MAINTENANCE AND OPERATION

INSTRUCTION MANUAL

Publish Date: 20-Jan-2023

DB8008

Digital Silence Monitor

with MP3 and IP Audio Backup Players

Contents

Introduction........................................................................................................................................ 5

Typographic conventions .................................................................................................................. 6

General Information.......................................................................................................................... 7

Product Features ................................................................................................................................ 8

Technical Specications .................................................................................................................. 9

Block Diagram .............................................................................................................................. 11

Safety Precautions............................................................................................................................ 12

Before you start ................................................................................................................................ 13

Mains Voltage Selector ................................................................................................................. 13

Power Cord .................................................................................................................................. 13

Operating Recommendations ....................................................................................................... 14

Radio Frequency Interference (RFI) ............................................................................................. 14

Unpacking and Inspection............................................................................................................... 15

Mounting .......................................................................................................................................... 15

Rack Requirement ......................................................................................................................... 15

Heat Dissipation ........................................................................................................................... 15

Panel Indicators and Connectors ................................................................................................... 16

Front Panel.................................................................................................................................... 16

Rear Panel..................................................................................................................................... 17

GPIO Connector Pinouts .............................................................................................................. 18

Electrical Characteristics of Optocouplers.............................................................................. 18

Navigation Through LCD Menu .................................................................................................... 19

The Basics ..................................................................................................................................... 19

Menu Structure.............................................................................................................................. 20

Restore Factory Defaults............................................................................................................... 28

Connecting DB8008 ........................................................................................................................ 29

Analog Audio Inputs ..................................................................................................................... 29

Digital Audio Input ....................................................................................................................... 29

LAN Port ....................................................................................................................................... 29

Operation.......................................................................................................................................... 30

Manual IP Identication ............................................................................................................... 30

Network Discovery ........................................................................................................................ 32

DB8008 WEB interface menu pages .............................................................................................. 34

Status ............................................................................................................................................. 34

Input .............................................................................................................................................. 35

Main and AUX Input ................................................................................................................ 35

IP Audio Client ......................................................................................................................... 36

Backup........................................................................................................................................... 37

Audio Loss and Audio Recovery............................................................................................... 37

Audio Monitor Mode ................................................................................................................ 37

MP3 Audio Player .................................................................................................................... 37

MP3 Files Upload via FTP ..................................................................................................... 38

Jingle Player............................................................................................................................. 38

Jingle Files Upload via FTP .................................................................................................... 38

How can a playlist le be made?.............................................................................................. 38

Output............................................................................................................................................ 39

Analog Audio.................................................................................................... 39

Digital Audio ............................................................................................................................ 39

IP Voice Announcement ............................................................................................................ 39

Dayparts........................................................................................................................................ 40

General.......................................................................................................................................... 41

Network ......................................................................................................................................... 42

Network..................................................................................................................................... 42

E-mail ....................................................................................................................................... 42

HTTP Server............................................................................................................................. 43

FTP Server................................................................................................................................ 43

SNMP Agent ............................................................................................................................. 43

Other ............................................................................................................................................. 44

Firmware Update ..................................................................................................................... 44

Storage...................................................................................................................................... 44

Factory Defaults....................................................................................................................... 44

Reboot....................................................................................................................................... 44

System Log................................................................................................................................ 45

UPnP discovery in Local Networks ................................................................................................ 46

UPnP Activation ............................................................................................................................... 47

APPENDIX A ................................................................................................................................... 48

List of DB8008 Jumper Settings for Analog Signals..................................................................... 48

DB8008 Jumpers Location............................................................................................................ 49

DB8008 Conguration with Impedance 10kΩ and 0dBu analog Input and Output Range 50

DB8008 Conguration with Impedance 600Ω and +18dBu analog Input and Output Range 51

APPENDIX B ................................................................................................................................... 52

How should I congure the connection between my DEVA Device and an FTP Client? 52

WARRANTY TERMS AND CONDITIONS................................................................................. 54

Product Registration Card.............................................................................................................. 55

THIS PAGE

IS INTENTIONALLY

LEFT BLANK

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 5 -

Introduction

DEVA Broadcast Ltd. is an international communications and high-technology manufacturing

organization, its corporate headquarters and facility located in Burgas, Bulgaria. The company

serves the broadcast and corporate markets worldwide – from consumers and small businesses to

the largest global organizations. It is dedicated to the research, design, development and provision

of advanced products, systems and services. DEVA Broadcast launched its own brand back in

1997 and has nowadays evolved to become known as a market leader and internationally reputed

manufacturer of user-friendly, cost-eective and innovative broadcast products.

