Performance Digital Video Recorder

Built on H.264 Technology

Operations Manual

Performance DVR | Operations Manual

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions -All the safety, operating and installation

instructions should be read before operating the unit.

2. Keep these instructions -The safety, operating and installation

instructions should be retained for future reference.

3. Heed all warnings -All warnings on the unit and in the operating

instructions should be adhered to.

4. Follow all instructions -All operating and use instructions should

be followed.

5. Do not use this apparatus near water -for example, in an

unprotected outdoor installation; or any area which is classified as a

wet location.

6. Clean only with a dry cloth -Unplug the unit from the outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners.

7. Do not block cooling fans and install in a well ventilated area.

8. Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9. Ensure horizontal mounting.

10. Avoid excess vibrations to the unit.

11. Do not stack the DVR unit(s).

12. Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where

they exit from the apparatus.

13. Only use attachments/accessories specified by the manufacturer.

14. Plug unit into a reliable power source.

15. A UPS (Uninterrupted Power Supply) with power surge

protection is strongly recommended.

Performance DVR | Operations Manual

Performance DVR

Operations Manual

Contents

1. Introduction . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . 3

2. Specifications and Features Overview . . . . . . . . . . . . 4

2.1. DVR Specifications . . . . . . . . . . . . . . . . . . . . . . . 4

2.2. DVR Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.3. Storage Calculations . .. . . . . . . . . . . . . . . . . . . . 6

3. Front panel controls . . . . . . . . . . . . . . .. . . . . . . . . . . 7

3.1. Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . 7

3.2. Function Details . . . . . . . . . . . . . . . . . . . . . . . . . 8

4. Basic System Operations . . . . . . . . . . . . . . . . . . . . . . 9

4.1. Turn on/off the recorder . . . . . . . . . .. . . . . . . . . 9

4.2. Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

4.3. Sensor Connection . . . . . . . . . . . . . . . . . . . . . . 10

4.4. PTZ Control . .. . . . . . . . . . . . . . . . . . . . . . . . . . 10

4.5. Network connection . . . . . . . . . . . . . . . . . . . . . . 10

5. DVR Menu and Operations . . . . . . . . . . . . . . . . . . . 11

5.1. Enter/Exit the Operation Menu . . . . . . . . . . . . . 11

5.2. Main Menu . . . . . . . . . . . . . . . . . . . . . .. . . . . . 11

5.3. Disk Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

5.4. Configuration . .. . . . . . . . . . . . . . . . . . . . . . . . . 12

5.5. Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5.6. Back Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5.7. Admin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6. System Connections . . . . . . . . . . . . . . . . . . . . . . . . 18

6.1. Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

6.2. RS232 Connection..... . . . . . . . . . . . . . . . . . 18

6.3. PTZ and Sensor Connections . . . . . . . . . . . . . . 19

6.4. RS-485 port connection . . . . . . . . . . . . . . . . . . 20

6.5. Serial Port Connection Settings . . . . . . . . . . . . 22

7. Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

7.1. Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 23

7.2. Frequently Asked Questions . . . . . . . . . . . . . . . 23

7.3. Hard Disk Installation . . . . . . . . . . . . . . . . . . . . 24

8. Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Performance DVR | Operations Manual

1. Introduction

Embedded Digital recorder for security

applications

The Embeded E-Series DVR is video recording device that can

record multiple cameras, while simultaneously providing Real Time

Viewing, Recording, Playback, Backup and Remote Transmission.

The DVR has comprehensive recording and playback facilities for

viewing stored video at extremely high quality

resolution/compression. Once set up, all recording takes place in the

background with no operator intervention. Maximum recording rates

of 30 fps (NTSC) and 25 fps (PAL) per channel are guaranteed with

all cameras. The recording rate and image resolution are also

selectable per camera.

