EN COMPACT 3.0
10
F0
The user can choose the comfort temperature and change the unit’s blower speed
manually. If the vehicle’s engine is running or started up, the unit will automatically
pass into
p0
mode in a brief period of time.
NOTE: This function,
p0
, cannot be selected manually. It is automatically activated by
the unit. This function can also be automatically activated by the unit with the vehicle’s
engine off whenever it detects that the batteries are well charged. The unit will remain in
this mode for a time after passing into selected
F0
mode.
Comfort temperature can be controlled by briey pressing the
-
+
keys of the
control panel or of the remote control. The blower speeds can be controlled
by keeping the
-
+
keys of the control panel pressed down or from on the
remote control, with the display showing
V1
,
V2
,
V3
,
V4
,
V5
.
When selecting
F4
the symbol
CA
will appear on the display alternating between the
selected temperatures. The user can choose the comfort temperature manually. With
this function, the unit regulates automatically its performance parameters until the cho-
sen comfort temperature is achieved. If the engine is running or the engine starts
running, the unit will automatically change onto the
P4
mode within a short period
of time.
Función
F0
- Manual Operation of the equipment, at intermediate power.
P0
Manual Operation , Maximum power.
Function
F4
Automatic Operation of the Unit, at intermediat power
p4
Automatic Operation of the unit at maximum power
Function
F1
- Digital thermometer function.
Function
F2
- Time Programming Function.
In this function, the Compact 3.0 will indicate on the screen the temperature inside the cabin.
F2
programmes the unit to disconnect automatically during a period of time between 1
and 9 hours. To programme it, keep the On/Off pressed until
F2
appears on the
screen, select the operating time with the
-
+
keys and conrm by pressing On/Off
.
