INSTRUCTION MANUAL

For domestic household use only.

Oil Free Column Heaters

Model: OFRC10BLK, OFRC15BLK & OFRC24BLK

08/54739/0 Issue 3

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE

INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY

Please read the operating instructions carefully before using your product

for the first time and keep them in a safe place.

• When using electrical appliances, basic precautions should always be

followed to reduce the risk of fire, electrical shock and injury to persons,

including the following:

• If the appliance is damaged, check with the supplier before installation

and operation.

- Do not use outdoors.

- Do not use in the immediate surroundings of a bath, shower or

a swimming pool.

- Do not use this heater if it has been dropped.

- Do not use if there are visible signs of damage to the heater.

- Use this heater on a horizontal and stable surface, or fix it to

the wall, as applicable.

• Do not locate the appliance immediately below a fixed socket outlet or

connection box.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the

appliance.

• CAUTION: Some parts of this product can become very hot and cause

burns. Particular attention must be given where children and vulnerable

people are present.

• IMPORTANT: Only use this heater on a horizontal and stable surface

with the castors attached.

• WARNING: In order to avoid overheating, do not cover the heater.

• The Heater carries this warning symbol indicating that it must

not be covered.

• Do not use this appliance in series with a thermal control, a program

controller, a timer or any other device that switches on the heat

automatically, since a fire risk exists when the appliance is accidentally

covered or displaced.

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED

FOR FUTURE REFERENCE. Note also the information presented on the

appliance

• In the event of a fault, unplug the appliance.

• Unplug the appliance when not required for long periods.

• This product is intended for INDOOR RESIDENTIAL applications only.

• DO NOT cover cord with carpeting, throw rugs, runners, or similar

coverings.

• DO NOT route cord under furniture or appliances. Take care to position

the cord away from traffic areas and where it will not be a tripping

hazard.

• This appliance must not be used in a bathroom.

• Although this appliance complies with safety standards, we do not

recommend its use on deep pile carpets or on long hair type of rugs

• The appliance must be positioned so that the plug is accessible.

• If the supply cord is damaged it must be replaced by the manufacturer

or service agent or a similarly qualified person in order to avoid a hazard.

• Keep the supply cord away from the front of the appliance.

• Do not use this heater in small rooms when they are occupied by

persons not capable of leaving the room on their own, unless constant

supervision is provided.

• To reduce the risk of fire, keep textiles, curtains and or flammable material

a minimum distance of 1m from the air outlet.

• DO NOT place material or garments on the appliance, or obstruct the

air circulation around the appliance, for instance by curtains or furniture,

as this could cause overheating and a fire risk.

• In order to avoid a hazard due to inadvertent resetting of the thermal cut-

out, this appliance must not be supplied through an external switching

device, such as a timer, or connected to a circuit that is regularly switched

on and off by the utility.

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED

FOR FUTURE REFERENCE. Note also the information presented on the

appliance

Exposed to the

weather outdoors

Near water If the power cable

wires are frayed or cut

Where small children

may be left unattended

No extension leads or

power boards

Where there is risk

of fire or close to

a naked flame

Where the power

cable may be

damaged

On a slope or

uneven surface

Where it may be

damaged by

chemicals

If there is a risk

of water falling on

the unit

Where there is a risk

of interference by

foreign objects

This product is not

made for DIY repair

Model no. OFRC10BLK OFRC15BLK OFRC24BLK

Power supply

230-240V~50Hz

Rated power 1000W

1500W

2400W

Heat settings

Thermostat Y

Timer N

Turbo Fan N

Weight (net) 6.4kg

8.3kg 10.7kg

Dimensions (w x d x h) 280 x 280 x 622mm

280 x 370 x 622mm 280 x 550 x 622mm

Specifications

For greater precision, please always refer to the rating label placed on the product.

WARNING THIS APPLIANCE MUST BE EARTHED

Fitting The Castors

WARNING The column heater must only be operated with the wheels and castors

fitted and in an upright position. The castors must be fitted to the control panel and

on the bracket between the last and second last fin on the opposite end, as shown

in Fig.1.