All models have sensor inputs and relay outputs to integrate the DVR

with security handling and telemetry control. Sensor functions

include motion detection in user-definable areas of the image on any

camera input. The unit can be easily operated and programmed via

the front panel control keys with on screen display menu or remote

control. One monitor output provides full-screen, quad and multi-

screen viewing, another additional output is for a spot/alarm monitor.

An optional CD/DVD writer or USB key can be connected for

archiving data.

Operations over network using Microsoft Internet Explorer (IE) or

using the Remote Client Software installed on the PC, one can view,

playback and configuration. Five simultaneous users can control

multiple dvr’s. The E series includes an authenticity check for both

local and remote playback.

The E-Series DVR has ATM/POS integration.

Versions

There are three “Real-Time” models; 4-channel, 8-channel and 16-

channel, each with various storage capacities and Real-Time

Viewing/Recording.

Setup

An administrator configures the DVR, initially. Access to the

configuration functions is normally password protected. Setup

options can either allow or restrict the functions available to the

operator (i.e. the number of multi-screen views can be limited).

Search and playback functions can also be password protected,

allowing the system to be configured in different ways for multiple

operators. All possible operator facilities are described in this manual

but some of these may not be available to you.

Performance DVR | Operations Manual

2. Specifications and Features

Overview

2.1. DVR Specifications

Parameter 4 Channel 8 Channel 16 Channel

Processor AMD ELANSC520/133 embedded microprocessor

Operation

system Real-time operation system -RTOS

Video input

4 Channel

(NTSC/PAL)

BNC 1.0VP-P

75?

8 Channel

(NTSC/PAL)

BNC 1.0VP-P

75?

16 Channel

(NTSC/PAL)

BNC 1.0VP-P

75?

Video output 1 Channel PAL/NTSC BNC 1.0VP-P 75? video

signal

Audio input 4 Channel 200-

1000mv10K?

(BNC)

8 Channel 200-

1000mv10K?

(BNC)

8 Channel 200-

1000mv10K?

(BNC)

Audio output 1 Channel 2000mv 1K? (BNC)

Video display

1(Full Screen)

& 4(Quad)

window

displays

1(Full Screen),

4(Quad), 9

(3x3) window

displays

1(Full Screen),

4(Quad), 9

(3x3),16 (4x4)

window

displays

Video standard

NTSC 525 line, 60f/s –PAL 625 line, 50f/s

System

resource Real-time recording,multi channel playback and

network operation simultaneous (Triplex)


resolution Real-time monitor 704×576, playback 352×288,

VGA output 720×576

Motion

detection

Area setting: multiple detection areas on the screen;

detection sense setting: 3 levels detection sense for

each area

Video

compression H.264 CBR (fixed frame rate); H.264VBR (variable

frame rate)

Audio

compression Audio -ADPCM 28.8 Mb/hour G.729 -3.6 Mb/hour

Video -40-460 Mb/hour


compression

rate

352×288CIF format -176×144QCIF format -

704×576 4CIF format.

Video recording

speed Real-time mode: NTSC 1f/s -30f/s for each channel

adjustable. PAL 1f/s -25f/s for each channel

adjustable;

Image quality 6 selectable levels

Hard Disk

Expansion Contains 4 IDE ports, able to install 6 Hard Drives

with one CD-RW / DVR-RW

HDD space

used Audio -ADPCM 28.8Mb/hour G.729 -3.6Mb/hour

Video -40-460Mb/hour

Sensor input 8 channel voltage sensor input –5 to 15V DC

necessary for the sensor input.

Sensor output

3 channels output, -output in open/close contact or

controllable -12V output -

Alarm relay 30VDC 1A, 125VAC 0.5A -relay output.

Network

connection RJ45 10M/100M Ethernet connection

Pan-tilt control

RS485

Power 110VAC/220VAC

Power

consumption 60W 75W 90W

Working

temperature 10°C –55°C

Working

humidity 10% -90% Relative

Barometric

pressure 86kpa -106kpa

Size 2U standard industrial case 441mm (Wide) x

430mm (Deep) x 89mm (High)

Weight 11KG in Box

Performance DVR | Operations Manual

2.2. DVR Features

-Real-time Monitor (Video Displays)

•1 VGA port for video output to PC Type Monitor and 2Video

output port to Video Monitor.

