Owner’s Manual
Model
DFG2562
DFG253A
7210580100R08
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
To view the full line of Dimplex products, please visit
www.dimplex.com
2 www.dimplex.com
Table of Contents
Always use a qualied technician
or service agency to repair
this replace.
!NOTE: Procedures and
techniques that are considered
important enough to
emphasize.
CAUTION: Procedures
and techniques which, if not
carefully followed, will result in
damage to the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
Welcome & Congratulations ..................3
Important Instructions ........................4
Installation ................................7
Operation ................................10
Maintenance ..............................13
Warranty .................................15
Replacement Parts .........................18
3
Welcome & Congratulations
Thank you and congratulations for choosing to purchase an electric
replace from Dimplex, the world leader in electric replaces.
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in a
possible electric shock, re hazard and will void the warranty.
Please record your model and serial numbers below for future
reference: model and serial numbers can be found on the Model and
Serial Number Label of your replace.
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)
S E R IAL No.
MODE L
MOD.
4 www.dimplex.com
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
① Read all instructions before us-
ing the electric replace.
②The heater is hot when in use.
To avoid burns, do not let bare
skin touch hot surfaces. The trim
around the heater outlet becomes
hot during heater operation.
③ Extreme caution is neces-
sary when any heater is used by
or near children or invalids and
whenever the unit is left operating
and unattended.
④ Always unplug the electric
replace when not in use.
⑤ Do not operate any heater after
it malfunctions. Disconnect power
at the service panel and have the
heater inspected by a reputable
electrician before reusing.
⑥ Do not operate any unit with
a damaged cord or plug, or if the
heater has malfunctioned, or if
the electric replace has been
dropped or damaged in any man-
ner, contact Dimplex Technical
Service at 1-888-346-7539.
IMPORTANT INSTRUCTIONS
⑦Do not use outdoors.
⑧ The electric replace is not
intended for use in bathrooms,
laundry areas and similar indoor
locations. Never locate heater
where it may fall into a bathtub or
other water container.
⑨ Do not run the cord under
carpeting. Do not cover cord with
throw rugs, runners, or the like.
Arrange cord away from traf-
c area and where it will not be
tripped over.
⑩ To disconnect the unit, turn the
controls off, then remove the plug
from the outlet
⑪ Do not insert or allow foreign
objects to enter any ventilation
or exhaust opening as this may
cause an electric shock or re, or
damage to the heater.
⑫ To prevent a possible re, do
not block air intake or exhaust in
any manner.
⑬ All electrical heaters have
hot and arcing or sparking parts
inside. Do not use in areas where
gasoline, paint, or ammable
liquids are used or stored.
⑭ Do not modify the electric re-
place. Use it only as described
5
SAVE THESE INSTRUCTIONS
in this manual. Any other use not
recommended by the manufactur-
er may cause re, electric shock
or injury to persons.
⑮ To reduce the risk of electric
shock, this appliance has a polar-
ized plug (one blade is wider than
the other). This plug will t in a
polarized outlet only one way. If
the plug does not t fully in the
outlet, reverse the plug. If it still
does not t, contact a qualied
electrician to install the proper
outlet. Do not change the plug in
any way.
⑯ Always plug heaters directly
into a wall outlet/receptacle.
Never use with an extension cord
or relocatable power tap (outlet/
power strip).
⑰ Do not burn wood or other ma-
terials in the electric replace.
⑱ Do not strike the replace
glass.
⑲ Always use a certied electri-
cian should new circuits or outlets
be required.
⑳ Always use properly grounded,
fused and polarized outlets.
㉑ Disconnect all power supply
before performing any cleaning,
maintenance or relocation of the
unit.