Fitting the castors

1. Remove the box containing the castor assemblies from the packaging.

2. Fit the castors to the stub axles by applying hand pressure until each castor

clicks into position - see below Fig. 2. Note that the castors are designed to be a

tight fit on the axles but will rotate in use.

3. The castors can only be fitted between the outer fins (as shown in Fig. 1).

4. Turn the heater upside down on a carpet or other soft surface to avoid damage.

Ask a second person to help with this if necessary.

WARNING: THE HEATER IS HEAVY – ENSURE THAT IT IS SUPPORTED TO

PREVENT IT FROM TOPPLING.

5. Position the castor bracket (see Fig. 2) onto the threaded pins on the control

panel. Place the winged nut ‘C’ on the thread and tighten it securely.

6. Repeat the process for castor bracket ‘B’ onto the last fin.

7. Lift the heater clear off the floor, then turn it back upright and stand it on its

castors. It is now ready for use.

Fig 1. Fig 2.

OFRC15/OFRC15TI

OFRC25/OFRC25TI

On/O see

Table 1

5 Fin

7/9/11 FinOFRC10/OFRC10TI

OFRC15/OFRC15TI

OFRC20/OFRC20TI

OFRC25/OFRC25TI

OFRC10BLK

OFRC15BLK

OFRC24BLK

Positioning

Select the position for the heater ensuring there is clearance from any furniture

and fittings of at least 300mm above the heater and 150mm each side. The heater

should only be operated on a flat stable surface.

NOTE: The column heater is designed for operation on an AC electricity supply, and

is only suitable for domestic use and similar indoor locations.

Tips

• The column heater is fitted with castors and a handle for ease of movement.

• A rocker switch provides the ability to choose an available heat output and

an adjustable thermostat enables the room temperature to be controlled

accordingly.

• Once the castors have been correctly fitted, no other assembly is required, just

plug in and play!

Safety Features

This appliance incorporates a number of safety devices. In addition to the ‘Important

Safety Advice’ section your attention is drawn to the following;

Tilt Switch

The tilt switch will prevent the heater from working if it is accidentally tipped over on

its side.

If the radiator is tipped over while it is hot, disconnect the power and allow it to cool,

then stand the radiator back upright. Reconnect the power - normal operation should

be resumed.

Overheat Protection

The heater is fitted with a temperature limiter which will reduce the output of the heater

should it overheat for any reason. The product will return to normal operation after the

cause of the over heating has been rectified.

Operation

IMPORTANT - OBJECTS OR CLOTHING MUST NOT BE PLACED ON THIS HEATER.

Before using the column heater ensure that all warnings and instructions have been

read carefully. To turn ON the heater simply plug it in. Neon indicator lights located

near the control area will illuminate when the appliance is plugged into a power

outlet. This indicates the appliance is in standby mode and ready to use.

Please note – The element has been coated with a protective film which will burn off

during the first few minutes of use, this may cause a small amount of fuming. This is

quite normal – the fumes are non-toxic and will disappear quickly.

We recommend that you open a window to ventilate the room when using the

heater for the first time.

Handle

Thermostat dial

Indicator light

On/Off & Heat switches

Cable wrap

Thermostat Dial

On/Off & Heat Switches

Description of Parts

Operation

Thermostat

The Thermostat Dial (see previous page) controls the heat output according to

the room temperature. This ensures that the column heater will not produce heat

unnecessarily when the room is already warm.

1. To set the temperature, turn the thermostat dial clockwise until the required

setting is reached. Alternatively to heat a cold room quickly, turn the thermostat

dial up fully.

2. When the room has reached the desired temperature, turn the thermostat

dial anti-clockwise until the thermostat just clicks off. The heater will now

automatically operate at this temperature.

3. The thermostat also has a frost protection setting marked '*' This setting is useful

in areas such as garages, or other cold indoor rooms, to prevent frost damage. If

the thermostat is set to its minimum setting '*' the heater will cycle on and off to

maintain a temperature of approximately 5°C to help protect against frost.