•Single window (Full Screen) /4 windows (Quad) /9 windows

(3x3)/16 window (4x4) monitor displays.

-Compression Method

•Multiple video compression modes: H.264fixed frame

variable frame.

•4/8/16-channel audio/video real-time compression,

independent hardware compression for each channel, stable

synchronization of sound and image.

-Storage

•Internally can hold 6IDE -compatible large capacity Harddisk

(HDD)

•Alternative HDD operations that will reduce the power

consumption and heat emission.

•Overwrite (FIFO) and Stop (HDD Full) modes for DVR HDD

recording.

-Back-up

•Built-in CD-RW driver to back up records onto CD-R disks,

upgradeable to DVR-RW drive.

•USB port for external back up of records.

•Download the files on DVR to local PC through network.

-Play and Record

•Supports multiplexed operation: live monitor, record, search

for downloading, one channel playback and remote

transmission simultaneously.

•Multiple recording modes: Manual –Schedule –Alarm -

Motion Detection.

Note: Alarm Recording and Motion Detection Recording

have Pre-recording function.

•Playback: With PIP or Multi-Channel Real-Time Monitor.

Playback also available using Network Connection.

•Fast search for reviewing manual recording and alarmed

recording.

•Multiple playback modes: X2, X4 & X8 fast play, pause,

15F/S, 5F/S slow play and frame by frame playback.

•Displays Time/Date during playback.

-Alarm relay

•8 channels external alarm input, video lost alarm and motion

detection alarm.

•Multi channel relay switch alarm output activates alarm relay

and on-site light control.

•Circuit Protection for Alarm inputs and outputs.

-Pan-tilt Control

•Supports Camera Pan-Tilt-Zoom (PTZ) Functions using

RS485 Communication Protocol.

•Integrates multiple protocols to control various PTZ speed

domes.

-Communication connection port

•DB-25-(25 pin) connection for alarm inputs and PTZ control.

•RS232 port for the connection with keyboard for central

control, or with the computer serial port for system upgrade

and debugging.

•Standard Ethernet port for remote viewing and control.

•Remote real-time monitor through network.

•Pan-tilt-zoom control.

•Record search and real-time playback. Note: playback quality

depends on network conditions. Download records through

network.

•System programming, settings & modification and system

software upgrade available online.

•Remote alarm processing and system log review remotely.

•Embedded TCP/IP protocol and RTOS (Real Time Operating

System) supports Web server direct connection to operate

and control all the above functions.

•Administration mode: Three USER levels for logging in

remotely. Each user login is password protected.

Performance DVR | Operations Manual

2.3. Storage Calculations

The HDD Capacities and Recording lengths are determined by

capacity of the installed HDDs and the selected image level.

The following storage time is based on the average use for HDD

space for single channel recording.

Mode Image

level Resolution

Frames

Transmission

Speed Average H

space (/hour)

1352 * 288

30 128 Kb/s 40 MB

2352 * 288

30 256 Kb/s 80 MB

3352 * 288

30 384 Kb/s 120 MB

4352 * 288

30 512 Kb/s 160 MB

5352 * 288

30 768 Kb/s 240 MB

CBR

6352 * 288

30 1 Mb/s 320 MB

Note: Adjustable frame rates, from 1fs to 30f/s can be selected.

User can choose based on own needs.

Using other than 30f/s (Real time), HDD (Hard Disk) space can be

greatly increased.