㉒When transporting or stor-
ing the unit and cord, keep in a
dry place, free from excessive
vibration and store so as to avoid
damage.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE
IMPORTANT INSTRUCTIONS
6 www.dimplex.com
!NOTE: This equipment has been
tested and found to comply with
the limits for Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and
can radiate radio frequency energy
and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
or television reception, which can be
determined by turning the equipment
off and on, the user is encouraged to
try to correct the interference by one or
more of the following measures:
· Reorient or relocate the receiving
antenna.
· Increase the separation between
the equipment and the receiver.
· Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
· Consult the dealer or an
experienced radio/TV technician for
help.
Operation is subject to the following
two conditions: (1) this device may not
cause interference and (2) this device
must accept any interference, including
interference that may cause undesired
operation of the device.
IMPORTANT INSTRUCTIONS
WARNING: Remote control
contains small batteries. Keep
away from children. If swallowed,
seek medical attention immedi-
ately.
WARNING: Do not install bat-
tery backwards, charge, put in re
or mix with used or other battery
types - may explode or leak caus-
ing injury.
!NOTE: Changes or modica-
tions not expressly approved by
the party responsible for compli-
ance could void user's authority to
operate the equipment.
7
Installation
WARNING: Ensure the power
cord is not installed so that it is
pinched or against a sharp edge
and ensure that the power cord is
stored or secured to avoid tripping
or snagging to reduce the risk
of re, electric shock or injury to
persons.
WARNING: Construction
and electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
WARNING: Do not attempt
to wire your own new outlets or
circuits. To reduce the risk of re,
electric shock or injury to persons,
always use a licensed electrician.
WARNING: To reduce the risk
of re, do not store or use gaso-
line or other ammable vapors or
liquids in the vicinity of the heater.
CAUTION: Clearance for air
circulation beneath the re-
place insert is provided by 2
rubber feet.
Do not install the replace
insert directly on carpet or
similar surfaces which may
restrict air circulation.
CAUTION: If installing the
replace in a carpeted area, place
a one-piece, solid, at surface
under the replace. Ensure that
both of the feet rest securely on
this surface.
!NOTE: The dimensions of the
rebox are 26 in. (661 mm)
wide X 18 ⅞ in. (480 mm) high
X 8 ¾ in. (223 mm) deep. The
rebox does not require any
additional venting.
Mantel Installation
Install the replace into the
mantel (refer to mantel assembly
instructions).
!IMPORTANT: If not using a
Dimplex mantel, the replace
must be installed in an enclosure
with the following minimum inter-
nal/opening dimensions - Figure
1.
Figure 1
9 in.
(229 mm)
24 ½ in.
(622 mm)
18 ¼ in.
(464 mm)
8 www.dimplex.com
Installation
Figure 2
Figure 3
New Wall Construction
1. Mark the desired location on
the oor and store the re-
place in a safe, dry and dust
free location.
2. Use studs to frame an open-
ing of 24 ½ in. (622 mm) wide
X 18 ¼ in. (463.6 mm) high
X 8 ⅞ in. (225.5 mm) deep.
(Figure 1)
Option #1 - The power cord can
be lead from behind the trim
and along the wall to an outlet
near the replace.
Option #2 - A new outlet can be
installed inside the new frame
construction. Plug the unit into
a 15 Amp/120 Volt outlet.
!NOTE: A 15 Amp, 120 Volt
circuit is required. A dedicated
circuit is preferred but not es-
sential in all cases. A dedi-
cated circuit will be required
if, after installation, the circuit
breaker trips or fuse blows
on a regular basis when the
heater is operating. Additional
appliances on the same circuit
may exceed the current rating
of the circuit breaker.
Option #3 - Hardwire
1. Wire a dedicated, properly
fused circuit with 120 Volt, 15
Amp rating. Allow up to 8 feet
of service cable for connect-
ing power supply to junction
box on replace when install-
ing after nishing wall.
CAUTION: Use two conduc-
tor, non-metallic sheath cable
with ground wire (3 wires total)
for the incoming power supply on
replace inserts. Use appropriate
wire to meet local and national
electrical codes for rated power
9
Installation
consumption.
