Denver BFH-15 Manuale utente
DENVER BFH-15
Smart Band
0102
05
44
SAT
Imported by:
DENVER ELECTRONICS A/S
Omega 5A , Soeften
DK-8382 Hinnerup
Denmark
User’s Manual
English----------------------------------
German---------------------------------
Danish-----------------------------------
Spanish---------------------------------
French-----------------------------------
Italian------------------------------------
Dutch------------------------------------
Norwegian------------------------------
Polish------------------------------------
Portuguese-----------------------------
Swedish---------------------------------
Finnish-----------------------------------
1
5
9
13
17
21
25
29
33
38
42
46
4
8
12
16
20
24
28
32
37
41
45
49
contents
Smart Band
User Guide
Working condition for mobile
iOS 8.0 & above
Android 4.4 & above
Support Bluetooth 4.0
Quick Start Guide
1. Download DENVER BFH-15 app
The smart band need to pair with the smart phone through app. Before downloading, please refer to working
condition for mobile.
Way to download 1: Searching the QR code, scan and download app.
Please use the QR code Scan tool to scan the following QR code and open the link and download app. In case
there is any problem to open the link, please try to copy the link and open it by browser.
Way to download 2: Search in the phone market and download. Please search and download the “DENVER
BFH-15”from App Store or Google play store.
2. Device Activate & Charge
Make sure power is working normally before initial use. In case device is under low battery, connect the device
to the charger. Device will automatically boot up (please connect the USB in normal DC port (5V-500mA) for
charging as below. The host should be separated from the strap when charging).
3. Pair the device
Open pair device in the app, please make sure the Bluetooth is ON when pair the device. When searching and
pairing device, please long press on the screen of the device and activate the device (light on). App will search
the device automatically, choose the device name and connect the device to the app.
1
How to Use
Key Definitions:
Tap: function switch
Long Press: activate, mode switch
Once the device connected to the app successfully, it will record and analyze your activities and sleep
automatically, Touch the click toggle, the display order is as follows
1. Normal Mode
Time Mode Step mode
Distance mode Calories Mode
Heart Rate Mode
2. Heart Rate Mode
Click to bpm mode, the blue light open, keep fitness bands touching your hand, the display will show heart
rate date;
3. Notification Mode
Incoming call notify Message notify
Alarming notify Sedentary notify
Low-power notify Charging notify
Charging full notify
Notification Mode instruction:
1. Under incoming call, message notify mode, the screen will still display the last time text and sliding, when
there is a new notification coming in.
2. If there is a call or message come, the device will force into call/message alert mode no matter under
whatever other mode, after quit, it returns to previous mode.
Functions Instruction
Activities Record:
Record daily activities, you could check daily activities including steps, distance and calorie consumption in the
app;
Sleep Monitoring:
2
Device could automatically recognize your state and monitoring the whole sleep progress with analyzing the
deep sleep and light sleep hours;
Notification Alerts:
Alarm alert, call alert, sedentary alert, etc. by silent vibration;
Anti-Lost:
When the smart phone is beyond the Bluetooth range (5m), the device vibrates to remind.
Remote Camera Control:
Operation on the screen could control remote photograph shooting.
Device Data Storage:
The activity data will be cleared every 0:00am as a cycle, but the device itself could restore 7 days’data, after 7
days, the data will be cleared. We suggest user to sync data with app at least one time within 7 days during use.
FAQ
Can’t find device when pairing device?
Please make sure the smart phone Bluetooth is ON and smart phone OS Android 4.4 & above and iOS 8.0 &
above.
Please make sure the device is near the smart phone when pairing (normal 0.5m) and among the normal
Bluetooth communication distance range (within 10m).
Please make sure the device is not under low battery. If there is still problem after full charge, please contact us.
Can’t connect the device with app?
Some smart phone Bluetooth service will be abnormal when reboot. Please reboot the Bluetooth or reboot smart
phone for pairing device.
How to Restore Factory Defaults
Make sure the device is connected with app, go in the app, enter “Mine-System Setting” and choose “Reboot
Device”.
How to update the device
Make sure the device is connected with app, go in the app “Device”-“Device update”, please wait some minutes
before update done.
Basic Specifications
Model: BFH-15
CPU: Realtek 8762-AG
Sensor: Gravitational acceleration sensor
Host Weight: 19g
Battery Type: Polymer Rechargeable Li Battery
Battery Capacity:50mAh
Data Sync: Bluetooth 4.0
Working Temperature: -10C--45C
Dustproof and Waterproof level: IP65
Standby: more than 7 days
3
Frequency bands: 2402-2480MHz
Maximum output power: 0dBm
This product is applied with professional Bluetooth RF signal and self developed algorithm, the accuracy of
step pedometer could be up to 95%.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/
Electric and electronic equipment and included batteries contains materials, components and substances that
can be hazardous to your health and the environment, if the waste material (discarded electric and electronic
equipment and batteries) is not handled correctly.
Electric and electronic equipment and batteries is marked with the crossed out trash can symbol, seen below.
This symbol signifies that electric and electronic equipment and batteries should not be disposed of with other
household waste, but should be disposed of separately.
As the end user it is important that you submit your used batteries to the approriate and designated facility. In
this manner you make sure that the batteries are recycled in accordance with legislature and will not harm the
environment.
All cities have established collection points, where electric and electronic equipment and batteries can either be
submitted free of charge at recycling stations and other collection sites, or be collected from the households.
Additional information is available at the technical department of your city.
Hereby, Inter Sales A/S declares that the radio equipment type BFH-15 is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:
www.denver-electronics.com/products/denver-bfh-15/c-1024/p-3195
Operating Frequency Range: 2402-2480MHz
Max Output Power: 0dBm
Imported by:
DENVER ELECTRONICS A/S
Omega 5A, Soeften
DK-8382 Hinnerup
Denmark
www.facebook.com/denverelectronics
4