Following are storage calculation guidelines (in the number of

Days):

Image Quality

30 Fps 1 Ch 4 Ch

8 Ch

1(128 Kb/s ) 128 Kb/s 61 15 8

2(256 Kb/s) 256 Kb/s 30 84

3(384 Kb/s) 384 Kb/s 20 53

4(512 Kb/s) 512 Kb/s 15 42

5(768 Kb/s) 768 Kb/s 10 31

80Gb

HDD

using

CBR

(constant

bit rate) 6(1024 Kb/s) 1024 Kb/s 821


Quality

30 Fps

1Ch

4Ch

8Ch

1 Fps 1Ch

4Ch

8Ch

1116kb/s

67 17 912.5kb/s

621

155

2160kb/s

49 12 625kb/s

312

3212kb/s

37 9544kb/s

176

4330kb/s

24 6350kb/s

156

5447kb/s

17 4262kb/s

124

80Gb

HDD

using

VBR

(variable

bit rate)

6825kb/s

92188kb/s

88 22


Quality

2 Fps 1Ch

4Ch

8Ch

3 Fps 1Ch

4Ch

8Ch

125kb/s

311

78 39 44kb/s

176

244kb/s

176

44 22 45kb/s

172

350kb/s

156

39 20 55kb/s

140

463kb/s

124

31 15 84kb/s

92 23

578kb/s

100

25 12 100kb/s

76 19

80Gb

HDD

using

VBR

(variable

bit rate)

692kb/s

84 21 10 122kb/s

64 16


Quality

10 Fps

1Ch

4Ch

8Ch

12 Fps

1Ch

4Ch

8Ch

171kb/s

108

27 14 80kb/s

96 24

2109kb/s

72 18 9130kb/s

60 15

3133kb/s

60 15 7149kb/s

52 13

4175kb/s

44 11 6210kb/s

36 95

5258kb/s

32 84275kb/s

28 74

80Gb

HDD

using

VBR

(variable

bit rate)

6443kb/s

16 42525kb/s

16 42

Performance DVR | Operations Manual

3. Front Panel

3.1. Front Panel Controls

1. Power Switch 2. Recording Light 3. Control Cover

4. CD-RW / DVR-RW

5. Onscreen Address

Entry 6. Cursor/Direction

Keys

7. IR Remote

Receiver 8. EXIT (Cancel) 9. Enter

10. AUX 11. Power Light 12. Jog Shuttle

13. Rec (Recording

Control) 14. Switch View Mode

15. Replay Last

Selection

16. Rewind 17. Slow Play 18. Play/Pause

19. Fast Forward 20. Jump to Next

Section 21. USB Connector

Note: Outside Ring of the jog shuttle when turning

clockwise is equal to right direction arrow, turning

counter clockwise is equal to left direction arrow; inner

circle turning clockwise equal to down direction and

counter clockwise equal to up direction.

Performance DVR | Operations Manual

3.2. Function Details

Order

Key name Logo Function

1Power switch and

indication light POWER Power switch-Power off by

pressing the key 4 seconds.

2Recording light LED (Green

)

on numbers If the LED light isGreen, it means

the recording is on

3Plastic Cover Dust-proof Cover

4CD-RW / DVD-RW

Used to Back-up records

Left & Right

Arrows tuL & R On screen Cursor Control;

shifting level 1 and level 2 menus;

Left and Right Camera Pan control.

6Up & Down

Arrows pqUp and Down Onscreen Cursor

Control; change setup; change

number; Camera Tilt control.

7IR Remote

receiver

Used to receive the remote signal.

Cancels cursor selection.

8Cancel EXIT During playback, restore to real-

timemonitor.

Enter Cursor Selection.

9Enter ENTER Entermainmenu.

In the Full Screen Mode:

Press the key to display the menu

of the Camera PTZ.

When setting Motion Detection

fields, Fn1 Enables Cursor field

selection.

During playback, display the

playback status bar

10 Function Key AUX

During playback work with number

key to realize PIP for the playback

and real-timemonitor.

11 Indication light Indication light

12 Jogshuttle

Direction control: outer Ring for Left

and Rightdirection, inner Ring for

up and down; When in playback,

outer circle can control reverse and

multi-speed play.

