Digitus USB 2.0 Manuale utente

WIRELESS LAN

USB 2.0 ADAPTER

USER´s GUIDE

(DN-70031)

All trade names are registered trademarks of respective manufacturers listed.

This manual may not be copied in any media or form without the written consent of original maker.

Information To User ..................................................……..i

1. Introduction .........................................................…… 1

2. Wireless LAN Basics ................................................……. 3

3. IP ADDRESS ..........................................................……. 4

4. Install Driver/Utility ...............................................……. 5

5. Wireless Network Configuration ................................……… 8

5.1 Utility Icon ........................................................ 8

5.2 Client Mode (Default Setting)................................... 9

5.3 AP and Wizard Setup............................................. 12

5.4 AP Mode ........................................................... 14

6. Technical Specifications ............................................... 15

7. Troubleshooting ......................................................... 16

8. Glossary ...................................................................17

INFORMATION TO USER

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by

one of the following measures:

* Reorient or relocate the receiving antenna.

* Increase the separation between the equipment and receiver.

* Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

* Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved

by the party responsible for compliance could void the user's authority to

operate this equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

* This equipment complies with FCC radiation exposure limits set

forth for an uncontrolled environment.

* This transmitter must not be co-located or operating in conjunction

with any other antenna or transmitter.

* We declare that this US model is limited in CH1~CH11 for 2.4G band by

specific firmware controlled by the manufacturer and is not user changeable.

REGULATORY INFORMATION

WLAN 11b/g Adapter must be installed and used in strict accordance with the

instructions. This device complies with the following radio frequency and

safety standards.

USA - Federal Communications Commission (FCC)

This device complies with Part 15 of FCC Rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference that may cause undesired

operation.

Europe- R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/CE

OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio

equipment and telecommunication terminal Equipment and the mutual

recognition of their conformity (R&TTE)

CE Declaration of Conformity

This product is herewith confirmed to comply with the requirements set out in the

Council (European parliament) Directive on the Approximation of the Laws of the

Member States relating to Electromagnetic Compatibility of Radio and Telecom

device (1999/5/EC). For the evaluation regarding this Directive, the following

standards were applied:

EN 300 328 V1.6.1 (2004-11)

EN 301 489-1 V1.4.1 (2002-08), EN 301 489-17 V1.2.1 (2002-08)

EN 60950-1: 2001

EU Countries Not intended for use

None.

Potential restrictive use

France: Only channels 10,11,12, and 13

The channel identifiers, channel center frequencies, and

regulatory domains of each 22-MHz-wide channel are shown in

following Table.

Channel

Identifier

Center

Frequency

(MHZ)

Regulatory Domains

Japan ETSI North

America Israel France Mexico

1 2412 ˇˇˇˇ

2 2417 ˇˇˇˇ

3 2422 ˇˇˇˇˇ

4 2427 ˇˇˇˇˇ

5 2432 ˇˇˇˇˇ

6 2437 ˇˇˇˇˇ

7 2442 ˇˇˇˇ

8 2447 ˇˇˇˇ

9 2452 ˇˇˇˇ

10 2457 ˇˇˇˇ

11 2462 ˇˇˇˇ

12 2467 ˇˇ

13 2472 ˇˇ

14 2484 ˇ

iii

Thank you for your purchase of the WLAN Mini USB Adapter.

Featuring wireless technology, this wireless networking solution has

been designed for both large and small businesses, and it is scalable

so that you can easily add more users and new network features

depending on your business scale.

FEATURES

Support Microsoft Windows 2000, XP and Vista.

Operating distance of up to 300 meters in free space.

54/48/36/24/18/12/11/9/6/5.5/2/1 Mbps selectable Data Rate.

Support USB 2.0 interface.

64-bit or 128-bit WEP (Wired Equivalent Privacy); WPA

(Wi-Fi Protected Access),WPA2

2.400GHz ~ 2.4835GHz unlicensed ISM Frequency Band.

Modulation Method :

IEEE 802.11b : DSSS (Direct Sequence Spread Spectrum).

IEEE 802.11g : OFDM (Orthogonal Frequency Division Multiplexing).

Easy operation and setting up.

SYSTEM REQUIREMENTS

Windows System : 2000, XP and Vista.

PCs must have a device driver installed. It allows you to communicate

with WLAN Mini USB Adapter.

BEFORE YOU START

1. Confirm Box Contents

CONNECTING YOUR WLAN

USB ADAPTER TO PC

Quick Start Guide

Connect your WLAN USB

dongle to your PC.

Install driver.

GETTING TO KNOW WIRELESS LAN USB ADAPTER

LED

LED turns on when POWER is applied to the WLAN Mini USB Adapter.

LED is blinking when PC is sending data through WLAN Mini USB

Adapter.

Wireless LAN network defined by IEEE 802.11b/g standard committee

could be configured as :

Ad Hoc wireless LAN.

Infrastructure wireless LAN.

Ad Hoc network is a group of PCs installed with wireless LAN cards, this

group of PCs is called a BSS (Basic Service Set). PCs in this group can use

their wireless LAN cards to communicate with each other, but can not

connect to the Internet.

Ad Hoc WirelessNetwork Infrastructure Wireless Network

The most obvious difference between Infrastructure wireless network

and Ad Hoc wireless network is that the PCs in Infrastructure wireless

network can access the resource in the Internet through Access Point.

Depending on your requirement, you can easily set up your PC’s

network to be a “Ad Hoc” or “Infrastructure” wireless network. Generally

speaking, if in your network, there is an Access Point in it, we recommend

you to set your network as an “Infrastructure”, so it can connect to

the Internet.

To use the WLAN Mini USB Adapter with a computing device, the WLAN

Mini USB Adapter must be equipped with an USB 2.0 Interface. All

drivers and supporting software for the WLAN Mini USB Adapter must be

installed and configured first.

Ask your system administrator for the following information, which you

may need to provide during driver installation :

Your Wireless Client Name.

Your Wireless SSID.

Your computer’s unique client name and workgroup name.

For your network account, your user name and password.

Your IP address, gateway address, and subnet mask if you’re not

using a DHCP client.

Any computer on a network is identified by a unique network address.

There are two methods to assign a network address to a computer on a

TCP/IP network :

Static IP addressing.

Dynamic IP addressing (DHCP Client).

In network with static IP addressing, the network administrator manually

assigns an IP address to each computer. Once a static IP address is

assigned, a computer uses the same IP address every time it reboots and

logs on to the network. You may manually change the IP address in the

Network Properties dialog box. Network using static IP address is easy to

set up and do not require additional network management software.

In network with dynamic IP addressing, a DHCP server in the network

dynamically assigns IP addresses to all clients every time they log on to

the network. Network using dynamic IP address requires setting up and

running a DHCP Server.
