DigiFarm AGCO C3000 Guida di riferimento
MD5007
rev 4
DigiFarm Technical Support
319.531.7574
support@digifarm.com
DigiFarm
Quick Reference Card
AGCO C3000 & TopCon X30 & RV50
AGCO C3000 Display Setup
1 Connect the RV50 cable to the AGI 4 via
the adapter cable and black connector on
the back of the receiver
2 Navigate to the Wrench icon, then
System, then GPS, then Correction;
congure the GPS correction source page
to match the screenshot:
3 Return to the Run screen to conrm RTK
x as in the screenshot:
MD5007
rev 4
DigiFarm Technical Support
319.531.7574
support@digifarm.com
DigiFarm
Quick Reference Card
AGCO C3000 & TopCon X30 & RV50
*Note- If this unit was ordered with a subscription, it will be preprogrammed and plug and play ready.
The following instructions will not be needed.
Log into the device via WAN static IP (166.XXX.XXX.XXX:8080) or LAN connection (192.168.1.1:8080) on Port
8080.
Username: digifarm
Password: digifarm
You will then be directed to the page shown below. On this page you can select a receiver preset based on
the receiver type you have, then enter your username and password. Save device info at the bottom then
select the reboot icon at the top of the screen.
