Digitus DA-10080 Manuale utente
Wireless Charging Pad,
magnetic
Quick Installation Guide
DA-10080
2
1. INTRODUCTION
The magnetic charging pad from DIGITUS® automatically
latches on to the optimal charging position of the iPhone® to
guarantee efficient charging. The induction charger features an
integrated 1.0m long USB-C charging cable and works with all
Apple Mag Safe®-compatible products.
2. FEATURES
1. Compatible with iPhone® 12/13.
2. Inductive charging technology for wireless charging of
compatible smartphones.
3. The magnetic ring is optimized for the latest Apple iPhone®
models and the charging function can be used with any
smartphone that allows inductive charging.
4. Connection cable with USB-C plug.
5. Compact and robust aluminum/ABS housing with
elegant look.
6. A power adapter is not included in the scope of delivery.
3
3. PACKAGE CONTENT
1x Wireless charging pad, magnetic
1x QIG (Quick Installation Guide)
NOTE:This charger is designed for Qi-compatible devices if
your phone does not have built-in Qi wireless charging
capabilities, please use a certified Qi wireless charging case or
receiver. Refer to your phone's user manual for detailed
features and functions
XNO Metal
XNO Thick Case
Phone cases that contain metal, magnets, or are thicker than
3mm will interfere with wireless charging.
4
This charger magnetically
snaps to the back of an
iPhone 12/13 or to its
MagSafe case or sleeve
(sold separately) and
aligns iPhone properly,
allowing you to hold and
use iPhone while it’s
charging.
Wireless Charger Output
15W/10W/7.5W/5W
USB-C Cable
5
You can also use MagSafe Charger
with other phone models that
support wireless charging.
Plug the USB-C connector to a
20W PD or greater USB-C power
adapter or compatible third-party
USB-C adapter (9V/2.22A or
9V/1.67A and higher).
NOTE:
You can also connect to a USB-C port on a Mac or PC. The
charger will also function with power adapters that provide a
minimum 12W (5V/2.4A) of power, but this will result in slower
charging.
6
IPhone 12/13 models
Place the charger on the back of the iPhone or its Mag Safe
case or sleeve. When the iPhone starts charging, the green
charging symbol appears.
NOTE:
If an iPhone Leather Wallet is attached, remove it before
placing the charger on the back of the case.
Other phones
Place the phone face up on the center of the charger. When
the phone is aligned properly with the charger, the Battery
Charging icon appears in the status bar.
Standby
Charging
Foreign Object Detected
It’s normal for a wireless charger and your
device to becomewarm while charging.
7
Frequency band(s):
110-205khz
Maximum radio-frequency
power transmitted -21.28 dBuA/m
Read all safety instructions and warnings prior to using this
product. Improper use and failure to follow safety guidelines
could result in hazards, injury and/or property damage that is
not the manufacturer’s responsibility. The user is responsible
for maintaining this product with care for maximum use.
1. Do not place metal objects, magnets, magnetic stripe cards,
and hard drive based devices near the wireless charger. It
may cause data corruption.
2. Do not attempt to modify, disassemble, or repair this product.
3. Do not expose to water, moisture, or extreme temperatures
(below 40°F or above 90°F).
4. Under any circumstances, if you find this product rapidly
increasing in temperature, emitting odor, or demonstrating
an abnormal phenomenon, discontinue use immediately.
8
Hereby Assmann Electronic GmbH declares that the
Declaration of Conformity is part of the shipping content. If the
Declaration of Conformity is missing, you can request it by post
under the below mentioned manufacturer address.
www.assmann.com
ASSMANN Electronic
GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