Creativity and innovation are deeply woven into DEVA Broadcast corporate culture. Through

successful engineering, marketing and management our team of dedicated professionals creates

future-oriented solutions to improve customers’ performance. You may rely that all issues

communicated to our crew would be addressed accordingly. We pride ourselves on our pre and

post-sales support and purchase services, which along with the outstanding quality of our radio

gear have won us due respect and the market authority position.

DEVA Broadcast best-of-breed solutions have become the best sellers for our partners. The

strategic partnerships which have been formed with industry leaders during all these years that

we have been operating on the broadcasting market, have proved us a reliable business partner

and a valuable asset, as our dealers worldwide would conrm. In constant pursuit of precision and

long-term satisfaction, DEVA Broadcast enhances the reputation of our partners and clients alike.

Furthermore, we have already a proven merit as a credible partner provider.

Our portfolio oers complete line of high quality and competitive products for FM and Digital

Radio, Radio Networks, Telecommunication Operators and regulation authorities. For almost

two decades of intensive software and hardware development, we have achieved a unique price-

performance and endurance of our product lines. Our company’s multitude of equipment and

services is in line with the latest technologies and key trends. The most recognizable characteristics

attributed to DEVA Broadcast products are their clear-cut, streamlined design, easiness of use and

cost-eectiveness: simplicity of forms but multiplicity of functions.

For us there is no stage when we deem that we have reached the most satisfactory level in

our work. Our engineers are in constant pursuit of new ideas and technologies to be captured in

DEVA Broadcast solutions. Simultaneously, a strict control is being exercised at each step of any

new development. Experience and hard work are our fundament but the continuous improving

process is what we never leave aside. DEVA Broadcast participates on a regular basis in all

landmark broadcasting events, not only to promote its products, but to exchange valuable know-

how and experience. We are also engaged in international large-scale projects involving radio and

audio solutions which makes us even more competitive on the global market.

All DEVA Broadcast products are developed and produced in accordance with the latest ISO

9001 quality control standards.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 6 -

Typographic conventions

The following table describes important conventions used in the manual.

Convention and Style Description Examples

Menu > Sub Menu >

Menu Command

A menu item(s) and menu

command that you need to click

in sequence

Click Settings > General

[Button] Interface Interactive buttons Press [OK] to save the changes

NOTE Important notes and

recommendations

NOTE: The notication will appear

only once

“Reference Name” on

Page XXX

References and links refer to “New Connection”

(see “Monitoring” on page 56)

Example Used when example text is cited Example for E-mail Notication:

Date: 04 Nov 2013, 07:31:11

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 7 -

General Information

DEVA’s DB8008 is a exible and reliable tool, designed by our engineers specically with

the aim of solving one of the most signicant problems in the radio industry – the one of radio

silence. DEVA’s smart and highly practical solution detects signal loss and immediately switches

the output to one of two alternative built-in backup players – MP3 or IP Audio. As an additional

advantage, it also allows for easy integration into the existing setups of a single station and large

radio networks alike.

The MP3 backup audio les and playlists can be uploaded to the device using any FTP client,

making this model not only ecient but also easy to use. The audio storage capacity of the unit is

an impressive 2GB for over 24 hours of audio playback without repetition. Moreover, the backup

sources priority is selected by users themselves.

The DB8008 features a fully DSP-based core, professional AES/EBU digital audio inputs and

outputs, and additionally allows for TCP/IP remote monitoring and control via SNMP and the WEB

Interface, which means that the device can also be used for local content or regional advertisement

spots. Another option provided by the model is the alert notications via email, SNMP or analog

opto-coupled outputs in case of signal loss.

Developed to provide users with a tool for an infallible and constant audio feed, the DB8008

is trademark DEVA device oering a simple and subtle solution to the problem of radio silence.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 8 -

Product Features

• Fully DSP based core

• Intelligent Silence Detector and Backup Audio Switcher

• Scheduler for disabling the Silence Detector and Forcing the Source for predened period

of time

• User selectable backup audio sources priority

• Conguration and Monitoring via SNMP, WEB, Front Panel LCD and Keyboard

• Alert Notications via E-mail, SNMP, Analog opto-coupled Outputs

• Lots of Storage for over 24 hours of non-repeating audio playback

• Always Fresh Backup Audio Tracks with Embedded FTP server

• Professional Balanced Stereo analog inputs and outputs on XLR connectors

• Professional AES/EBU Digital audio inputs and output on XLR connectors

• Consumer S/PDIF Digital audio inputs and output on Optical and Coaxial connectors

• Headphones Jack on the front panel for local monitoring of the Audio Signal

• TCP/IP Remote monitoring and control via SNMP and WEB Interface

• Variety of Audio Sources

• Multiformat IP Audio Stream (three separate sources)

