Devilink™ RS
Installation Manual
GB-DAS
Devilink™ CC
Devilink™ FT
2
Devilink™ RS
Ambient temperature
Floor temperature
Communication/link test
Battery warning
Tamper proof. Locked by CC
e Devilink™ RS (Room Sensor) has a built-in tempera-
ture sensor which measures the ambient temperature. It
allows you to control the heating based on room tempera-
ture, in the room where installed. With the Devilink™ RS
you can also adjust the temperature.
Installation scenario:
Placement of DevilinkTM RS
3
Placement of Devilink™ RS
Not on a wall where it will be subjected to direct
sunlight.
Installation height should typically be between
80-150 cm.
In wet rooms it should be installed on an even
surface, according to local building regulations.
At least 50 cm away from windows/doors that
will be le open occasionally.
Not on the inner side of a wall facing the
outside.
4
3. Light indications (LED)Installation of Devilink™ RS
1. Remove the front cover by gently
pressing the release tab on the
bottom side of the sensor.
2. Mount the room sensor
a. Mark up drill holes
b. Drill holes
c. Place xing plugs in holes
d. Screw mount the RS
3. Mount batteries
4. Put front cover on by placing the top
of the cover in place rst and then
gently press the bottom end in place.
Conguration:
See Step-by-Step guide in Devilink™ CC instruction
manual.
5
Trouble shooting
Short green ash Not included in network
Green fast ash Inclusion in progress
Red ash +
for 5 sec.
Inclusion failed
ON Link test in progress
Red ash +
for 5 sec.
Link test failed
ON + Red LED
ash every 2½ min.
Low battery level
ON + Red LED
ash every 30 sec.
Critical battery level
E5 Floor sensor short circuited
E6 Floor sensor lost
ON
Tamper proof enabled by
Devilink™CC
Flash Limited by Devilink™CC
Factory reset a Devilink™ RS:
Take the front cover o . Take out one battery and hold the
ON/OFF/Install button down while reinserting the battery.
Keep holding down the install button until it ashes (ap-
prox. 5 sec.)
6
Battery Alkaline 2xAA, 1.5V
Battery lifetime Up to 4-5 years
Backlight Green LED
Ambient temperature 0˚ to +40˚C
Battery monitoring e sensor has a built-in
monitoring circuit, which will
detect low or critical battery
level.
Transmission
frequency
868.42MHz
Transmission range in
normal buildings Up to 30m
Transmission power Max. 1 mW
IP class 21
Dimensions 81 mm x 66 mm x 21 mm
Disposal Instruction:
Equipment containing electrical components should not
be disposed together with domestic waste.
It must be collected separately with other electrical and
electronic waste according to local legislation.
Technical specications
The 2 Year DEVI Warranty
You have purchased a DEVI heating system
which we are sure will serve to improve the
comfort and economy of your application.
DEVI provides superior electrical heating solu-
tions for total climate control in and around
homes and buildings. DEVI oers a complete
product program with DeviexTM heating cables
or DevimatTM heating mats, DeviregTM thermo-
stats, DevifastTM xing strips and Devi Self-lim-
iting heating cables combined with additional
products completing the product program.
This 2 year warranty applies to all DEVI prod-
ucts.
Should you, against all expectations, experience
a problem with your DEVI product, you will nd
that DEVI oers a 2 year warranty from the date
of purchase on the following conditions:
During the warranty period DEVI shall oer a
new comparable product or repair the product
in case the product is found to be faulty by rea-
son of defective design, materials or workman-
ship. Repair or replacement shall be carried out
at DEVI’s discretion. DEVI shall not be liable for
any consequential or incidental damages in-
cluding, but not limited to, damages to property
or extra utility expenses.
This warranty shall only be valid on production
of proof of purchase and must be submitted to
the installer or seller without undue delay.
An extension of the warranty period following
repairs undertaken under warranty cannot be
granted.
The DEVI Warranty shall not cover any damage
caused by incorrect conditions of use, incorrect
installation or if installation has been carried out
by non-authorised electricians. All work will be
invoiced in full if DEVI is required to inspect or
repair faults that have arisen as a result of any
of the above.
The DEVI Warranty shall not extend to equip-
ment which has not been paid in full.
DEVI will, at all times, provide a rapid and ef-
fective response to all complaints and inquiries
from our customers.
The warranty explicitly excludes all claims ex-
ceeding the above conditions.
Attention:
The Warranty Certicate must be completed correctly for the Warranty to be valid.
Please read the Warranty conditions above.
The DEVITM Warranty is granted to:
Name:
Telephone:
Warranty Certificate
Address:
City:
Type of thermostat:
Article number: Date:
Suppliers Stamp:
Country:
Electrical installation by:
Article: 08095916
Version: 01.01
DEVI A/S
DK • 7100 Vejle
Phone +45 76 42 47 00
Fax +45 76 42 47 03
