DS-TACHO-2
TECHNICAL REFERENCE MANUAL
DS-TACHO-2 V20-1
1
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
1. Table of contents
1. Table of contents 2
2. About this document 3
2.1. Legend 3
3. Introduction 4
4. Specifications 5
5. Operating instructions 6
6. Set up in DEWESoft 7
7. Measurement 8
8. Warranty information 9
8.1. Calibration 9
8.2. Support 9
8.3. Service/repair 9
8.4. Restricted Rights 9
8.5. Printing History 10
8.6. Copyright 10
8.7. Trademarks 10
9. Safety instructions 11
9.1. Safety symbols in the manual 11
9.2. General Safety Instructions 11
9.2.1. Environmental Considerations 11
9.2.2. Product End-of-Life Handling 11
9.2.3. System and Components Recycling 11
9.2.4. General safety and hazard warnings for all Dewesoft systems 12
10. Documentation version history 15
DS-TACHO-2 V20-1 2/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
2. About this document
2.1. Legend
The following symbols and formats will be used throughout the document.
Important
It gives you important information about the subject.
Please read carefully!
Hint
It gives you a hint or provides additional information about a subject.
Example
Gives you an example of a specific subject.
DS-TACHO-2 V20-1 3/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
3. Introduction
DS TACHO 2 is a remote optical LED sensor. It has a visible red LED light source and green LED on-target
indicator. The red LED light source acts as the aiming device during setup and can accurately measure
speeds from 1 up to 250000 RPM from a distance of up to 1 meter with a maximum offset angle of 45
degrees from the rotating object. The sensor is housed in a threaded stainless-steel tube and supplied
with a 90-degree mounting bracket and a 2.5 meter shielded cable.
Common usage of the sensor is in a wide range of general purpose applications in relatively clean
environments.
DS-TACHO-2 V20-1 4/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
4. Specifications
Speed range
1 – 250 000 RPM
Distance to object
Up to 1 meter and 45 degrees offset from target
Power supply
3-15VDC, 45mA
Operating temperature
3-15VDC, 45mA
Connector
L1B7m connector for SIRIUS and DEWE-43 counter input
Output signal
Negative pulse input voltage (+V) to 0
Dimensions
74 mm length, 16mm diameter
Cable length
2.5 meters
DS-TACHO-2 V20-1 5/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
5. Operating instructions
The remote optical sensor is capable of detecting a reflected pulse from a target consisting of reflective
tape at distances of up to 1 meter from the rotating object and angles up to 45 degrees.
For most applications, a 12-mm square piece of reflective tape should be applied to a clean area on the
rotating object. The sensor should be optically aligned to illuminate the on-target indicator once per
revolution. The sensor must be mounted steady to obtain accurate measurement. The optical sensor
must be placed at a slight angle (15 degrees recommended) from perpendicular, so that the sensor will
receive only pulses from the reflective marker.
The optical sensor must be at least 25 mm from the reflective target to avoid false triggering. The green
LED on-target indicator will blink at the input frequency rate when the sensor is properly aimed.
NOTE : The green LED On-Target Indicator will blink on and off at slow speeds and
remain on steady at high speeds.
DS-TACHO-2 V20-1 6/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
6. Set up in DEWESoft
Connect the sensor to the counter input (ACC+, STG+, Multi, …) and enter the counter setup.
Under the Basic application select Sensor (encoder, CDM, tacho…) mode. From the dropdown menu
select the Tacho (Digital) as a sensor type. It depends on the connection of the sensor which signal is
selected as Signal input (CNT_IN1 or CNT_IN0). After selecting all the mentioned parameters, you can
immediately see the angle and the frequency of rotation.
DS-TACHO-2 V20-1 7/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
7. Measurement
Once the sensor is properly connected and defined in DEWESoft, it can be used for frequency
measurements (for example: order tracking, balancing, basic RPM measurements, …).
Example: in the order tracking setup you can directly select the tacho as a frequency channel.
The lowest detectable frequency for the counter input on the DEWE-43 / SIRIUS is 5 Hz, therefore if you
have 1 pulse/revolution, the lowest RPM is 300.
DS-TACHO-2 V20-1 8/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
8. Warranty information
Notice
The information contained in this document is subject to change without notice.
Note:
Dewesoft d.o.o. shall not be liable for any errors contained in this document. Dewesoft MAKES NO
WARRANTIES OF ANY KIND WITH REGARD TO THIS DOCUMENT, WHETHER EXPRESS OR IMPLIED.
DEWESOFT SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. Dewesoft shall not be liable for any direct, indirect, special,
incidental, or consequential damages, whether based on contract, tort, or any other legal theory, in
connection with the furnishing of this document or the use of the information in this document.
The copy of the specific warranty terms applicable to your Dewesoft product and replacement parts can
be obtained from your local sales and service office. To find a local dealer for your country, please visit
https://dewesoft.com/support/distributors.
8.1. Calibration
Every instrument needs to be calibrated at regular intervals. The standard norm across nearly every
industry is annual calibration. Before your Dewesoft data acquisition system is delivered, it is calibrated.
Detailed calibration reports for your Dewesoft system can be requested. We retain them for at least one
year, after system delivery.
8.2. Support
Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties
regarding the system. For any support please contact your local distributor first or Dewesoft directly.
Dewesoft d.o.o.
Gabrsko 11a
1420 Trbovlje Slovenia
Europe Tel.: +386 356 25 300
Web: http://www.dewesoft.com
The telephone hotline is available Monday to Friday from 07:00 to 16:00 CET (GMT +1:00)
8.3. Service/repair
The team of Dewesoft also performs any kinds of repairs to your system to assure a safe and proper
operation in the future. For information regarding service and repairs please contact your local
distributor first or Dewesoft directly on https://dewesoft.com/support/rma-service.
8.4. Restricted Rights
Use Slovenian law for duplication or disclosure. Dewesoft d.o.o. Gabrsko 11a, 1420 Trbovlje, Slovenia /
Europe.
DS-TACHO-2 V20-1 9/15
DS-TACHO-2
TECHNICAL REFERENCE MANUAL
8.5. Printing History
Version 2.0.0, Revision 217 Released 2015 Last changed: 23. July 2018 at 16:54.
8.6. Copyright
Copyright © 2015-2019 Dewesoft d.o.o. This document contains information which is protected by
copyright. All rights are reserved. Reproduction, adaptation, or translation without prior written
permission is prohibited, except as allowed under the copyright laws. All trademarks and registered
trademarks are acknowledged to be the property of their owners.
8.7. Trademarks
We take pride in our products and we take care that all key products and technologies are registered as
trademarks all over the world. The Dewesoft name is a registered trademark. Product families
(KRYPTON, SIRIUS, DSI, DS-NET) and technologies (DualCoreADC, SuperCounter, GrandView) are
registered trademarks as well. When used as the logo or as part of any graphic material, the registered
trademark sign is used as a part of the logo. When used in text representing the company, product or
technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ®
sign is not used in the visual representation of the triangle logo.
DS-TACHO-2 V20-1 10/15
