
AM loop
antenna
(supplied)
White Black
FM indoor antenna
(supplied)
• See “AM loop antenna assembly” on the next page for instructions on
how to assemble the AM loop antenna.
3/8 inch
(10 mm)
3
5Enjoying your music!
2
Press CD to switch the input source to
“CD”.
Insert a disc.
Press 1/3.
Playback starts.
1
2
nPlay a CDnAM loop antenna assembly
Put the stand section through the
bottom of the loop antenna from the
rear and bend it forward.
Insert the projecting part into the
square hole in the stand.
Loop antenna
Stand
Square hole
Projecting part
1
2
3
4
Tune in the station you want to
preset.
Press ENTER.
The preset number flashes.
Use 0 – 9, +10 or PRESET +, – to
select the number to be preset, then
press ENTER.
The reception frequency and reception mode are
preset.
1
2
3
nListening to preset FM/AM stations
This unit can be preset with a total of 40 broadcast
stations. (FM: 30 stations, AM: 10 stations)
Use FM or AM to select the reception
band.
Use TUNE + or TUNE – to select the
station you want listen to.
• FM放送局を受信中にMODEを繰り返し押すと、FM受信モードをステ
レオ受信モード（STEREO）とモノラル受信モード（MONO）に切り
替えます。電波が弱く、安定したステレオ受信ができないときは、モノ
ラル受信モードにしてください。お買い上げ時は“STEREO”に設定
しています。
1
2
nListening to FM/AM broadcasts
5
nEnjoying music using Bluetooth
Press Bluetooth to
switch the input source
to “BT AUDIO”.
When using for the first time, the
unit will go into the pairing mode
automatically and “PAIRING” will
appear on the display of the unit.
Activate the Bluetooth
settings on your mobile
device.
Bluetooth ON
Denon RCD-M41
Bluetooth
1
2
Select “Denon D-T1”
from the Bluetooth device
list on your mobile device.
• Enter “0000” when the
password is requested on
the screen of the Bluetooth
device.
Bluetooth ON
Denon D-T1
Bluetooth
Play music using any
app on your device.
Bluetooth ON
Denon RCD-M41
Bluetooth
3
4
To reconnect a previously paired Bluetooth
device, Start at step 2.
6
Owner’s Manual
PDF
Overview
Connections
Playback
Settings
Tips
Appendix
PDF Download
CD RECEIVER SYSTEM
CD RECEIVER SYSTEM
WEB Manual
Copyright © 2018 D&M Holdings Inc. All Rights Reserved.
D-T1
Contents
English
Online Manual
• For more information, visit www.denon.com
• Refer to the Online Manual for other functions
information and operation procedure details.
manuals.denon.com/DT1/NA/EN/
Specifications
oAudio section
0CD player
Playable frequency response: 2 Hz - 20 kHz
Wow & flutter: Below measurable limits (± 0.001 %)
Sampling frequency: 44.1 kHz
0Audio amplifier
Rated output: 2-channel
15 W + 15 W (6 Ω/ohms, 1 kHz, T.H.D. 10 %)
oTuner section [FM] [AM]
Receiving Range: 87.5 MHz – 107.9 MHz 520 kHz – 1710 kHz
Effective sensitivity: 1.2 μV / 75 Ω/ohms 20 μV
FM STEREO separation: 35 dB (1 kHz)
FM S/N ratio: Monaural : 65 dB
Stereo : 60 dB
FM THD+N (1 kHz): Monaural : 0.2 %
Stereo : 0.5 %
Contents Connections Playback Settings Tips Appendix
70
Front panel Display Rear panel Remote Index
oBluetooth section
Communications system: Bluetooth Version 4.0
Transmission power: Power Class 2
Maximum communication range: Approx. 10 m in line of sightz
Frequency band: 2.4 GHz band
Modulation scheme: FHSS (Frequency-Hopping Spread Spectrum)
Supported profiles: A2DP (Advanced Audio Distribution Profile) 1.2
AVRCP (Audio Video Remote Control Profile) 1.4
Corresponding codec: SBC, MP3, AAC
Transmission range (A2DP): 20 Hz - 20,000 Hz
zThe actual communication range varies depending on the influence of such factors as obstructions between devices, electromagnetic waves from
microwave ovens, static electricity, cordless phones, reception sensitivity, antenna performance, operating system, application software etc.
Contents Connections Playback Settings Tips Appendix
71
Front panel Display Rear panel Remote Index
oClock/Alarm/Sleep
Clock type: Crystal oscillator (Within 1 – 2 minutes per month)
Alarm: Once alarm/Everyday alarm: One system each
Sleep: Sleep timer: Max. 90 minutes
oGeneral
Power supply: AC 120 V, 60 Hz
Power consumption: 30 W
Power consumption in clock mode : 14 W
Power consumption in standby mode : 0.3 W
0For purposes of improvement, specifications and design are subject to change without notice.