13 Record REC Start/stop recording, use with arrow

keys

14 Switch View Mode VIEW Select for Multi-Screen; During

playback, shift between Playback

and Real time display.

15 Play last section 9Play the previous recording file.

17 Slow play ?3 levels of slow play speed

adjustments: (15f/S -5f/S & frame

by frame)

Play/stop

18 Play/stop „/;When in real time mode, press to

enterrecordsearch menu

19 Fast Forward 83 levels of fast play speed-X2 -X4

-X8.

20 Play next section :Playthe next recording file after the

current file.

Performance DVR | Operations Manual

4. Basic System Operations

4.1. Turn on/off the recorder

4.1.1. Turn onthe recorder

Plug in the power line; switch on the power button at

the back of the recorder; power indicator light on;

DVR on; default single window for the video output

displays; press Enter the Log-in screen appears on

Monitor; If the starting time is within the

programmed recording time, the system will start

recording function automatically. Channel indicator

lights will indicate the cameras in record mode. The

system will work in a normal manner.

Note: if the system stops during HDD Boot detection,

the HDD may not be installedproperly. Check the

HDD connections (Ribbon and Power Connections)

to fix this problem. *Please unplug the 120VAC

power supply during HDD installation*

4.1.2. Enter the setting menu

Before you enter the menu, you must input the

password. There are two levels of password—User

password and Administrator password.

Administrator password 236461(admin1)

Generaluser password483781(guest1)

With user password you are not allowed to enter

system setting and admin setting.

4.1.3. Turnoff the DVR

Press the POWER key on the front panel for 4

seconds to stop the current operations. Then switch

off the power button at the DVR rear to turn off the

power.

4.1.4. Power off recovery

When the power is cut off abnormally, the recorder

will recall its last state and continue where it left off.

The state indicator light is the same as it was before

the power off.

4.2. Recording

The default recording mode after startup of the DVR is 24 hr

continuous recording for each channel. The User can program

customized recording times for each camera. Instructions for the

different recording modes are as follows:

a) Schedule Recording:

-Enter the menu, and set the timing period for the recording.

See details at Menu>Config>Camera>Schedule

b) Manual Record Selection

-Press “Record” button on the remote controller or “Rec” on the

front panel.

-Check the status of each channel in the recording menu; The

Highlighted channels are in record mode.

-To select the channel to be recorded, press the related number

key. Selected camera # will highlight on your screen. When all

cameras that need to be recorded are selected, press Enter to

begin the recording.

-Repeat above steps and remove the highlight to stop the

camera from recording.

-Press Cancel or EXIT to return without changes.

c) Sensor recording

-Connect the sensor input according to the device connection

and the instructions.

-·Program the related settings in the menu to start Sensor

recording. See details at Menu>Config>Camera>Sensor input

Indice

Altri manuali Digital Equipment Registratore digitale

Digital Equipment

Digital Equipment 8504 Manuale utente

Manuali Registratore digitale popolari di altre marche

FLIR

FLIR M3100E Series Manuale utente

VTRACKPRO

VTRACKPRO FPRO300 Manuale utente

Swann

Swann NVR-7085 models Manuale utente

XtendLan

XtendLan DVR-1670C Manuale utente

urmet domus

urmet domus 1093/004AHD Manuale utente

Holux

Holux M1 Manuale utente

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuale utente

Whistler

Whistler D16VRS Manuale utente

Defender Security

Defender Security 82-20235 Manuale utente

MISUMI

MISUMI MP-WF100M Manuale utente

Speco

Speco D8HU Manuale utente

UST

UST DDR-E04AA Istruzioni per l’uso

Consolidated

Consolidated Digital Video Recorder Manuale utente

Mace

Mace DVR0404RW Guida rapida

RCA

RCA RTD315W Manuale utente

FSM

FSM Colibri Grande PRO Manuale utente

Hauppauge

Hauppauge HD PVR 2 Manuale utente

Identivision

Identivision ICR-PH161i PIONEER Manuale utente