Note – If the heater fails to turn ON when the thermostat is at a low setting, this may

be due to the room temperature being higher than the thermostat setting.

On/Off & Heat Switches (see previous page)

Selector switches located on the control panel provide a choice of heat output to

suit varying conditions and for economy of operation.

Available output options are as follows:

On/Off Switches (Left) Heat Switches (right)

Model O I I II

OCR10BLK

Off On (700W) 700W 1000W

OCR15BLK

Off On (1000W) 1000W 1500W

OCR24BLK

Off On (1700W) 1700W 2400W

WARNING - ALWAYS DISCONNECT THE POWER SUPPLY BEFORE CLEANING THE

HEATER.

• Do not use detergents, abrasive cleaning powder or polish of any kind on the

body of the column heater.

• Allow the column heater to cool, then wipe with a dry cloth to remove dust and

a damp cloth (not wet) to clean off any marks. Be careful not to allow moisture

into to the heater.

Storage

If the heater is not required for long periods, for example during the summer, it should

be stored in a dry place and preferably covered to prevent the accumulation of dirt

and dust. The supply cord should be neatly coiled around the cable wrap ensuring that

the plug does not trail on the floor.

Cleaning

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Dimplex Stufa

Dimplex

Dimplex PLX 2000TI Manuale utente

Dimplex

Dimplex VFE 20 Manuale utente

Dimplex

Dimplex DXUFSR2 Manuale utente

Dimplex

Dimplex Monterey Manuale utente

Dimplex

Dimplex CEL50 Manuale utente

Dimplex

Dimplex EF12 Series Manuale utente

Dimplex

Dimplex NELSON DELUXE NLS20RC Manuale utente

Dimplex

Dimplex OFRC10ECCb Manuale utente

Dimplex

Dimplex BFH24R Manuale utente

Dimplex

Dimplex QUBEFAN Q2TSNH Manuale utente

Dimplex

Dimplex OCR15FA Manuale utente

Dimplex

Dimplex OFRC20 Manuale utente

Dimplex

Dimplex LPC Series Manuale utente

Dimplex

Dimplex SmartRad SRX80 Manuale utente

Dimplex

Dimplex OCR15TIF Manuale utente

Dimplex

Dimplex SRX 080M Manuale utente

Dimplex

Dimplex DXC20TIE7 Manuale utente

Dimplex

Dimplex FSR 15...35 GW Guida rapida

Dimplex

Dimplex Cold Watcher Manuale utente

Dimplex

Dimplex CXLS24 Manuale utente

Dimplex

Dimplex VFMi 20 C Manuale utente

Dimplex

Dimplex DTX Series Manuale di istruzioni per l'installazione

Dimplex

Dimplex SRX 070 ECM Manuale utente

Dimplex

Dimplex CXD2000H-NA Series Manuale utente

Manuali Stufa popolari di altre marche

oventrop

oventrop Regucor Series Manuale utente

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuale utente

ELMEKO

ELMEKO ML 150 Manuale utente

BN Thermic

BN Thermic 830T Manuale utente

KING

KING K Series Guida

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guida rapida

Well Straler

Well Straler RC-16B Manuale utente

EUROM

EUROM 333299 Manuale utente

Heylo

Heylo K 170 Manuale utente

Eterna

Eterna TR70W Manuale utente

Clarke

Clarke GRH15 Manuale di istruzioni

IRSAP

IRSAP The Radiator Company Ovali Manuale utente

Empire Heating Systems

Empire Heating Systems WCC65 Manuale utente

Wetekom

Wetekom 92 86 43 Manuale utente

Desa

Desa SPC170-F Manuale utente

Watlow

Watlow Watrod Electric Tubular Heaters Manuale utente

Haverland

Haverland ECO-DRY GPS Series Manuale elenco delle parti

Stelpro

Stelpro ASILVC2060 Series Manuale utente
