Digicom 3G SoHo Manuale utente
For further information visit our
website http://www.digicom.it
3G SOHO 11/05/2010
Wireless 3G Gateway HSDPA & HSUPA Station
3G SOHO - Code 8D5634
3G SOHO PLUS - Code 8D5635
l3.5G/HSUPA/HSDPA Wireless Gateway
lFast Internet with 7.2 Mbps UMTS Technology
lSimultaneous Internet and Voice call
l2 Mbps Upload transmission
l65.000 colors display
lSend and Receive SMS
lRemotecongurationandManagement
l1analogphone FxS port
l1 FxO port for
Mobile eXtension applications
l
Built-in ADSL 2/2+ Router function (optional)
DESCRIPTION
3GSOHObelongstoDigicom’sGatewaysnewgeneration,projectedand
carriedoutusingthelatestwirelesstechnologies.
INTERNET
3G SOHO is the ideal solution for High-speed Internet connectionsusing
HSDPA technology (1) at 7.2Mbps. Furthermore thanks to the HSUPA
standard support,thegatewaycantransferthee-mailattachedleswith
anuploadspeedupto2Mbps(1).
PHONE
Easy call with 3G SOHO: just connect a traditional phone to the TEL
connector to make a call via GSM,asitwereamobilephone.Thebilling
systemwillbethenGSMtoGSMwithconsiderablesavingsifcomparedto
thePSTN-mobilerates.
Note 1: The support of HSDPA and HSUPA technologies and their
Download/Upload speeds depend on the mobile operator.
For further information visit our
website http://www.digicom.it
Itisidealforalltheapplicationsofsmallremoteofce,
teleworking,forthemanagementoftheagentsnetworks,
etc.
REMOTE ACTIVATION
Thisfunctionremote enables the connection. When a
specicSMSisreceivedoraphonenumberisdetected
(CLI),3GSOHOwillconnectforatimesetbytheuser.
Furthermore 3G SOHO can be set to intercept E-mails
receivedinLANenablingthe3Gconnectionanditcan
sendanSMS.
MANAGEMENT AND CONFIGURATION
Conguration and management of 3G SOHO are
carried out via WEB interface, independently by the
operatingsystem.
SMS
ThroughtheWEBinterfaceyoucansend and receive
SMS.TheinformationofSMSreceivedisdisplayed.
DISPLAY
All the main information about the gateway status are
supplied on a 65.000 colors display, for example
the coverage level, the caller ID connection, the SMS
received,thelostcalls,thedateandtimewillbeavailable
onthedisplaytoguaranteethemaximumefcency.
LAN and Wi-Fi
3G SOHO uses the 54M Wireless LAN technology for
the connection to your laptop. A LAN Ethernet port is
available for the wired connection.
MOBILE EXTENSION (Optional)
3G SOHO has a full series of options that add high
value functions like an FxO analog port or the built-in
ADSL Router.
The Mobile eXtension function, performed with the
FxOanalogport,canremotemanageallthecallsofyour
PSTNline(orPABXextension)onthemobilephone.
SoyouwillbeabletoansweracallcomingtothePSTN
line with your mobile phone. You will also call from your
mobilephoneusingthePSTNline.
This function is very useful in applications of mobile
companyLANwhereyoucanremotemanagethePABX
line on your mobile phone.
You will be able to operate and work as if you were in
ofceevenwhenyouareaway.
UMTS
Network
3G Soho
FxS
Port
ring...ring...
ring...ring...
Hello!
335 12345678
FxO
Port
Dial
0331-702(611)
PABX
PSTN
For further information visit our
website http://www.digicom.it
3G SOHO 11/05/2010
ADSL (Optional)
3G SOHO can be equipped with a built-in ADSL2/2+ Router.
Inthisway,incaseofBACKUP of the ADSL line orformobile-to-mobilecalls(inLeastCostRoutingapplication),
the UMTS module can be used.
BACKUP
Withthebuilt-inADSLrouteroptionandthepossibilitytousetheUMTSnetwork,youcanbealwaysonlineeven
whentheADSLlineisdown.Youre-mailwillbealwaysavailableandyoucanbereachedviaphonethroughthe
mobile network.