• Multiformat Real-Time Transport Protocol (RTP) Stream Receiver

• Multiformat Icecast compatible Stream Receiver

• Built-in SD Card MP3 Player

• External or internal Digital clock sync

• Digital Volume Control of all Audio Sources

• Protected access to the device settings

• UPnP for easy discovery in Local Networks

• Professional 19 inches, 1U aluminum rack mount chassis

• Wide Range Internal Power Supply 100-240VAC 50-60Hz

• Easy installation and operation

• Remote Firmware Upgrade for future-proof operation

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 9 -

TECHNICAL SPECIFICATIONS

MAIN ANALOG AUDIO INPUTS

Connectors Balanced XLR

Impedance 600Ω or high impedance

Level 0dBu or +18dBu Jumper selectable, with digital gain adjustments

Dynamic range >80dB

Digital Gain Adjust -10dB to +10dB

MAIN DIGITAL AUDIO INPUTS

Connectors Balanced XLR, Coaxial, Optical

Sample Rates 32, 44.1, 48 and 96kHz

Digital Gain Adjust -10db to +10dB

AUX ANALOG AUDIO INPUTS

Connectors Balanced XLR

Impedance 600Ω or high impedance

Level 0dBu or +18dBu Jumper selectable, with digital gain adjustments

Dynamic range >80dB

Digital Gain Adjust -10dB to +10dB

AUX DIGITAL AUDIO INPUTS

Connectors Balanced XLR, Coaxial, Optical

Sample Rates 32, 44.1, 48 and 96kHz

Digital Gain Adjust -10dB to +10dB

RTP RECEIVER

Stream Formats MP3, AAC

Bit Rates All standard bit rates, including VBR

ICECAST PLAYER

Stream Formats PCM (32, 44.1, 48kHz), MPEG1 Layer 3 (MP3), HE-AAC (v.1 and v.2)

Bit Rates All standard bit rates, including VBR

IP AUDIO SOURCE

Number of Streams one main and two alternative streams with auto-switch on failure

Stream Clients shoutcast, icecast

Stream Formats PCM, MPEG1 Layer 3 (MP3), HE-AAC (v.1 and v.2); all at 32, 44.1,

48kHz only

Bit Rates All standard bit rates, including VBR

Number of Channels Mono, Stereo

Buer Size Adjust 5Kb to 64Kb

Digital Gain Adjust -10dB to +10dB

BUILT-IN MP3 PLAYER

Storage Capacity 2Gb on SD Card

Supported encoders HE-AAC (v.1 and v.2), MPEG-1 Layer 3

MP3 bit rates 32-320 kbps and VBR

Sample rates All sampling frequencies specied by MPEG1 L1/L2/L3 (32, 44.1 and

48kHz)

Supported le types *.MP3, *.AAC, *.M4A, *.M3U

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: o󰀩[email protected] ,Web: www.devabroadcast.com

- 10 -

Playback modes Alphabetical ascending and descending, Shue, Playlist and Shued

playlist

Remote le management Build-in FTP server

Digital Gain Adjust -10dB to +10dB

ANALOG AUDIO OUTPUT

Connector Balanced XLR

Frequency response ±0.5dB, 5Hz-20kHz

Distortion <0.01% THD+N

Level 0dBu or +18dBu Jumper selectable, with digital gain adjustments

Dynamic range >80dB

Digital Gain Adjust -10dB to +10dB

DIGITAL AUDIO OUTPUTS

Connectors Balanced XLR, Coaxial, Optical

Sample rates 32, 44.1, 48kHz

Digital Gain Adjust -10dB to +10dB

PHONES AUDIO OUTPUT

Connector 1/4” (6.3mm) jack, stereo

Type Headphones

SILENCE DETECTOR

Threshold Adjustable from -40dBfs to -5dBfs

Trigger time 10-250 sec

Scheduler for disabling Silence Detector and Forcing Audio Source to predened

Source or Silence

USER INTERFACE

Indicators 5 LEDs on front panel, 2 LEDs on rear panel

Web interface control, conguration and status information

SNMP interface control, conguration and status information

Front Panel LCD with Keyboard

Pin Input Pin Input (DB9 Connector on Rear Panel) to externally force the audio

source to predened source

ALARM NOTIFICATIONS

Notify via SNMP, E-mail or Output Pins on DB9 Connector (Rear Panel)

NETWORK

Connector RJ-45

Type Ethernet

Device Discovery UPnP support

OPERATING CONDITIONS

Temperature 10°C - 45°C

Humidity < 75%, non-condensing

POWER REQUIREMENTS

Power supply 115/230V AC (internal switch), 18VA

Connector IEC320, rear panel

SIZE AND WEIGHT

Dimension (W x H x D) 1U, 19” x 1.7” x 6.9”, 483 x 45 x 160 mm

Weight 8 lbs, 3kg