2. Remove the outer jacket and
strip the individual conductor
from the end.
3. Loosen the screw securing
the junction box cover and
remove the cover.
4. Take the cables out from the
junction box, loosen the two
wire twist nuts and remove
the cord set (Figure 2).
5. Route the power supply wire
through the knockout on sup-
plied alternative junction box
cover and secure with a wire
clamp (not supplied) (Figure
3).
6. Connect the black wire (live)
from the unit to the black wire
from power supply (Figure 3).
7. Connect the white wire
(neutral) from the unit to the
white wire from power supply
(Figure 3).
8. Connect the green wire
(ground) from the unit to the
green wire from power supply
(Figure 3).
9. Place all connectors inside
the unit and secure the junc-
tion box cover to unit. Ensure
that the cable clamp grips
only the jacket of service
cable.
Wiring
L1
N
N
SWITCH OUT
CUTOUT THERMOSTAT
M
M
L
HEAT ON/OFF
SWITCH
LIGHT HARNESS
ASSEMBLY
FLICKER
MOTOR
CAPACITOR
BLOWER
MOTOR
ELEMENT
10 www.dimplex.com
Installation
Operation
WARNING: This electric
rebox must be properly installed
before it is used.
Manual Controls
A. 3-Position Switch
The switch has two On positions
marked “ I” and “ II ”.
The “ I” position is for manual op-
eration. In this position the built-in
remote control is by-passed.
The “ II ” position is for operating
the unit with the provided remote
control. When in the remote
control (“ II ”) position the unit is
operated with the ON and OFF
buttons of the remote control.
When the switch is in the center
“ O ” position the unit is off.
Figure 4
Front glass
Mounts
Hooks
Final Steps
Carefully pour and evenly distrib-
ute the supplied glass rock media
on the front tray of the rebox
(Figure 4). Once complete, hang
the front glass assembly on the
mounts of the rebox.
B. Heater On/Off Switch
The Heater On/Off Switch sup-
plies power to the heater fan
and the heater element. When the
switch is in the On position, the
heater operates if the thermostat
calls for heat.
C. Heater Thermostat Control
To adjust the temperature to your
individual requirements, turn the
thermostat control clockwise all
the way to turn on the heater.
When the room reaches the de-
sired temperature, turn the ther-
mostat knob counter-clockwise
until you hear a click. Leave in
this position to maintain the room
temperature at this setting. For
additional heat, turn clockwise un-
Altri manuali per DFG2562
1
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Dimplex Camino da interno
Dimplex
Dimplex BF36E Manuale utente
Dimplex
Dimplex CHERITON LED CHT20 Manuale utente
Dimplex
Dimplex DF2010-EU Manuale utente
Dimplex
Dimplex BLF74 Manuale utente
Dimplex
Dimplex SILVERTON Manuale utente
Dimplex
Dimplex Optiflame Toluca Deluxe TLC20LX Manuale di istruzioni
Dimplex
Dimplex THWG XLF50 Manuale utente
Dimplex
Dimplex Revillusion RBF30 Manuale utente
Dimplex
Dimplex DWF1146GP Manuale utente
Dimplex
Dimplex DVF1200 Manuale utente
Dimplex
Dimplex GDS28L8-1802W Manuale utente
Dimplex
Dimplex Opti-Myst Cassette 500 Manuale utente
Dimplex
Dimplex Toluca Deluxe Manuale utente
Dimplex
Dimplex EWF-SS Manuale utente
Dimplex
Dimplex LVA191 Manuale utente
Dimplex
Dimplex MULTIFIRE DF3215 Guida rapida
Dimplex
Dimplex DIMPLEX ELECTRIC FIREPLACE Manuale utente
Dimplex
Dimplex RBF Manuale utente
Dimplex
Dimplex LVA231 Manuale utente
Dimplex
Dimplex GDS33HG-1310RG Manuale utente