Youcanalsoaddabackuprechargeablebatteryinordertohaveyourgatewayalwaysoperativeevenwhenthe
electric power is down.
LEAST COST ROUTING
Thismodeallowsasaving on the telephone bill (2),usingthemobilenetwork,insteadofthePSTNone,forthe
mobile-to-mobile calls.
Dependingontheprexesinsertedduringtheconguration,3GSOHOwillcallusingthemobilenetworkinsteadof
thePSTNnetworkwithaconsiderablesavingonthetelephonebill.
InordertoperformthisapplicationitisneecessarytheFxOoptionontheproduct.
Note 2 : The telephone saving depends on the rates plan defined by your operator for the prefixes inserted
during the configuration.
3G Soho
UMTS
INTERNET
ADSL
Firewall
Computer
Wireless
Camera
For further information visit our
website http://www.digicom.it
TECHNICAL FEATURES
Wireless WAN
l3G Gateway for Small Office/Home Office or Consumer
applications
l
UMTS Technology with HSDPA Category 8 (7.2 Donwnlink)
lHSUPA Category 5 (2.0 Uplink update to 5.76 Mbps)
lEDGE/GPSR Class 12
lBands: UMTS 2100MHz
lBands: EDGE/GPRS/GSM 850/900/1800/1900MHz
Hardware
l1.8” 65.000 colors display
lWEB based local and remote configuration
l1 FxS analog phone port
l
1 FxO (optional) analog port for Mobile eXtension applications
l
1 SIM holder
lLAN: 1 10/100 Ethernet port
l
Size & Weight: 250x14 x70mm (exclusive of antennas); 450gr
lReset to Factory Default Button
l12VDC/1.2A external power supply (range 10-14.5V)
lStandby consumption 672mA - 770mA
Maximum consumption 840mA
lOperating temperature 0-40 ºC
l20-95% non condensing humidity
lBackup Battery (optional) Li-ion 7.4 V /850 mA
lCE Mark
Network Functionalities
lFull Routing IP (static and dynamic, NAT, Dynamic DNS
(DDNS)
lFirewall function (SPI) and protection from DoS attacks
lPacket Filtering, URL content
lDMZ, Virtual Server, VPN Pass-through
lVPN IPSec (1 tunnel), DES, 3DES, AES, MD5, SHA1
lDHCP Server/Client support
Wireless LAN
lWireless up to 54Mbps (IEEE802.11g, b)
l64/128 bit WEP, WPA-PSK/WPA2-PSK encryption
Management
lWEB based local and remote configuration and
management
lFirmware upgrade through WEB interface
dware
ADLS (optional)
lBuilt-in ADSL 2/2+ Router
lStandard ADSL2+, G.dmt bisplus (ITU G.992.5); ADSL
2 G.dmt.bis (ITU G.992.3), Full.rate ANS T1.413 Issue
2, G.dmt (ITU G.992.1), G.Lite (ITU G.992.2) G.hs (ITU
G.994.1), ATM Adaptation Layer Type 5 (AAL5)
lMultiple Protocol over AAL5 (RFC 2684 Formely RFC
1483); Bridge or Routed Ethernet encapsulation, VC and
LLC based mux
lPPP over Ethernet (PPPoE) and PPP over ATM (PPPoA)
esso
3G SoHo is available in 2 versionstosatisfyallthecustomer’sneeds.
ThePLUSversionhas1FxOphoneinterfacetousetheadditionalfunctionsofMobileeXtensionandtheconnection
toPABXextensionside,thenitcanbeusedasagatewayfortheincomingcalls.
ItisequippedalsowiththeADSL2/2+routerfortheBack-uporInstantOfceapplications(whilewaitingfortheADSL
connection,youusethe3Gone).
8D5634 - 3G SOHO-GatewayHSDPA/HSUPA7.2MDownload-2MUpload,1interfacciaLAN10/100,1FxSVoiceport
8D5635 - 3G SOHO PLUS -GatewayHSDPA/HSUPA7.2MDownload-2MUpload,110/100LANinterface,1FxSVoice
port,1FxOVoiceport,built-inADSL2/2+router
Questo manuale è adatto per i seguenti modelli
